Low Latency OLAP with Hadoop and HBase

  1. 1. Low-Latency “OLAP” with Hadoop and HBase Andrei Dragomir | Software Engineer© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
  2. 2. Synopsis §  What are we trying to solve §  Description of our system §  How it works §  Minimizing Latency© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 2
  3. 3. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 3
  4. 4. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 4
  5. 5. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 5
  6. 6. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 6
  7. 7. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 7
  8. 8. In a nutshell Low-latency OLAP system Hadoop DFS to store input data (ie log files, or HBase tables) The processing loop of the system takes a cube description and processes it (pre-aggregations) using Hadoop Map/Reduce. The output is written to a statistics HBase table. To get the data, users query a server, which scans the HBase table, applying the filters, roll-ups or drill-downs, and returning the result.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 8
  9. 9. Vocabulary Date Country City OS Browser Sales 2012-05-12 USA NY Win FF $ 0.0 2012-05-12 USA NY Win FF $ 10.0 2012-05-13 USA SF OSX Chrome $ 25.0 2012-05-13 Canada Ontario Linux Chrome $ 0.0 2012-05-14 USA Chicago OSX Safari $ 15.0 ... ... ... ... ... ... 5 Visits 2 Countries 4 Cities: 3 OS: 3 Browser: $50.0 3 Days USA: 4 NY: 2 Win: 2 FF: 2 3 sales Canada: 1 SF: 1 OSX: 2 Chrome: 2© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 9
  10. 10. Vocabulary Date Country City OS Browser Sales 2012-05-12 USA NY Win FF $ 0.0 2012-05-12 USA NY Win FF $ 10.0 2012-05-13 USA SF OSX Chrome $ 25.0 2012-05-13 Canada Ontario Linux Chrome $ 0.0 2012-05-14 USA Chicago OSX Safari $ 15.0 ... ... ... ... ... ... 5 Visits 2 Countries 4 Cities: 3 OS: 3 Browser: $50.0 3 Days USA: 4 NY: 2 Win: 2 FF: 2 3 sales Canada: 1 SF: 1 OSX: 2 Chrome: 2 §  We want to get (mostly) numeric data: metrics §  These metrics have a set of labels (dimensions) §  We want to view the metrics by any combination of dimensions© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 10
  11. 11. Vocabulary Date Country City OS Browser Sales 2012-05-12 USA NY Win FF $ 0.0 2012-05-12 USA NY Win FF $ 10.0 2012-05-13 USA SF OSX Chrome $ 25.0 2012-05-13 Canada Ontario Linux Chrome $ 0.0 2012-05-14 USA Chicago OSX Safari $ 15.0 ... ... ... ... ... ... 5 Visits 2 Countries 4 Cities: 3 OS: 3 Browser: $50.0 3 Days USA: 4 NY: 2 Win: 2 FF: 2 3 sales Canada: 1 SF: 1 OSX: 2 Chrome: 2 §  We want to get (mostly) numeric data: metrics §  These metrics have a set of labels (dimensions) §  We want to view the metrics by any combination of dimensions© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 11
  12. 12. Vocabulary Date Country City OS Browser Sales 2012-05-12 USA NY Win FF $ 0.0 2012-05-12 USA NY Win FF $ 10.0 2012-05-13 USA SF OSX Chrome $ 25.0 2012-05-13 Canada Ontario Linux Chrome $ 0.0 2012-05-14 USA Chicago OSX Safari $ 15.0 ... ... ... ... ... ... 5 Visits 2 Countries 4 Cities: 3 OS: 3 Browser: $50.0 3 Days USA: 4 NY: 2 Win: 2 FF: 2 3 sales Canada: 1 SF: 1 OSX: 2 Chrome: 2 §  We want to get (mostly) numeric data: metrics §  These metrics have a set of labels (dimensions) §  We want to view the metrics by any combination of dimensions© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 12
  13. 13. OLAP Queries §  Rolling up to country level Country visits sales SELECT  COUNT(visits),  SUM(sales)   USA 4 $50 GROUP  BY  country   Canada 1 0 §  “Slicing” by browser Country visits sales SELECT  COUNT(visits),  SUM(sales)   USA 2 $10 GROUP  BY  country   Canada 0 0 HAVING  browser  =  “FF”   Browser sales visits §  Top browsers by sales Chrome $25 2 SELECT  SUM(sales),  COUNT(visits)     GROUP  BY  browser     Safari $15 1 ORDER  BY  sales   FF $10 2© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 13
  14. 14. Looking inside – physical diagram© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
  15. 15. Looking inside – logical diagram© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
  16. 16. Simplifying assumptions: pre-aggregation §  In most cases... §  Data needs to be summarized – hard to draw 1B data points §  You don’t need to look at all dimensions at the same time – hard to correlate §  Not all queries are used with the same frequency© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 16
  17. 17. A timeless CS problem: Optimize... Time Space §  Pre-aggregation §  Runtime §  Fast aggregation §  Flexible §  Efficient reads – O(1) §  Inflexible §  I/O, CPU intensive §  Processing latency §  Slow– always need §  Combinatorial to look at all the Explosion data §  Low throughput© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 17
  18. 18. Solution ? §  Just do both ! §  Can tune: pre-aggregate more, or rely on runtime aggregation §  Ingestion + process speed vs Query speed §  Works just like normal queries + materialized views© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 18
  19. 19. Solution ? §  Process: pre-aggregate all the report definitions, create an indexed HBase table. §  Query: use the indexes to get the data fast. Perform extra aggregation, filtering if needed at runtime. §  Platform strengths §  Parallelism in M/R §  Fast access and natural key ordering in HBase© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 19
  20. 20. Minimal HBase details Row   Columns...   §  Data is stored in tables Key   u1   v1   v2   v3   §  Each row has a key, u2   v   X   ...   and any number of columns (long & wide) u3   v   x   ...   u4   x   v2   ...   §  Ordered by row keys: u5   ...   v3   ...   clustered indexes u6   ...   v5   ...   built-in u7   ...   ...   ...   §  Sparse tables. NULLs u8   ...   ...   ...   are free.© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 20
  21. 21. Minimal HBase details Row   Column §  Operations use row key   ...   key: get(), put()   aaa   v1   aab   v2   §  Can scan a range of ←   rows:[start,  end)   aac   v3   ←   aad   v4   §  We can use the row ←   aae   v5   key as a built-in ←   aaf   v6   indexing aba   ...   mechanism abb   ...  © 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 21
  22. 22. SaasBase vs. SQL Views Comparison© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 22
  23. 23. Reports configuration §  List of Dimensions (with custom classes, arguments, etc) §  List of Metrics (with custom classes, arguments, etc) §  List of Reports, each containing §  Dimensions (subset) §  Metrics (subset) §  Sorting, etc §  The reports configuration is used in the entire system: import, process, query© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 23
  24. 24. Solution ? Date Countr Cit Sale y y s 2012-05-1 USA NY 3 2 2012-05-1 USA NY 10 2 2012-05-1 USA SF 25 3 2012-05-1 CAN ON 0 3 2012-05-1 USA CH 15 4© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 24
  25. 25. Solution ? Date Countr Cit Sale y y s 2012-05-1 USA NY 3 2 2012-05-1 USA NY 10 2 2012-05-1 USA SF 25 3 2012-05-1 CAN ON 0 3 2012-05-1 USA visits_by_city:  {   CH 15    dimensions:  [country,  city],     4    metrics:  [visits]   },     daily_sales:  {      dimensions:  [year,  month,  day,   country],        metrics:  [sales]   }  © 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 25
  26. 26. Solution ? Date Countr Cit Sale y y s 2012-05-1 USA NY 3 2 2012-05-1 USA NY 10 2      Statistics  HBASE  Output  Table            ROWKEY                        VALUE   2012-05-1 USA SF 25 3 daily_sales/2012+05+12+USA        $13     daily_sales/2012+05+13+CAN        $0   2012-05-1 CAN ON 0 daily_sales/2012+05+13+USA        $25   3 daily_sales/2012+05+14+USA        $15   2012-05-1 USA visits_by_city:  {   CH 15 visits_by_city/CAN+ON                  1      dimensions:  [country,  city],     4    metrics:  [visits]   visits_by_city/USA+CH                  1   },     daily_sales:  {   visits_by_city/USA+NY                  2      dimensions:  [year,  month,  day,   visits_by_city/USA+SF                  1   country],        metrics:  [sales]   }  © 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 26
  27. 27. HBase natural order: hierarchical filtering© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 27
  28. 28. Sorting §  Add the metrics that you want to sort by to the row key... §  In a way that preserves the ordering© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 28
  29. 29. Sorting §  Add the metrics that you want to sort by to the row key... §  In a way that preserves the ordering §  ORDER  BY  metric  DESC  ==  Long.MAX_VALUE  –  metric   2012+05+USA+0000000000+   2012+05+USA+4294961296+SF  =  1000  visits   2012+05+USA+4294961396+NY  =  900  visits   .  .  .       2012+05+USA+9999999999+  © 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 29
  30. 30. Minimizing Latency© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
  31. 31. Minimizing Import Latency §  Only import the minimal set of changes §  Map/Reduce input filters: §  c.a.s.a.i.FileCache – checks if file already processed §  c.a.s.a.i.FileDateFilter – checks if a date in the file path is against a specified interval §  process files from 3 days ago up until now, once §  HBase scan (from import table) start and stop row §  Minimize map-task overhead – stitch input splits© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 31
  32. 32. Minimizing Import Latency §  Minimize map-task overhead – stitch input splits §  for 400000 files -> 400000 Map Tasks, slow reduce-copy phase §  o.a.h.m.i.CombineFileInputFormat – make 2GB splits §  c.a.s.a.m.i.FixedMappersTableInputFormat – stitches multiple HBase regions in the same map task© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 32
  33. 33. Minimizing Import Latency §  If warehousing in HBase, use o.a.h.h.m.HFileOutputFormat   §  ~ 100 times faster than using the API §  No shuffle step! you must use a global order partitioner §  Problem: data grows over time §  Solution: estimate output partitions based on input data size, and make partitions (regions) using this heuristic §  c.a.s.a.m.FileSizeDatePartitioner – inject input files size and dates and rebalance regions based on these, and a fixed size (2GB)© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 33
  34. 34. Minimizing Processing Latency §  Processing involves reading the input (files, tables, events), pre-aggregating it (reducing cardinality) and generating tables that can be queried in real-time §  Processing does GROUP BY, COUNT/SUM/AVG, ORDER BY §  Minimize each M/R step: read, map, partition, combine, copy, sort, reduce, write §  Read §  Filter input data (incremental processing) – differentiate between OPEN and CLOSED data §  HBase Scan options: caching, batching, etc §  Ensure HBase table regions are distributed in the cluster© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 34
  35. 35. Minimizing Processing Latency §  c.a.s.a.m.j.SuperProcessor   §  One shot M/R job: for all data, for all reports, emit the pre-aggregated values in 1 map() call §  no allocations §  Simple and tight §  no system calls (avoid context switches) §  no String <> byte[] transformations §  minimize Map > Combine > Reduce I/O §  NO ALLOCATIONS© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 35
  36. 36. Minimizing Query Latency §  c.a.s.a.m.t.ReportHandler   §  Simple Thrift server §  Data is already processed and pre-aggregated §  Query time does HAVING/WHERE (filters), extra GROUP BY (roll-ups) §  Calculate an optimal set of HBase scan()s   §  single / multiple scans §  start / stop rows (prefixes, index positions) §  Perform extra roll-ups / sorting §  Assorted sundries: paging, display-time ser/des, etc© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 36
  37. 37. Flexible §  Report configuration – the core of the system §  c.a.s.a.e.Dimension, c.a.s.a.e.Metric   §  Can override ser/des, aggregate functions (for metrics) §  Can override behavior (only add 1 if X...) §  Emergent patterns are rolled-up in the reporting core §  The entire processing loop can be written outside of M/R for realtime §  Storm ? §  Applied in 4 use-cases right now, easy to extend §  Some programming required© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential. 37
  38. 38. Thank you adragomi@adobe.com / @adragomir http://hstack.org Our team: Adrian Muraru, Andrei Dulvac, Bogdan Dragu, Bogdan Drutu, Cosmin Lehene, Raluca Podiuc, Tudor Scurtu© 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
  39. 39. © 2012 Adobe Systems Incorporated. All Rights Reserved. Adobe Confidential.
