Plans for open calls and offering by BonFIREFlorian Schreiner, FraunhoferInstitute FOKUSW: www.bonfire-project.euE: bonfire@bonfire-project.eu

Testbeds for Internet of Services Experimentation Type of project: Integrated Project Project coordinator: ATOS ORIGIN Project start date: 1st June 2010 Duration: 42 months Max EC contribution: 6.7 M€ (1.34 M€ for 2 open calls) Multi-site, cloud facility for applications, services and systems research experimentation, different underlying networks (std. internet, emulated, controlled) Access, control and monitor heterogeneous and virtualised compute, storage and networking resources!

“How to stimulate use and populate facilities” Identified and engaged target community Internet of Services Participated in Collaboration meeting Issued survey Analysed project needs Mature projects: support exploitation New projects: diversify testing http://www.surveymonkey.com/bonfire

Why BonFIRE Controlled deployment Monitoring Support Networks: Std. Int. Emultd. Contrld. Permanent and on-request infrastructure facilities

IoS can benefit from the BonFIRE facility Virtual Cloud Federator, VM managers and repositories, Service Deployment Descriptors, Service Life-cycle Manager, Service SLAs Monitoring VM QoS Monitoring, etc Extended FIRE framework: entry for Services projects with connection to some existing FIRE federation tools - LARGE SCALE testing - Address CROSS CUTTING issues (Network Effects & Services needs) - VALIDATION and OPTIMISATION through experimentation FIRE

How BonFIRE BonFIRE will launch 2 open calls (Feb 2011 & 2012) € 1,340,000 funding // 6-7 experiments Expected funding per experiment: ~ € 200,000 Duration: maximum 12 months Start dates: June 2011 / June 2012 External evaluators (FP7 rules) Proposer pack will be available: Proposal template Guide for proposers Better proposals Better facility Broader capabilities

Immediate target audiences FI IoS 3D &Media IoS Sec Initial target for M9 prototype IoT Research teams that need to do ‘research by experimentation’ from ‘services’ projects (universities, industries - Service providers, ISV – research centers) Service Engineering covering aspects such as service discovery, service management and lifecycle control, composition and aggregation of services, orchestration Virtualization techniques and distributed computing. IT Platforms: management services (SLAs, LM, etc) and QoS monitoring. Middleware technologies Extended enterprises. Service Architectures beyond SOA platforms with enhanced capabilities. EAI Enterprise Application Integration NoF

Three Scenarios – Service Experiments on top of three different Network Infrastructures Emulated Network Conditions Extended multi-site clouds connected through standard internet Controlled Network Conditions (federation) 2. Cloud scenario with emulated network (IBBT’s Virtual Wall) 3. Extended Cloud scenario with controlled network (implies federation) General Internet

Embeddedexperiments BonFIRE currentlyrunning 3 “embeddedexperiments” (AC 4) to test thefacilityforoperationbeforethe 2 open calls

Example of Embedded Experiments to prepare the Infrastructure PracticalexampleElasticity in Cloud-based web applications: The experiment tests in a comprehensive manner the whole functionality offered by BonFIRE: CRUD of VMs Complex network topologies Geographical dispersed allocation of resources, DNS, storage, etc. Measurement of the latency of BonFIRE as infrastructure provider in a wide variety of load scenarios. Resize or modify resources dynamically. Dynamic configuration of load balancers. The use of resources through federation with other cloud providers in some scenarios. Monitor API Improvementsto

Experiment: in more detail http/https KPI-collector Changes-generator DLG http://www.web-app.com KPI/ SLAs POLICIES/ LOAD TESTS TESTBED MANAGEMENT EXPERIMENT -MANAGER KPI LB … OPERATIONS WS WS WS CLOUD-MANAGER AS AS AS … MONITORING DB VM-REPOSITORY WEB-APP

Example of an ElasticityExperiment BonFIRE Site BonFIRE Site Load Balancer BonFIRE Monitor Load Generator BonFIRE Portal BonFIRE Broker

+ + = W: www.bonfire-project.eu E: bonfire@bonfire-project.eu

The 1st Open Callsopenssoon!! We estimate to fund about 4 experiments Total available funding in this call: 750K€ Estimated total Commission funding available per experiment: €150.000-200.000(max) Call identifier – BonFIRE-1- New experiments Language in which proposal should be submitted: English Date of close of call – 2nd March 2011 Time of close of call - 17:00 Brussels time Mail address for further information ict@ec.europa.eu
