A proof of conceptwith Hadoop :storage andanalytics ofelectrical time-series June 13th 2012 Bruno JACQUIN, Marie-Luce PICARD, Leeley DAIO-PIRES DOS SANTOS, Alzennyr GOMES DA SILVA, David WORMS, Charles BERNARD

Outline1. A very brief presentation of the EDFGroup2. Smart metering data3. Massive data management for utilities ?4. A Proof of Concept using Hadoop5. Conclusion and Perspectives

The EDF Groupprofile

EDF GROUP PROFILE EDF Group profile¥  A leading player in the energy market, active in all areas of electricity from generation to trading and network management.¥  Balance between regulated and deregulated activities.¥  Expertise in engineering and operating generation plants and networks.¥  Expertise in the design and promotion of energy eco-efficiency solutions. in the French and UK electricity markets, solid positions in Italy and numerous¥  Leader other European countries; industrial operations in Asia and the United States. 37 million 630,4 TWh 108.9g of CO2 customers worldwide electricity generation worldwide per kWh generated (CO2 emissions from EDF Group electricity and heat generation) 158,842 €65.2 billion employees worldwide in sales Consolidated data at 12.31.2010.

EDF WORLDWIDEMap of Group operations

Smart-Grids projects everywhere in theworld ... Key: red=electricity, green=gas, blue=water and triangle=trial or pilot where circle=projectEDF R&D : Créer de la valeur et préparer l’avenir 6

The EDF Group: a bright outlook for smartgrids Lower consumption peaks mean less Clearer information dependence on high-carbon generation to raise awareness of energy saving strategies Decarbonization of the energy mix Billing based on actual through a smoother integration consumption of renewable energies into networks Smart meter Reduction in network losses to boost competitivity of the system Precision in targeted investments for the maintenance and modernization of networks More efficient repairs to networks after extreme weather events Promoting the development of electric transportation that emits fewer green house gases New energy uses (e.g. electric mobility, storage, etc.)

Smart Grids : what ? And what for ?" Environmental, economical, social and policy drivers lead to a deep change of the energy sector: "  Climate change, environmental concerns "  Increased pressure of operational and financial efficiency "  Increasing awareness of consumers, role of citizens "  Technological pressure (IT, smart devices)Source – WikipediaA smart grid delivers electricity from suppliers to consumers usingdigital technology with two-way communications to control appliancesat consumers homes to save energy, reduce cost and increasereliability and transparency. It overlays the electrical grid with aninformation and net metering system, and includes smart meters.Such a modernized eletricity network is being promoted by manygovernments as a way of addressing energy independence, globalwarming and emergency resilience issues.

Smart metering data:the Precious LoadCurves

WhatData ou « The curve look like ? Big does a load data deluge »

WhatData ou « The curve look like ? (2) Big does a load data deluge »

WhatData ou « The curve look like ? (3) Big does a load data deluge » Individual load curves : - Left : same customer, two different days - Up: same day, two different customers

Massive datamanagement forutilities ?

Massive data management in the energydomain: myth or reality ?"  Challenges : "   More complexity in the electric power system (demand response, distributed generation …) "   Faster evolution of customer indoor equipment (smart meters and devices, Internet of Things …) ð  Core business will involve more IT and data management"  The R&D SIGMA project deals with scalability and Big Data : "   Skillson Big Data techniques "   Prototyping on business cases "   With internal (IT), academic or industrial partners

Massive data management in the energydomain: myth or reality ?"  The SIGMA project studies and experiments appropriate methods and techniques "  Storage technologies for massive data sets, especially time- series "   Data processing : "   Complex Event Processing, real time analytical processing "   Large scale data-mining : massively parallel processing, distributed data-mining"  Use cases "  Smart-grids, CRM and customer insight, generation optimization : consumption and production forecasting, power plant maintenance

A Proof of Conceptusing Hadoop

Storing massive time series"  Objective: Proof of Concept for running a large number of queries (variable levels of complexity with variable scopes and frequencies, variable acceptable latencies) on a huge number of load curves "   Data: individual curves, weather data, contractual information, network data "   1 measurement every 10 mn for 35 million customers a year "   Annual volume of data "   1800 billion records ; 120 TB uncompressed data

Storing massive time series: objectives "  Build an « operational Data Warehouse » able to: "   Supply a large volume of data "   Ingest new coming data "   Pre-processing, synchronization and filling "   Allow concurrent and simultaneous queries " Tactical queries: Curve selection compared with a mean curve " Analytical queries: Aggregated curves " Ad-hoc queries "   ‘Recoflux’ (simplified) "   Extraction capabilities

Storing massive time series: evaluation "  Evaluation criteria " Quantitative "   competition(QoS) "   Performances (SLA) " Qualitative : "   Convergence "   Agility

Using relational technologies for storingmassive time series"  Relational approaches, Very Large DataBases "   Works carried out with partners: Teradata, Oracle, IBM, EMC², HP "   Appliances or software offers, "   Shared-nothing or shared-everything ; Column-based, line or hybrid mode? "   Separation between an operational use (ODS) and an analytical use (DWH)?

Using Hadoop for storing massive time series "   Native distributed file-system (HDFS) "   Distributed treatments using the Map/Reduce paradigm "   Large dotcom usage but very limited industrial deployment, maturity is yet to come despite the major editors arriving with offers including integration, appliances and support "   Internal POC concluded in April 2012

The Data model The data deluge » Big Data ou « Compressed data Volume on HDFS : è 10 TB (x3)

Data generator - CourboGen © "   Generates load curves and associated data "   Customizable tool: interval, duration, data quality, noise on the curves "   Distributed architecture (NodeJS, Redis) "   Output as data streamVisualization of 35M curves for one week

Design"   Hive in the center of our DW" HBase at the forefront of data access

Design "   Hive in the center of our DW "  Allows ad-hoc and complex analytical queries "   Customer tables stored as rcfile are replicated in all Data Nodes (19) "   Consumption measurements are partitioned by day and customer profil criteria "   Daily volume: 25 GB ; Average block size: 10 MB " HBase at the forefront of data access "  Allows low latencies queries "   Recent metering data stored “In Memory” tables "   Stores a subset of measurements and aggregates in tables with “Bloom filters” enabled

Hardware configuration: the cluster"   20 nodes in 2 racks: "  7 x 1U nodes with 4 x 1 TB "   13 x 2U nodes with 8x1 TB "   Total : 132 TB ; 336 cores (AMD)" Hadoop distribution : Cloudera CDH3u3 (open source)

Hardware configuration: the cluster

Time series representation models: options §  TUPLE CREATE TABLE cdc_tuple ( id_cdc INT, date_releve TINYINT, p INT ) PARTITIONED BY(day STRING, optarif STRING, psousc TINYINT) ROW FORMAT SERDE org.apache.hadoop.hive.serde2.columnar.ColumnarSerde STORED AS RCFILE; §  ARRAY CREATE TABLE cdc_array ( id_cdc INT, values array< array< int > > ) … §  COLUMN CREATE TABLE cdc_144_cols (id_cdc INT, p1 INT, p2 INT, …, p144 INT )…

Time series representation models: optionsGetting a daily individual load curve‘select * from cdc_tuple where day=2008-01-01 and id_cdc =136630;’

Time series representation models: impact "   Computing a global aggregated load curve for 1 day Representation model Daily volume Query execution time Tuple 10.1 GB ( x 3 replicas) 2 min 22 sec Column 8.8 GB ( x 3 replicas) 1 min 17 sec Array 16 GB ( x 3 replicas) 1 min 18 sec

Results - HBase"   Tactical queries are successfully handled by HBase, offering low latencies under a high concurrent load. Representation Period Nb concurrent Queries / Sec Query execution model execution queries time (seconds) time Columns (7 * 144) 1 minute 100 470 0.21 Array (7 x 1 array of 1 minute 100 495 0.20 144 values) Columns (7 * 144) 5 minutes 500 524 0.19 Array (7 x 1 array of 5 minutes 500 430 0.18 144 values) Query: curve selection

Results – Hive (1) Query Execution time (tuples representation) Aggregation France (sum) 10 min interval 1 min, 56 sec Load curve aggregated by contractual information 2 min, 21 sec Analysing consumption trends according to the customers building 1 heure, 18 sec caracteristics TOP N customers candidates for a power level update 1 heure, 7 min, 35 sec Results for different queries: - Planned queries (with adequate partitioning) - ad-hoc queries

Results – Hive (2)"   Recoflux scenarios Scénario Mode séquentiel (minutes) Mode parallèle (minutes) 1 jour 1 semaine 1 jour 1 semaine 521 1.44 10.10 1.56 3.00 522 27.87 195.09 28.50 31.01 523 7.98 23.94 524 10.71 74.99 15.97 19.58 525 6.10 42.70 7.45 8.39 526 0.86 6.08 0.92 2.43" Recoflux is a very important business application (power consumption aggregations are computed according to different criteria ; updates and temporal data): results really acceptable

Using NoSQL technologies for storingmassive time series: resultsIntegration Hadoop / Tableau Software : visualisation of 700k feeders

Alternative approach for storing massivetime-series : conclusions"  The less "   Not yet mature, a few feedbacks available in the industry "   Lack of competences in Europe (impact of configuration and tuning, smart skills) "   Major editors offering: still young but actively emerging"  The more "   Low cost "   Ability to recycle existing commodity hardware "   One of the few solution which allows the coupling between structured and unstructured data "   Flexibility despite being a complex system to deploy and manage. Fault tolerant and scalable.

Alternative approach for storing massivetime-series : conclusions"  Perspectives "   Partnersoffering industrial support "   Hardware configuration "   Usage of statistical libraries "   Connectivity with the relational world "   USAGES: "  ETL, "  intelligent and reliable archival solution, "  high throughput data presentation (publication)

Conclusions and perspectives" Hadoop perspectives "   Non traditional usage of Hadoop using a structured schema "   Will become a component of the company IS for non-critical usages "   Any suggestions ? "   storage mode for time-series ? "   usages ?"  Contacts: " marie-luce.picard@edf.fr " bruno.jacquin@edf.fr
