    Focal Plane Engineering Challenges Focal Plane Engineering Challenges Presentation Transcript

    • FOCAL PLANE ENGINEERING CHALLENGES
    • Eric F. Schulte Focal Plane Engineering Consultant Indium Bump Bonding Hybrid Focal Plane Layout Mission Statement: FPA packaging Capitalize on 30+ years of R&D experience to save my and Stress Control Contact clients time and money by providing rapid, cost-effective, Metallization knowledgeable solutions to engineering challenges in: Compound - Design Semiconductor Plasma Etching - Materials Detector - Process Processing Resume and - Yield, throughput, and cost Specific Process - Reliability Experience Patents, of infrared, visible, and UV focal plane detectors, hybrid Publications, and assemblies, MEMS, and 3-D stacked structures. Awards Contact Eric: See last page
    • Indium Bump Bonding Is THE Lead-Free, High-density Interconnect Solution. High-yield in-house indium bump bonding capability requires integrated proficiency in the following process areas: - Under-bump metallization deposition – CTE matched, diffusion barrier, ohmic contact, metallurigically compatible. - Bump photolithography process – Thick photoresist for efficient clean liftoff, dimensional uniformity. - Indium deposition – Parameters optimized for minimum grain growth, confined directionality, lateral uniformity; in-situ pre-deposition surface clean. - Indium liftoff capability – special techniques to minimize damage to bumps, contain indium, eliminate cross- contamination. - Pre-hybridization oxidation removal – to ensure bump-to-bump adhesion, minimize force and slip. - Hybridization process – Appropriate selection of bonding equipment and options, vacuum tooling design, bonding parameters (thermo-compression vs. reflow, temperature profiles, compression profiles, scrubbing, slip prevention) - Post-hybrid measurement – gap, parallelism, alignment, mechanical integrity, electrical integrity. Correct choices for all of the above capabilities are essential to first-pass success Contact Eric: See last page
    • Hybrid Focal Plane Layout Design considerations for successful FPA layout: - Minimum die length and width for handling and stability during bonding. - Die flatness requirements. - Detector & ROIC die thickness tradeoffs. - ROIC bulk wafer resistivity and backside surface finish for IR transparency (for post-bond metrics) - ROIC and detector backside surface finish requirements for vacuum hold on bonder tooling. - Detector size vs. RIOC size - Saw lane dimensions, border widths, saw lane fiducials. - Circumferential guard devices and ground plane. - Single-sided or double-sided indium bump configuration. - Indium bump dimensions, shape, spacing, and bump count for optimal yield, minimum bond force, maximum mechanical integrity. - Under-bump metallization choices for optimal adhesion, conductivity, CTE matching, and diffusion resistance. - Hybridization fiducial design and location for optimal precision of alignment, parallelism, post-hybrid metrics. Correct choices for all of the above parameters are essential to first-pass success Contact Eric: See last page
    • FPA packaging and Stress Control Focal plane die flatness is essential for high performance, high yield, and reliability. - Not only must the materials stack be balanced in theory, but one must also take into account the process sequence and thermal excursions during processing to achieve a flat final product. Additionally, if the stack contains fragile layers (i.e. compound semiconductors) one must consider transient stresses during processing to avoid residual damage to those delicate components. - Thin film stress is the #1 contributor to FPA failure during production, testing, and in the field. o Incorrect choices of metallization, insulators, and substrate material can lead to bowing/warpage of the focal plane with subsequent failures in hybrid interconnect, semiconductor device responsivity, or loss of focus. - Adhesive failures are the #2 contributor to FPA failure. These failures are usually due to incorrect choice of adhesive and/or incorrect adhesive curing and/or inadequate surface preparation. o Some bondlines call for very rigid adhesives to withstand high stress, others require flexible adhesives to avoid thermal mismatch bowing. The trick is in knowing which to use in a particular situation. o Adhesive cure cycles are critical to proper performance of the bondline. The manufacturer’s recommended cure cycle is not necessarily the best choice in unique situations/unusual materials combinations. o Removal of organics, adsorbed water, and silicones is essential to reliable bondlines. Numerous wet and dry processes are available to give an ideal surface, depending on the materials involved and the process history. Correct choices for all of the above parameters are essential to first-pass success Contact Eric: See last page
    • Contact Metallization “Simple” metal contacts are ANYTHING BUT simple! Considerations include: - Selection of the proper metal(s) to achieve the optimum balance of: o Ohmic contact. o Thermal expansion match to substrate. o Series resistance. o Barrier to diffusion. o Metallurgical compatibility with underlying and overlying materials (reliability). - Selection of proper deposition technique (evaporation, sputtering, reactive sputtering) to control: o Static (as-deposited) stress. o Dynamic stress due to thermal expansion issues. o Step coverage (or not). o Damage to underlying semiconductor material due to deposition energetics. - Pre-deposition surface preparation to achieve: o Good adhesion. o Barrier-free ohmic contact. - Selection of patterning technique o Liftoff vs. etchback patterning. o Photoresist selection: positive vs. negative tone, viscosity. o Photoresist spin and bake parameters. o Photoresist sidewall profile for optimal liftoff. o Critical dimension monitoring and control. Correct choices for all of the above parameters are essential to first-pass success Contact Eric: See last page
    • Compound Semiconductor Plasma Etching Eric Schulte was the first to develop reactive ion etching (RIE) of HgCdTe for infrared detectors, and the first to successfully fabricate spec. HgCdTe focal plane arrays using the technique. He received the prestigious IRIS (InfraRed Industry Symposium ) “Best Paper Award” in 1993 for his pioneering work in the field. Key to the success of this development was finding the correct etch chemistry and plasma parameters which could produce a high etch rate with controllable sidewall angle, good surface morphology, and minimal damage to the remaining HgCdTe material. This process is now routinely used in the HgCdTe IR detector industry where high aspect ratio etching is required. Contact Eric: See last page
    • Device Processing Through the years, Eric has led development projects in virtually every aspect of HgCdTe, InSb, and Si device processing including: - Starting wafer specification, measurement, and cleanup. - Photolithography: resists, spin, spray, bake, exposure, development, profile control, liftoff, strip. - Metal deposition: Thermal evap, e-beam evap, sputtering, reactive sputtering; adhesion, stress, conductivity. - Insulator deposition: Thermal evap, e-beam evap, sputtering, reactive sputtering, CVD; adhesion, stress, dielectric strength. - Dry etching: Semiconductors, metals, insulators, plasma surface prep., resist compatibility, damage control and mitigation. - Wet etching and surface preparation: Static, agitated, manual spray, automated spray, spin, surfactants, rinsing. - Implant and diffusion: species, profiles, characterization, stability, effect on performance. - Annealing: open-tube and closed-tube, vacuum, vapor, inter-diffusion. - Yield improvement: Test data analysis, physical analysis, correlation of performance defects to physical defects to processing parameters, techniques, contamination, particulates, handling, etc. - Cost and thruput improvement: Creative application of equipment and processing techniques to simplify and integrate processes, reduce touch labor, reduce queue dwell, improve process flow. - Reliability: failure analysis, performance degradation tracking, thermal cycling, vibration testing, bond strength measurement, accelerated shelf life testing, stress analysis and mitigation. Contact Eric: See last page
    • RESUME OF ERIC F. SCHULTE FOCAL PLANE ENGINEERING CONSULTANT Permanent residence: Santa Barbara, Ca. Contact Eric: See last page EDUCATION BSEE, Michigan Technological University, 1970 MSEngSci, University of Texas at Dallas, 1982 2004-Present (as a part-time consultant) - U.S. Army Night Vision Laboratories – Project to develop small-pitch indium bump deposition and hybridization techniques for high-density focal plane arrays. (Ongoing) - Lockheed-Martin Santa Barbara FocalPlane – Advanced process development in hybridization, array fabrication, backend processing, and packaging. (Ongoing) - Teledyne Imaging Systems – 2-color HgCdTe detector processing, yield, and performance, with concentration on contact metallization, stress control, passivation, dry etch, and hybridization. (Ongoing) - Judson Technologies – Technical assistance in all aspects of large IR focal plane production: detector processing, hybridization, packaging (Ongoing) - NASA GSFC Microshutter Project – Indium bump bonding capability setup, thin film stress management, MEMS process development, array handling and packaging design. (Completed in 2006) 1985-2004 (retired) - Raytheon Vision Systems, Goleta, Ca. Senior Principal Engineer, 2nd Gen Array Production Dept., responsible for conception, development, and implementation of novel processing techniques and equipment for the manufacture of infrared detectors. Numerous key developments in device design, semiconductor processing, equipment design, hybridization, process monitoring and control, failure analysis, and product reliability have resulted in 9 US patents, as well as company and industry awards.
