  • Hoogte 750 mm= 2.46 foot

Prezentare solutii WILA - scule si accesorii abkant Presentation Transcript

  • 1. “ Information about Wila and it’s products” WILA b.v. - Lochem (Holland) Peter Timmerije by
  • 2. Solutions by Wila
    • New Standard and American style Clamping systems
    • New Standard and American style Tooling
    • Crowning
    • Accessories
  • 3. Subjects
    • History of Wila
    • Difficulties in working with press brakes
    • Solutions by Wila
  • 4. Solutions by Wila
    • New Standard Clamping systems
    • New Standard Tooling
    • Crowning
    • Accessories
  • 5. History of Wila
    • Founded 1932
    • App. 225 employees in Lochem(NL)
    • - And 12 employees in our sales company in the USA
    • Mission: leading supplier Press Brake Tooling Systems:
      • Innovative technology (Products & Mfg.)
  • 6. Press brake, main components Upper beam Lower beam Frame Hydraulic cilinder Upper clamping system Top tool Lower tool Crowning
  • 7. Difficulties in working with press brakes
    • Many brands and types of press brakes and tools
  • 8. Many types of tools
  • 9. Difficulties in working with press brakes
    • Separate brands are not easily compatible
    • Shimming consumes time
    • Deflection delivers scrap
    • Changing tools
      • takes a lot of time and money
      • generates risks for injuries
    • Many brands and types of press brakes and tools
  • 10. Solutions by Wila
    • New Standard and American Clamping systems
    • New Standard Tooling
    • Crowning
    • Accessories
  • 11. NEW STANDARD and AMERICAN clamping systems
    • Fastest tooling changeovers
    • Automatic seating, aligning and centering
    • Clamps every tool segment separately
    • Vertical and horizontal loading
  • 12.
  • 13.
  • 14.
  • 15. Press brake tolerances
  • 16. Press brake tolerances
  • 17.
    • Level II ( NSCL II )
    • Level I ( NSCL I + and ASCL I )
    • Level Basic ( NSCL Basic )
    Clamping programm is split up in 3 levels .
    • Retrofit versions ( NCL… )
  • 18.
  • 19. Press brake tolerances
  • 20.
  • 21.
    • Level II ( NSCL II )
    Clamping programm is split up in 3 levels.
  • 22.
  • 23. Straightforward precision alignment Quick assembly www.wila.nl
  • 24. Keyhole-shaped fixing holes enables to be mounted to the ram and bed in a single, simple motion. Back Straightforward precision alignment www.wila.nl Quick assembly
  • 25. Alignment in the X-direction, i.e. in relation to the back gauge, is straightforward and permanently realizable over the machine’s entire length. This can significantly increase the economic life of the press brake Back Quick assembly Straightforward precision alignment (Tx)
  • 26. Non-deformable, one-piece body Hardened steel Maximum bending freedom Clamping possible at 10mm Specially designed clamping medium The body is fabricated from a single piece, which means that it is practically non-deformable. The special CrMo alloy provides a tensile strength of roughly 1100 N/mm2. Next part www.wila.nl
  • 27. Non-deformable, one-piece body Hardened steel Maximum bending freedom Clamping possible at 10mm Specially designed clamping medium The clamping medium is a hose, designed specifically for this purpose. Oil is pumped into this hose onder high pressure (40-50 bar). This results in an unrivalled clamping force over the full length of the machine. Next part www.wila.nl
  • 28. Non-deformable, one-piece body Hardened steel Maximum bending freedom Clamping possible at 10mm Specially designed clamping medium Every surface on the body which come into contact with tools is hardened to approximately 56 o Rc. This guarantees the preservation of all properties, resulting in an extremely long life. Next part www.wila.nl
  • 29. Non-deformable, one-piece body Hardened steel Clamping possible at 10mm Specially designed clamping medium The dimensions of the body - including the rear side - are minimal. This creates an unbelievably high degree of bending freedom. Next part www.wila.nl Maximum bending freedom α > 30 O
  • 30. Non-deformable, one-piece body Hardened steel Maximum bending freedom Clamping possible at 10mm Specially designed clamping medium Thanks to the design and spacing of the clamping pins, tool components with a minimum length of 10mm can be individually positioned and securely clamped, anywhere on the machine. Next part www.wila.nl
  • 31. Cover strip www.wila.nl
  • 32. The plastic guards at both ends of the clamping system provide guidance and prevent damage during the horizontal interchange of tools. The guards can also be delivered in a flat version . Next part www.wila.nl www.wila.nl Guard
  • 33. www.wila.nl
  • 34.
  • 35.
  • 36.
  • 37.
  • 38.
  • 39.
  • 40. NSCL II
    • Hydr. Clamping
    • UPB
    • Min. tool length 10 mm (.394)
    • Release time 1.5 sec.
    • Pull-up weight 180 kg/meter (120 lb/ft)
    • F max. h ead 250 T/meter (84 US tons/ft) shoulders 300 T/meter (101 US tons/ft)
    • - Material 1000-1200 N/mm2 (145000-174000 PSI )
    • Contact surface CNC deep hardened 56 HRc
    • Cover strip Alu.
  • 41.
  • 42.
    • Level II ( NSCL II )
    Clamping program is split up in 3 levels.
    • Level I ( NSCL I + and ASCL I )
  • 43. NSCL I + ASCL I
  • 44. NSCL I+ and ASCL I
    • Hydr. Clamping
    • Min. tool length 15 mm (.591)
    • UPB
    • Material 600-720 N/mm2 (87000-104400 PSI )
    • Cover strip black.
  • 45. NSCL I+
    • Release time 2.5 sec L= 3060 mm
    • (10 ft )
    • F Max. head180 T/meter (60 US tons/ft),
    • shoulders 250 T/meter (84 US tons/ft),
    • - Pull-up weight 100 kg/meter (67 lb/ft)
  • 46. ASCL I
    • Release time 2.5 sec L= 3060 mm
    • (10 ft )
    • F Max. shoulders 160 T/meter (54 US tons/ft),
    • Pull-up weight 75 kg/meter (50 lb/ft)
  • 47.
  • 48.
    • Level II ( NSCL II )
    • Level I ( NSCL I + and ASCL I )
    Clamping programm is split up in 3 levels.
    • Level Basic ( NSCL Basic )
  • 49. NSCL Basic
  • 50. NSCL Basic
    • Mech. Clamping
    • UPB
    • - Min. tool length 20 mm (.787)
    • F Max. head 180 T/meter (60 US tons/ft),
    • shoulders 250 T/meter (84 US tons/ft),
    • Material 600-720 N/mm2 (87000-104400 PSI )
    • Cover strip bronze
  • 51.
    • Level II ( NSCL II )
    • Level I ( NSCL I + and ASCL I )
    • Level Basic ( NSCL Basic )
    Clamping programm is split up in 3 levels.
    • Retrofit versions ( NCL… )
  • 52. NCL…
  • 53. NCL…
    • Hydr. Clamping
    • Press brakes with customized ram
    • Min. tool length 15 mm
    • - Material 600-720 N/mm 2
  • 54. NEW STANDARD interchangeable press brake tools
    • Delivery from stock
    • Precision ground
    • Made of a special CrMo-alloy steel
    • CNC deep hardened for trouble free service
    • Patented quick-change button for fast tooling change-overs
    “ Safety-Click ”
  • 55.
  • 56. Hardening possibilities Nitrating Laser hardening CNC Deep hardening
  • 57.
  • 58.
  • 59. Available modified Standards New standard With nose 28 º Radius R=1.5 and 2 mm With nose 60 º Radius R=2 –3-4 and 5 mm With nose 80º thru 90º R=2-3-4-5 and 6 mm
  • 60.
  • 61. Accessories
  • 62. NEW STANDARD anti deflection devices
    • Eliminate time-consuming shimming
    • Enable less experienced operators to achieve faster bends
    • Cut down on scrap
    • Increase productivity
  • 63.
  • 64. Deflection of the Press Brake during bending
  • 65. Deflection of the Press Brake during bending
  • 66.
  • 67. Crowning, 4 basic concepts
  • 68.
  • 69. Crowning , 4 basic concepts
  • 70.
  • 71.
  • 72.
  • 73.
  • 74. Crowning, 4 basic concepts
  • 75.
  • 76.
    • Level II ( NSCR II )
    Crowning programm is split up in 3 levels.
  • 77. New Standard Crowning II
  • 78.
  • 79.
  • 80.
  • 81.
  • 82.
  • 83.
  • 84.
  • 85.
  • 86.
  • 87.
  • 88.
  • 89.
  • 90.
  • 91.
  • 92.
  • 93. NSCR II
    • Hydr. Clamping
    • UPB
    • Release time 1sec.
    • Min. tool length 10 mm (.394)
    • Material 1000-1200 N/mm2 (145000-174000 PSI )
    • F max. shoulders 300 T/meter(101 US tons/ft)
    • Contact surface CNC deephardened 56 HRc
    • Cover strip Alu.
  • 94.
    • Level II ( NSCR II )
    Crowning programm is split up in 3 levels.
    • Level I ( NSCR I + )
  • 95. NSCR I +
  • 96. NSCR I+
    • Hydr. Clamping
    • UPB
    • Release time 1sec.
    • Min. tool length 15 mm (.591)
    • Material 600-720 N/mm2 (87000-104400 PSI )
    • F max. shoulders 200 T/meter(67 US tons/ft)
    • Cover strip black
  • 97.
    • Level II ( NSCR II )
    • Level I ( NSCR I + )
    Crowning programm is split up in 3 levels.
    • Level Basic ( NSCR Basic )
  • 98. NSCR Basic
  • 99. NSCR basic
    • Mech. Clamping
    • UPB
    • Min. tool length 20 mm (.787)
    • F Max. shoulders 200 T/meter(67 US tons/ft)
    • - Material 600-720 N/mm2 (87000-104400 PSI )
    • Cover strip bronze
  • 100.
    • Level II ( NSCR II )
    • Level I ( NSCR I + )
    • Level Basic ( NSCL Basic )
    Crowning programm is split up in 3 levels.
    • Retrofit versions ( NCR… )
  • 101. NCR…
  • 102. NCR ...
    • Hydr. Clamping
    • Press brakes with normal lower beam
    • Material 600-720 N/mm 2
  • 103. “ Thank you for your attention”
