November 20111   © 1994 – 2011 Fieldbus Foundation
Outline• Remote Operations Management:  Definition and Business Challenges• Introducing FOUNDATION for ROM:  Technology an...
Remote Operations Management Applications•       Oil & Gas Pipeline        SCADA•       Offshore Platforms•       Oil & Ga...
Business Drivers for Growth in Remote Operations            Management Market•       Plant operations are becoming more   ...
The Business Challenges•       Traditional approach does not work•       Move from steady state to dynamic        environm...
Upstream Capital and Operating Costs Rising•   Need to reduce capital and    operational costs•   According to IHS/CERA, “...
End User Requirements•   Users need a real time view into    what’s happening in widely    dispersed remote assets•   User...
The Old Remote Operations Management Model•       Systems collect historical data•       End users analyze the data using ...
Introducing FOUNDATION for Remote Operations        Management•   Provides a wireless and wired infrastructure for remote ...
Application Example                              Control Room                                   BACKHAUL:                 ...
What are FOUNDATION for ROM Products?• More than a simple protocol  translation gateway• Capability Can be Embedded  into ...
The Business Value of FOUNDATION for ROM for End       Users• Enables real time operations  management and more effective ...
The Business Value of FOUNDATION for ROM for       Suppliers• Fills key gaps in current remote                            ...
Our Future Direction: Helping Users            Realize the Benefits                                           November 201...
Seeing Your Process in High Definition• Diagnostic Data from FOUNDATION  Fieldbus Devices is Miles Ahead of  Other Technol...
Managing Information• You know you are getting a true  measurement, no digital to analog  conversion• Persistent data stor...
A Single Environment for Information in Context & Data     Quality                                                        ...
Information Provided in Context• Allows data to be managed and                           Business                         ...
Optimizing People and Processes• Implementation of Predictive and Proactive Asset Management  Strategies• More Effective U...
Improved Integration of Functional Areas for ROM•        Machinery health         Monitoring•        Safety Interlocks•   ...
An Open Standard for Remote Operations         Management•    FOUNDATION Technology is a     Standard. Standards Promote  ...
Potential Market•        The worldwide market for SCADA rebounded         in 2010 after weathering the effects of the     ...
Application Examples: Oil and Gas Fields•        Enables Integrated Operations                             Source: CAP Gem...
Application Examples: Pipelines•    API Monitoring, Custody Transfer                          Source: Moxa                ...
Application Examples: Tank Farms •   Overfill Protection, Integration of Fire & Gas     Detection                         ...
Application Examples: Mining, Hydro Fracking • Coordination of widely dispersed automation assets • Oil sands • Concentrat...
Application Examples: Pharma• Faster Integration of Multiple  Skid Mounted Mobile Units• Faster Commissioning• Easier Vali...
Upcoming SlideShare
Loading in...5
×

02 foundation for rom media day presentation

260

Published on

Published in: Business, Economy & Finance
1 Comment
0 Likes
Statistics
Notes
  • Be the first to like this

No Downloads
Views
Total Views
260
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
19
Comments
1
Likes
0
Embeds 0
No embeds

No notes for slide
  • It is the direction of helping users realize the benefits of FOUNDATION technology throughout the lifecycle of the plant that will provide the cornerstone of our strategy moving forward. We all love technology, but technology itself is of little value if it does not provide a business value proposition. Our goal is to help users see their process in high definition, manage information effectively to make the best decisions about their operations, and optimize their overall plant performance.
  • Transcript of "02 foundation for rom media day presentation"

    1. 1. November 20111 © 1994 – 2011 Fieldbus Foundation
    2. 2. Outline• Remote Operations Management: Definition and Business Challenges• Introducing FOUNDATION for ROM: Technology and Application Examples• What FOUNDATION for ROM can Bring to Remote Operations November 20112 © 1994 – 2011 Fieldbus Foundation
    3. 3. Remote Operations Management Applications• Oil & Gas Pipeline SCADA• Offshore Platforms• Oil & Gas Fields• Water & Wastewater SCADA• Tank Farms & Terminal Automation• Mining November 2011 3 © 1994 – 2011 Fieldbus Foundation
    4. 4. Business Drivers for Growth in Remote Operations Management Market• Plant operations are becoming more geographically dispersed• Resources are being found in increasingly hard to reach and hazardous areas• Drive to subsea production• Effort to get people out of harm’s way and reduce personnel requirements : “Lights Out” operation• Need to transport resources over greater distances• “…a new generation of mega pipelines is being built to bring massive amounts of natural gas from some of the most remote regions of the world to many of the most densely populated centers of New Generation of Mega Pipelines commerce and industry. “ – Forbes Source: Forbes Magazine November 2011 4 © 1994 – 2011 Fieldbus Foundation
    5. 5. The Business Challenges• Traditional approach does not work• Move from steady state to dynamic environment• Dynamically changing supply and demand• Tighter production specifications• Increased regulatory pressure• Human resources challenge: Increasingly challenging to send operators to check remote service areas Workers Check a Pipeline in China• Integration of wireless technology Source: AP• Increased focus on cyber security November 2011 5 © 1994 – 2011 Fieldbus Foundation
    6. 6. Upstream Capital and Operating Costs Rising• Need to reduce capital and operational costs• According to IHS/CERA, “The rising costs of both building and operating upstream oil and gas facilities continued to increase in the past six months• “Both cost indexes registered their largest increases since the Great Recession during the Q3 2010-Q1 2011 period.”• “Costs for construction labor and engineering and project management posted strong gains, 9 percent and 6 Source: IHS/CERA percent, respectively. “• Users are building ever larger installations. The engineering and 6 customization problem is magnified. November 2011 © 1994 – 2011 Fieldbus Foundation
    7. 7. End User Requirements• Users need a real time view into what’s happening in widely dispersed remote assets• Users need to know the state of the assets as well as the state of the process• Process must keep running safely in the event of loss of communication with remote assets/process• Solution must provide high level of both physical and cyber security• A lot of complex equipment. Need to link in people that understand this equipment in a secure fashion around the world• Faster time to startup• Reduced operational costs November 2011 7 © 1994 – 2011 Fieldbus Foundation
    8. 8. The Old Remote Operations Management Model• Systems collect historical data• End users analyze the data using their tools and their intellect• End user make decisions about the future based on their conclusions and historical data• Steady state environment• “Coordination comes from a central location in a rigid, hierarchical fashion”: ARC Advisory Group• Hard wired• Large degree of customization is often the case• Run to failure November 2011 8 © 1994 – 2011 Fieldbus Foundation
    9. 9. Introducing FOUNDATION for Remote Operations Management• Provides a wireless and wired infrastructure for remote assets and applications, all within FOUNDATION fieldbus• Integrates Wired Infrastructure, Remote I/O, ISA100.11a and WirelessHART®• Incorporate remote operations data into FOUNDATION Fieldbus infrastructure for data management with direct access to device diagnostics• FOUNDATION for ROM has the potential to transform remote operations, providing greater reliability and reduced costs. November 2011 9 © 1994 – 2011 Fieldbus Foundation
    10. 10. Application Example Control Room BACKHAUL: WIFI, WIMAX, SATELLITE CELLULAR, ETC. Remote Process Wireless Backhaul Enables HSE Wired and Wireless Backhaul Access To Remote Sensors Using Standard Wireless FOUNDATION for ROM Device Technologies I/O H1 HART Wireless November 201110 © 1994 – 2011 Fieldbus Foundation
    11. 11. What are FOUNDATION for ROM Products?• More than a simple protocol translation gateway• Capability Can be Embedded into Existing RTUs, Controllers, etc.• Will be Tested & Registered with Fieldbus Foundation November 201111 © 1994 – 2011 Fieldbus Foundation
    12. 12. The Business Value of FOUNDATION for ROM for End Users• Enables real time operations management and more effective use of remote experts• Data structures, data quality, EDDL• Fewer Personnel• Reduced engineering and operational costs• Familiar & comprehensible to a good DCS engineer• Highly configurable• Enables Predictive Maintenance Strategy• Increased Reliability & Availability Source: Aramco• Open and Interoperable Standard• Less Customization• Greener November 2011 12 © 1994 – 2011 Fieldbus Foundation
    13. 13. The Business Value of FOUNDATION for ROM for Suppliers• Fills key gaps in current remote Secure Access operations management capability Traceability by extending FOUNDATION Data integrity Technology to remote operations Management of Change (OSHA 1910.119)• Accelerates next generation remote Interspersed functionality operations management capability Same system or multiple systems• Can greatly improve your value Multiple instances of the same data point proposition for plant asset Risk management management Crisis recovery• Enables additional services - Personnel productivity feasibly studies, application Systems health services Potential Issues to be considered in an Automation Asset Management Plan• Inherent security in backhaul Source: ARC November 2011 13 © 1994 – 2011 Fieldbus Foundation
    14. 14. Our Future Direction: Helping Users Realize the Benefits November 201114 © 1994 – 2011 Fieldbus Foundation
    15. 15. Seeing Your Process in High Definition• Diagnostic Data from FOUNDATION Fieldbus Devices is Miles Ahead of Other Technologies• Incorporation of NAMUR NE 107 Diagnostics• Transmission of multiple process variables• User layer!• Physical layer diagnostics• Distinguishing Device Problems from Process Problems November 2011 15 © 1994 – 2011 Fieldbus Foundation
    16. 16. Managing Information• You know you are getting a true measurement, no digital to analog conversion• Persistent data storage: audit trail and reporting• Data is time-stamped• FOUNDATION Fieldbus devices can indicate data quality -- whether signals communicating setpoints, PVs, etc. have good, bad or uncertain quality.• Structured data and data quality means improved handling of failures when one does happen.• Failure is alarmed, handled by control algorithm November 2011 16 © 1994 – 2011 Fieldbus Foundation
    17. 17. A Single Environment for Information in Context & Data Quality November 201117 © 1994 – 2011 Fieldbus Foundation
    18. 18. Information Provided in Context• Allows data to be managed and Business System placed in context. Publish subscribe means that you only get the data you need when you need it. Production Manufacturing Management Work• Easier traceability and ISA S95 Transactions Operations Management Processes regulatory compliance. Sensors, Actuators and Logical Devices ISA S88 Real-Time• Seamless connectivity to the Control & Events operations management layer and enterprise layer. Source: ARC Advisory Group November 2011 18 © 1994 – 2011 Fieldbus Foundation
    19. 19. Optimizing People and Processes• Implementation of Predictive and Proactive Asset Management Strategies• More Effective Use of Shrinking Resources• Role Based Diagnostics• Alarms and Alerts November 201119 © 1994 – 2011 Fieldbus Foundation
    20. 20. Improved Integration of Functional Areas for ROM• Machinery health Monitoring• Safety Interlocks• Fire and Gas Detection Systems• Video Surveillance November 2011 20 © 1994 – 2011 Fieldbus Foundation
    21. 21. An Open Standard for Remote Operations Management• FOUNDATION Technology is a Standard. Standards Promote Choices• Administered by an Open Foundation, Vendor Neutral• Products are Tested and Registered• Standards Based Solutions are More Easily Replicated and Administered November 2011 21 © 1994 – 2011 Fieldbus Foundation
    22. 22. Potential Market• The worldwide market for SCADA rebounded in 2010 after weathering the effects of the global economic crisis.• SCADA market is growing faster than overall process automation market.• As demand for oil recovers and funding is freed up, project activity can be expected to return to robust levels in coming years, according ARC Advisory Group.• Growth factors include the continuing worldwide demand for additional energy from carbon-based fuels, the shifting of exploration and production locations to more remote and hostile environments, and end user requirements to link SCADA to information technology and business systems.• Frost and Sullivan estimates global SCADA market to be around $4.5 billion for all industries November 2011 22 © 1994 – 2011 Fieldbus Foundation
    23. 23. Application Examples: Oil and Gas Fields• Enables Integrated Operations Source: CAP Gemini November 2011 23 © 1994 – 2011 Fieldbus Foundation
    24. 24. Application Examples: Pipelines• API Monitoring, Custody Transfer Source: Moxa November 201124 © 1994 – 2011 Fieldbus Foundation
    25. 25. Application Examples: Tank Farms • Overfill Protection, Integration of Fire & Gas Detection November 201125 © 1994 – 2011 Fieldbus Foundation
    26. 26. Application Examples: Mining, Hydro Fracking • Coordination of widely dispersed automation assets • Oil sands • Concentrating data from multiple wellheads • Smaller environmental footprint November 201126 © 1994 – 2011 Fieldbus Foundation
    27. 27. Application Examples: Pharma• Faster Integration of Multiple Skid Mounted Mobile Units• Faster Commissioning• Easier Validation• Reduced Cost to Both End User and OEM FOUNDATION Fieldbus Instrumentation on a Skid Mounted Fermenter Source: PharmaManufacturing.com November 2011 27 © 1994 – 2011 Fieldbus Foundation
