Integrated Risks Transfer   Mode of   Large Scale Disasters in  China  and  World   Peijun SHI State Key Laboratory of E...
Contents <ul><li>Large-scale Disaster and  Its Risk Assessment  </li></ul><ul><li>Integrated Risks Transfer   Mode of   </...
1   Large-scale Disaster and  Its Risk Assessment
Indian Ocean tsunami, 2004 Katrina Hurricane, USA, 2005 Wenchuan Earthquake, China, 2008 Typhoon-Storm Disaster, Myanmar, ...
Large-scale Disaster Snowstorm of Southern China,2008 Wenchuan Earthquake, 2008 Tangshan Earthquake, 1976 Yangtze River Fl...
<ul><li>A serious disaster due to hazards encountered  once in one century , causing  huge human casualties  and  property...
Standard of Large-scale Disaster Classification Notes: (1) The standard for different disaster grades shall meet  any two ...
Major Features of Large-scale Disaster <ul><li>Huge human casualties </li></ul><ul><ul><li>Eg, China Wenchuan Earthquake i...
Cases of Worldwide LSDs (1989-2009) Year  Disaster Name Intensity (frequency) Death Toll (persons)  Affected Area (10 4 km...
The Risk Assessment of Large-scale Disasters <ul><li>Regional Multi-hazard Loss Assessment Model  </li></ul><ul><li>Region...
“ multi-hazards” and  “disaster chains”   The  “multi-hazards”  refers to a succession of hazards that always co-exists an...
Regional Multi-hazard Loss Assessment Model For  the given district D, at the time T 1  before disaster, the exposures’ va...
Regional Multi-hazard Loss Assessment Model Based on above analysis, the total loss of multi-hazard in region D caused by ...
Regional Multi-hazard Loss Assessment Model <ul><li>A Case of Regional Multi-hazard Loss Assessment </li></ul>
The Matrix Method of Hazard Causing and Disaster Forming multi-hazard risk in Europe JRC–Multi-risk Approach
Map of Comprehensive Urban Natural  Disaster Intensity in China
Regional Disaster-chain Loss Assessment Model <ul><li>Properties of  Disaster-chain </li></ul><ul><li>Inducibility:  the c...
<ul><li>Loss Assessment by Areas and Hazards </li></ul>Regional Disaster-chain Loss Assessment Model where,  The total dis...
A Case of Regional Disaster-chain Loss Assessment <ul><li>Wenchuan Earthquake Catastrophe of May 12, 2008 </li></ul>Region...
Wenchuan Earthquake <ul><li>14:28 pm on May 12 of 2008 , a major earthquake measuring 8 Richter scale jolted  Wenchuan Cou...
Wenchuan Earthquake, 2008
Assessment of Wenchuan Earthquake Disaster Chain Heavy Rain Rock Collapse Landslides Earthquake Barrier lakes Debris Flow
Disaster Index (DI) <ul><li>The weight for each indicators:  </li></ul><ul><ul><li>Average magnitude of earthquake (0.3); ...
Assessment Map of Wenchuan Earthquake Disaster Area Type
Evaluation Results of Wenchuan Earthquake Disaster Chain Table of Earthquake Disaster Estimated Losses in Chuan/Gan/Shaan(...
2  Integrated Risks Governance   Mode of   Large Scale Disasters in  China  and  World
Disaster risk sharing mechanism according to disaster intensity The large-scale Disaster Insurance Mode
Chinese   Risk  Transfer Mode of   Large-scale Disasters The China Agriculture Policy Insurance Experimentation  Program (...
Issues to be Considered Governments Public Insurance Companies Society :   general populace  private/public companies  com...
Chinese   Risk  Transfer Mode of Large Scale Disasters The principle of the risk transfer mode of LSDs should be  “ suppor...
Small disaster risk  relies on community government Medium-scale disaster risk  relies on local government governance Larg...
<ul><li>The  financial products  of “LSD risk” available in concerned countries all over the world include mainly:  </li><...
World   Risk  Transfer Mode of   Large Scale Disasters <ul><li>Based on the experience of risk governance in China, we pro...
World   Risk  Transfer Mode of   Large Scale Disasters <ul><li>The principle of global risk transfer mode should be   </li...
3 Discussion
Discussion  Integration of both  top-down  and  bottom-up  governance in  transition-in and transition-out  of LSD risk Ch...
Comparison Disaster Governance System Between China and US After Katrina, A New Shared Vision of National Preparedness Sys...
<ul><li>Thank you ! </li></ul>
