    Adventures in pH Control Adventures in pH Control Presentation Transcript

    • Adventures in pH ControlGreg McMillan CDI Process & IndustrialDave Joseph Rosemount Analytical
    • Photography & Video Recording Policy Photography and audio/video recording is not permitted in any sessions or in the exhibition areas without press credentials or written permission from the Emerson Exchange Board of Directors. Inquiries should be directed to: EmersonExchange@Emerson.com Thank you.
    • Presenters Greg McMillanPrincipal ConsultantEmail: Greg.McMillan@Emerson.com33 years Monsanto-Solutia Fellow2 years WU Adjunct Professor10 years DeltaV R&D ContractorBS Engineering PhysicsMS Control Theory Dave JosephSr. Industry ManagerEmail: Dave.joseph@emerson.com24 years with Rosemount AnalyticalBS and MS in Chemical EngineeringMember AIChE
    • Key Benefits of Course  Recognize the opportunity/challenges of pH control  Learn about modeling and control options  Optimize hardware implementation  Understand the root causes of poor performance  Prioritize improvements based on cost, time, and goal  Gather insights for applications and solutions 4
    • Section 1: Measuring pH  Brief theory of pH  Inside a pH sensor  The Smart pH sensor  Diagnostics 5
    • Top Ten Signs of a Rough pH Startup  Food is burning in the operators’ kitchen  Only loop mode configured is manual  Operator puts his fist through the screen  You trip over a pile of used pH electrodes  Technicians ask: “what is a positioner?”  Technicians stick electrodes up your nose  Environmental engineer is wearing a mask  Plant manager leaves the country  Lawyers pull the plugs on the consoles  President is on the phone holding for you 6
    • The definition of pH pH is the unit of measurement for determining the acidity or alkalinity of a solution. The mathematical definition of pH is the negative logarithm of the molar hydrogen ion concentration, pH = - log([H+]) pH is measured by various different sensors, H2O most common and economical is the glass H+ OH- OH- H+ electrode/silver reference system. pH measurement requires periodic maintenance to maintain accuracy.
    • pH Scale vs Moles/Liter IonConcentration pH Hydrogen Ion [H+] Hydroxyl Ion [OH-] 0 Acidic 1.0 0.00000000000001 1 0.1 0.0000000000001 2 0.01 0.000000000001 3 0.001 0.00000000001 4 0.0001 0.0000000001 5 0.00001 0.000000001 6 0.000001 0.00000001 7 Neutral 0.0000001 0.0000001 8 0.00000001 0.000001 9 0.000000001 0.00001 10 0.0000000001 0.0001 11 0.00000000001 0.001 12 0.000000000001 0.01 13 0.0000000000001 0.1 14 Basic 0.00000000000001 1.0
    • pH Values of Acids and Bases 14 4.0 % Sodium Hydroxide 12 0.04% Sodium Hydroxide 10 Milk of Magnesia 8 0.84% Sodium BicarbonatepH Water @ 25ºC 6 0.00001% Sulfuric Acid 4 0.0001% Hydrochloric Acid 0.01% Sulfuric Acid 2 0.1% Hydrochloric Acid 4.9% Sulfuric Acid 0 1E00 1E-01 1E-02 1E-03 1E-04 1E-05 1E-06 1E-07 1E-08 1E-09 1E-10 1E-11 1E-12 1E-13 1E-14 Hydrogen Ion Concentration (Mole/Liter)
    • What is pH? – technical stuff  pH = - log([H+])  Kw = [H+]*[OH-] = 1.0x10-14 at 25ºC  pH + pOH = pKw  pH is measured using the Nernst equation  E(mV) = Ex + 2.3(RT/F)*log aH+  ~ Ex – (S)*pH in simple form  Where Ex = calibration constant  2.3(RT/F) ~ slope (S) in mV/pH units  aH+ = activity of hydrogen ion ~ [H+]
    • Theoretical Response of apH Sensor (25ºC) 500 400 300 Slope of 59.16 mV/pH Unit 200 100 0 mV-100-200 Zero mV at 7 pH-300-400 pH-500 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
    • pH Sensor Basics•The pH electrodeproduces a potential(in mV’s) • The referenceproportional to the electrode potentialpH of the solution. must remain stable regardless of process or time effects Glass Body Ag/AgCl • Internal element- AgAgCl Internal Shield Wire • Electrolyte fill - KCl/AgCl • Liquid Junctions pH Sensitive Fill Glass Solution 12
    • Inside the pH Glass Membrane... Alkali Metal Ions Anionic Sites Glass Matrix (unaffected) M M M M S M M Core Glass S S S M Leached Layer + M H Inner Zone (not to scale) + + H H + + + H + H H H Outer Zone + + H HLeached LayerDissolving Hydrogen Ions 13
    • The reference electrode The Reference Cell maintains a stable potential regardless of the process pH or changes in the activities of other ions in AgCl/KCl solution. Ag/AgCl Fill Internal Solution Wire The Liquid Junction completes the electrical circuit between the pH measuring electrode and the reference cell via the process solution. Liquid Junction 14pH17
    • The sum of all potentials… Assuming a preamp with low leakage current, the pH sensor Ex = Eoutside of glass (in process solution) - Einside of glass (in glass fill solution) - Emeasurement wire (in glass fill solution) + Ereference wire (in reference Ag/KCL solution) + Ejunction potential (sum of all interface potentials)  Glass fill solution typically formulated to cancel out effects so that 7 pH is 0 mV at any temperature.
    • Double Junction Combination pH Electrode - Circuit Diagram Em W R3 Er W R4 solution ground silver-silver chlorideDehydration, loss of active sites, internal electrodechemical attack, and premature E4 aging reduces efficiency and secondmakes sensor dramatically slow W R5 junction potassium chloride (KCl) electrolyte Gel layer is used as a term in salt bridge between junctions for the glass surface that has water molecules primary R6 W junction inner E5 gel silver-silver chloride layer internal electrode E3 outer W R2 gel pH fill solution layer E2 Process ions may Measurement R1 W migrate into porous becomes slow Ii reference junction if glass gets coated E1 while electrolyte ions Process Fluid migrate out W W R10 W W R9 R7 R8 High acid or base concentrations can affect glass gel layer and reference junction potential Increase in noise or decrease in span or efficiency is indicative of glass electrode problem Shift or drift in pH measurement is normally associated with reference electrode problem 16
    • Life Depends On Process Conditions Months >100% increase in life from new glass designs for high temperatures 25ºC 50ºC 75ºC 100ºC Process Temperature  High pH conditions decrease glass life at any temperature  Degraded accuracy and response time is also common  Leads to unreliable feedforward control 17
    • New Glass preserves response time After 120 hours exposure at 140ºC 200 mV 150 New Glass 100 Other 50 minutes 0 0 50 100 150 200 Glass electrodes get slow as they age High temperatures cause accelerated aging New glass formulations can resist this effect 18
    • Review: pH Measurement loop Analyzer (not part of the sensor) 4. Solution ground 2. Reference electrode Liquid junction 1. Glass electrode 3.Temperature element
    • What is a SMART sensor?  SMART sensors store calibration data on an embedded chip.  SMART sensors record the initial calibration data of the sensor and all data from the last 5 calibrations  They allow trending the performance variables of the sensor to determine how healthy the sensor is and what work is needed on it before venturing out into the field.  Trended diagnostics enable Plantweb users to take action before the reading is compromised without any intimate knowledge of how a sensor works or what conditions the sensor may have been exposed to.  Results are reduced maintenance and increased measurement uptime.
    • SMART loop: instrument-cable-sensor 4-wire Models 56 and 1056 are smart-enabled 2-wire, FF Model 1066 is smart-enabled Smart pH sensorused sensor used OR in “Smart” mode VP8 (or cable) Model 6081pH Smart-enabled Wireless Transmitter
    • SMART pH Sensors  Plug and Play - Factory pre-calibrated - Calibrate in lab instead of in field - Can restore to factory values  SMART technology - Automatically trend diagnostics - Capture intermittent sensor problems - SMART signal superimposed on mV signal (like HART)  Simple Migration path - Compatible with previous analyzers - Compatible with previous sensors
    • Calibration history Advanced diagnostics  Last 5 calibration data sets for troubleshooting
    • Calibration data set – diagnostics Current readings! Calibration Data Time stamp between calibrations Calibration method Slope Offset Temperature at the time of calibration Glass impedance Reference impedance
    • Calibration History
    • Plug & Play Convenience Conventional approach: Field calibration with buffers SMART approach: Cal in the lab, Plug & Play in the fieldConventional sensor Field Equipment Smart Sensor Field Equipment
    • Siemens Water Technologies, WI • Application: spent caustic, pH ~10-12 • pH sensor: 3500HTVP and 396PVP • User comment: “The SMART is somewhat fool proof. I do like the backward compatibility with it, because initially we had the wrong probes hooked to the wrong boards, and everything still worked. The SMART features obviously didnt, but the probes themselves all functioned fine. “
    • Key Indicators of Sensor PerformancePlantweb pH measurementsprovide a complete view ofthe operational parameters: pH reading raw sensor output temperature reference impedance Glass impedance RTD resistance
    • Diagnostics - Broken Glass 3K 150 M 0-5   Broken Glass! Reference Electrode Glass Solution Electrode GroundBroken Glass Fault  pH Glass electrode normally has high impedance of 50-500 Megohm  Recommended setting of 10 Megohm will detect even hairline cracks  Glass can be cracked at the tip or further back inside the sensor (and not easily visible) 29
    • Diagnostics - Coated Sensor 3K 40k 150 M   Coated Sensor! Reference Electrode Glass Solution Electrode GroundCoated Sensor Fault (Ref Z Too High)  pH Reference electrode normally has low impedance of 1-10 KilOhm  Reference coating slowly builds up around the junction  Setting of 20 KilOhm should not generally cause false alarms 30
    • Diagnostics - Non-Immersed Sensor 60K 1500 M   Dry Sensor! Reference Electrode Glass Solution Electrode Ground Dry Sensor Fault (Glass Z Too High)  pH Glass electrode normally has impedance of 50-500 Megohm  When sensor is dry there is no continuity between the electrode(s) and the solution ground so impedance reading is very high  Recommended setting of 1000 Megohm will not cause false alarms 31
    • More Advanced Diagnostics  pH parameters slope, reference offset, glass, and reference impedances change little over bulk of operational life.  When parameters start to change, they indicate that more frequent calibrations will be necessary.  Diagnostics are at their most powerful when they can be compared to the original properties of the sensor.  Example: a pH slope of 54 may not indicate a problem, but a sudden drop in slope from 58 to 54 may indicate a 9 month old sensor will not last much longer.  Trending the electrode slope, reference offset, and reference impedance will show the first sign of problems.
    • SMART and Trending DiagnosticsSMART pH sensorsautomatically record their ^mV/ pH 59 58.9 58.8 Max pH error per calibration cycle Change in Slope 58.7 58.6 58.5 58.4 58.3 58.2 58.1 58 57.9 57.8 57.7 57.6 57.5 57.4 57.3initial conditions and the ^pH 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6 1.7 0.1 # 0.02% # 0.03% # 0.05% # 0.07% # 0.09% # 0.10% # 0.12% # 0.14% # 0.15% # 0.17% # 0.19% # 0.21% # 0.23% # 0.24% # 0.26% # 0.28% # 0.30% 0.2 # 0.03% # 0.07% # 0.10% # 0.14% # 0.17% # 0.21% # 0.24% # 0.27% # 0.31% # 0.34% # 0.38% # 0.42% # 0.45% # 0.49% # 0.52% # 0.56% # 0.59% 0.3 # 0.05% # 0.10% # 0.15% # 0.20% # 0.26% # 0.31% # 0.36% # 0.41% # 0.46% # 0.52% # 0.57% # 0.62% # 0.68% # 0.73% # 0.78% # 0.84% # 0.89% 0.4 # 0.07% # 0.14% # 0.20% # 0.27% # 0.34% # 0.41% # 0.48% # 0.55% # 0.62% # 0.69% # 0.76% # 0.83% # 0.90% # 0.97% # 1.04% # 1.11% # 1.19% 0.5 # 0.08% # 0.17% # 0.26% # 0.34% # 0.43% # 0.51% # 0.60% # 0.69% # 0.77% # 0.86% # 0.95% # 1.04% # 1.13% # 1.22% # 1.30% # 1.39% # 1.48%last 5 calibrations to make 0.6 # 0.10% # 0.20% # 0.31% # 0.41% # 0.51% # 0.62% # 0.72% # 0.82% # 0.93% # 1.03% # 1.14% # 1.25% # 1.35% # 1.46% # 1.57% # 1.67% # 1.78% 0.7 # 0.12% # 0.24% # 0.36% # 0.48% # 0.60% # 0.72% # 0.84% # 0.96% # 1.08% # 1.21% # 1.33% # 1.45% # 1.58% # 1.70% # 1.83% # 1.95% # 2.08% 0.8 # 0.14% # 0.27% # 0.41% # 0.55% # 0.68% # 0.82% # 0.96% # 1.10% # 1.24% # 1.38% # 1.52% # 1.66% # 1.80% # 1.94% # 2.09% # 2.23% # 2.37% 0.9 # 0.15% # 0.31% # 0.46% # 0.61% # 0.77% # 0.92% # 1.08% # 1.24% # 1.39% # 1.55% # 1.71% # 1.87% # 2.03% # 2.19% # 2.35% # 2.51% # 2.67% 1 # 0.17% # 0.34% # 0.51% # 0.68% # 0.85% # 1.03% # 1.20% # 1.37% # 1.55% # 1.72% # 1.90% # 2.08% # 2.25% # 2.43% # 2.61% # 2.79% # 2.97% 1.1 # 0.19% # 0.37% # 0.56% # 0.75% # 0.94% # 1.13% # 1.32% # 1.51% # 1.70% # 1.90% # 2.09% # 2.28% # 2.48% # 2.67% # 2.87% # 3.07% # 3.26%trending easier. 1.2 1.3 1.4 1.5 1.6 # 0.20% # 0.22% # 0.24% # 0.25% # 0.27% # # # # # 0.41% # 0.61% 0.44% # 0.66% 0.48% # 0.72% 0.51% # 0.77% 0.54% # 0.82% # # # # # 0.82% 0.89% 0.96% 1.02% 1.09% # # # # # 1.03% 1.11% 1.20% 1.28% 1.37% # # # # # 1.23% 1.34% 1.44% 1.54% 1.64% # # # # # 1.44% 1.56% 1.68% 1.80% 1.92% # # # # # 1.65% 1.79% 1.92% 2.06% 2.20% # # # # # 1.86% 2.01% 2.17% 2.32% 2.48% # # # # # Beginning Slope - Ending Slope = 2.07% 2.24% 2.41% 2.59% # # # # 2.28% 2.47% Slope Change 2.66% 2.85% # # # # 2.49% 2.70% 2.91% 3.11% # # # # Slope change * Max change in pH = 2.76% # 3.04% # 3.32% # 2.70% 2.93% 3.15% 3.38% 3.60% # # # # # 2.92% 3.16% 3.40% 3.65% 3.89% # # # # # 3.13% 3.39% 3.65% 3.91% 4.17% # # # # # 3.34% 3.62% 3.90% 4.18% 4.46% # # # # # 3.56% 3.86% 4.15% 4.45% 4.75%• Predictive maintenance 1.7 # 0.29% # 0.58% # 0.87% # 1.16% # 1.45% # 1.75% # 2.04% # 2.34% # 2.63% # 2.93% # 3.23% # 3.53% # 3.83% # 4.13% # 4.43% # 4.74% # 5.04% 1.8 # 0.31% # 0.61% # 0.92% # 1.23% # 1.54% # 1.85% # 2.16% # 2.47% # 2.79% # 3.10% # 3.42% # 3.74% # 4.06% # 4.38% # 4.70% # 5.02% # 5.34% 1.9 # 0.32% # 0.65% # 0.97% # 1.30% # 1.62% # 1.95% # 2.28% # 2.61% # 2.94% # 3.28% Max mV deviation per # 3.61% # 3.94% # 4.28% # 4.62% # 4.96% # 5.30% # 5.64% 2 # 0.34% # 0.68% # 1.02% # 1.37% # 1.71% # 2.05% # 2.40% # 2.75% # 3.10% # 3.45% # 3.80% # 4.15% # 4.51% # 4.86% # 5.22% # 5.57% # 5.93% 2.1 # 0.36% # 0.71% # 1.07% # 1.43% # 1.79% # 2.16% # 2.52% # 2.89% # 3.25% # 3.62% calibration cycle # 3.99% # 4.36% # 4.73% # 5.10% # 5.48% # 5.85% # 6.23% 2.2 # 0.37% # 0.75% # 1.12% # 1.50% # 1.88% # 2.26% # 2.64% # 3.02% # 3.41% # 3.79% # 4.18% # 4.57% # 4.96% # 5.35% # 5.74% # 6.13% # 6.53% 2.3 # 0.39% # 0.78% # 1.18% # 1.57% # 1.97% # 2.36% # 2.76% # 3.16% # 3.56% # (Max mV deviation / Beginning 3.97% # 4.37% # 4.78% # 5.18% # 5.59% # 6.00% # 6.41% # 6.82%with reference Impedance 2.4 2.5 2.6 2.7 2.8 # 0.41% # 0.42% # 0.44% # 0.46% # 0.48% # # # # # 0.82% # 1.23% 0.85% # 1.28% 0.88% # 1.33% 0.92% # 1.38% 0.95% # 1.43% # # # # # 1.64% 1.71% 1.77% 1.84% 1.91% # # # # # 2.05% 2.14% 2.22% 2.31% 2.39% # # # # # 2.47% 2.57% 2.67% 2.77% 2.88% # # # # # 2.88% 3.00% 3.12% 3.24% 3.36% # # # # # 3.30% 3.44% 3.57% 3.71% 3.85% # # # # # 3.72% 3.87% 4.03% 4.18% 4.34% # # # # # 4.14% 4.31% 4.48% 4.66% 4.83% # # # # # 4.56% 4.75% 4.94% 5.13% 5.32% # # # # # 4.98% Slope) = Max pH error 5.19% 5.40% 5.61% 5.81% # # # # # 5.41% 5.63% 5.86% 6.08% 6.31% # # # # # 5.83% 6.08% 6.32% 6.56% 6.81% # # # # # 6.26% 6.52% 6.78% 7.04% 7.30% # # # # # 6.69% 6.97% 7.25% 7.53% 7.80% # # # # # 7.12% 7.42% 7.71% 8.01% 8.31%trending 2.9 # 0.49% # 0.99% # 1.48% # 1.98% # 2.48% # 2.98% # 3.48% # 3.99% # 4.49% # 5.00% # 5.51% # 6.02% # 6.53% # 7.05% # 7.57% # 8.08% # 8.60% 3 # 0.51% # 1.02% # 1.53% # 2.05% # 2.56% # 3.08% # 3.60% # 4.12% # 4.65% # 5.17% # 5.70% # 6.23% # 6.76% # 7.29% # 7.83% # 8.36% # 8.90% 3.1 # 0.53% # 1.05% # 1.58% # 2.12% # 2.65% # 3.18% # 3.72% # 4.26% # 4.80% # 5.34% # 5.89% # 6.44% # 6.98% # 7.53% # 8.09% # 8.64% # 9.20% 3.2 # 0.54% # 1.09% # 1.64% # 2.18% # 2.74% # 3.29% # 3.84% # 4.40% # 4.96% # 5.52% # 6.08% # 6.64% # 7.21% # 7.78% # 8.35% # 8.92% # 9.49% 3.3 # 0.56% # 1.12% # 1.69% # 2.25% # 2.82% # 3.39% # 3.96% # 4.54% # 5.11% # 5.69% # 6.27% # 6.85% # 7.44% # 8.02% # 8.61% # 9.20% # 9.79%• Determine optimum 3.4 # 0.58% # 1.16% # 1.74% # 2.32% # 2.91% # 3.49% # 4.08% # 4.67% # 5.27% # 5.86% # 6.46% # 7.06% # 7.66% # 8.26% # 8.87% # 9.48% # 10.09% 3.5 # 0.59% # 1.19% # 1.79% # 2.39% # 2.99% # 3.60% # 4.20% # 4.81% # 5.42% # 59mV/pH - 55mV/pH = 4mV/pH * 6pH = 6.03% # 6.65% # 7.27% # 7.89% # 8.51% # 9.13% # 9.76% # 10.38% 3.6 # 0.61% # 1.22% # 1.84% # 2.46% # 3.08% # 3.70% # 4.32% # 4.95% # 5.58% # 6.21% # 6.84% # 7.47% # 8.11% # 8.75% # 9.39% # 10.03% # 10.68% 3.7 # 0.63% # 1.26% # 1.89% # 2.53% # 3.16% # 3.80% # 4.44% # 5.09% # 5.73% # 6.38% 24mV / 59mV/pH = 0.41pH # 7.03% # 7.68% # 8.34% # 8.99% # 9.65% # 10.31% # 10.98% 3.8 # 0.65% # 1.29% # 1.94% # 2.59% # 3.25% # 3.90% # 4.56% # 5.22% # 5.89% # 6.55% # 7.22% # 7.89% # 8.56% # 9.24% # 9.91% # 10.59% # 11.27% 3.9 # 0.66% # 1.33% # 1.99% # 2.66% # 3.33% # 4.01% # 4.68% # 5.36% # 6.04% # 6.72% # 7.41% # 8.10% # 8.79% # 9.48% # 10.17% # 10.87% # 11.57% 4 # 0.68% # 1.36% # 2.04% # 2.73% # 3.42% # 4.11% # 4.80% # 5.50% # 6.20% # 6.90% # 7.60% # 8.30% # 9.01% # 9.72% # 10.43% # 11.15% # 11.87%calibration frequency and Change in Process = 1% = 2% = 3% Beginning Slope - Ending Slope = Slope Change = 4% = 5%predict probe life with pH Slope Change * Maximum Change in Process pH = Maximum pH Deviation For a typical application ranging from 4 toslope trending 10 pH the error from assuming 59 slope instead of 55 could be 0.41 pH units >>> need to recalibrate
    • Using Diagnostics Instruments ship with the diagnostics turned off When enabled, default setpoints will generally be ok Few false alarms when correctly configured Some problems may not be detectable with online diagnostics When in doubt, check with buffers
    • Section 2: Modeling and Control  Virtual plant and embedded process models  Online identification of titration curve  Minimization of project capital cost  Cascade pH control  Batch pH control  Linear reagent demand control  Elimination of split range control  Model predictive control 35
    • Embedded Process Model for pH 36
    • Titration Curves can Vary Weak Acid and Strong Base Strong Acid and Weak Base pka = 10 pka = 4 Slope moderated near each pKa Weak Acid and Weak Base Multiple Weak Acids and Weak Bases pKa and curve change with pka = 10 temperature! pka = 9 pka = 5 pka = 4 pka = 3 37
    • Nonlinearity can cost big moneypH measurement error may look smaller on the flatter portion of a titrationcurve but the associated reagent delivery error is larger 10 pH 4 Reagent to Feed Reagent Flow Ratio Optimum Savings Original set point set point Oscillations could be due to non-ideal mixing, control valve stick-slip. or pressure fluctuations 38
    • Titration Curve Matched to Plant pH Slope 39
    • Modeled pH Control System AY signal pH set point characterizer 1-3 Signal characterizers linearize loop via reagent demand control AC 1-1 LC LT 1-5 1-5 signal splitter characterizer AY Feed 1-4 AY 1-2 NaOH Acid To other Tank middle signal selector FT FT Tank 1-1 1-2 AY 1-1 AT AT AT Eductors 1-1 1-2 1-3 Static Mixer From other Tank To other Tank Downstream system 40
    • Conventional vs. Reagent Demand One of many spikes of recirculation pH spikes from stick-slip of water valve Influent pH Tank 1 pH for Reagent Demand Control Tank 1 pH for Conventional pH Control Start of Step 4 (Slow Rinses) Start of Step 2 (Regeneration) 41
    • Traditional System for Minimum VariabilityThe period of oscillation (4 x process dead time) and filter time(process residence time) is proportional to volume. To prevent Reagentresonance of oscillations, different vessel volumes are used. Major overlooked Reagent Reagent problem is reagent Deliver delay from dip tube design FeedSmall first tank provides a faster responseand oscillation that is more effectively filtered Big footprintby the larger tanks downstream and high cost! 42
    • Traditional System forMinimum Reagent Use Reagent The period of oscillation (total loop dead time) must differ by more than factor of 5 to prevent resonance (amplification of oscillations) Feed Reagent Reagent Big footprint and high cost! The large first tank offers more cross neutralization of influents 43
    • Tight pH Control withMinimum Capital IL#1 – Interlock that prevents back fill of reagent piping when control valve closes IL#2 – Interlock that shuts off effluent flow until vessel pH is projected to be within control band Eductor High Recirculation Flow Reagent Any Old Tank Signal Characterizer LC LT 1-3 1-3 *IL#2 f(x) FT 1-1Effluent AC 1-1 FC 1-2 AT 1-1 *IL#1 Influent FT 1-2 10 to 20 pipe diameters 44
    • Linear Reagent Demand Control Signal characterizer converts PV and SP from pH to % Reagent Demand – PV is abscissa of the titration curve scaled 0 to 100% reagent demand – Piecewise segment fit normally used to go from ordinate to abscissa of curve – Fieldbus block offers 21 custom space X,Y pairs (X is pH and Y is % demand) – Closer spacing of X,Y pairs in control region provides most needed compensation – If neural network or polynomial fit used, beware of bumps and wild extrapolation Special configuration is needed to provide operations with interface to: – See loop PV in pH and signal to final element – Enter loop SP in pH – Change mode to manual and change manual output Set point on steep part of curve shows biggest improvements from: – Reduction in limit cycle amplitude seen from pH nonlinearity – Decrease in limit cycle frequency from final element resolution (e.g. stick-slip) – Decrease in crossing of split range point – Reduced reaction to measurement noise – Shorter startup time (loop sees real distance to set point and is not detuned) – Simplified tuning (process gain no longer depends upon titration curve slope) – Restored process time constant (slower pH excursion from disturbance) 45
    • Cascade Control to ReduceDownstream Offset Linear Reagent Demand Controller Flow Feedforward FT 1-1 RSP FC AC Trim of Inline 1-1 Sum Set Point 1-1 Reagent AT f(x) Filter f(x) 1-1 FT Static Mixer PV signal 1-2 SP signal Characterizer characterizer Feed Coriolis Mass 10 to 20 Flow Meter pipe diameters M AC 1-2 Any Old Tank Enhanced PID Controller AT 1-2 46
    • Full Throttle Batch pH Control Batch pH End Point Predicted pH Reagent Cutoff Sum Rate of Projected Past Change DpH New pH DpH DpH/Dt Sub Div Mul Old pH Delay Dt Total System Dead Time Batch Reactor Filter AT 1-1 10 to 20 pipe diameters Section 3-5 in New Directions in Bioprocess Modeling and Control shows how this strategy is used as a head start for a PID controller 47
    • Linear Reagent Demand Batch pH Control FQ FT Secondary pH 1-1 1-1 PI Controller AC FC 1-1 1-1Influent #1 AT Online Curve 1-1 Identification Static Mixer 10 to 20 pipe FT diameters 1-2 Influent #2 AC f(x) 1-1 Batch Reactor Signal Master Reagent Demand Characterizer Adaptive PID Controller AT Uses Online 1-1 Titration Curve 10 to 20 Reduces injection and mixing delays and enables some cross pipe neutralization of swings between acidic and basic influent. It is diameters suitable for continuous control as well as fed-batch operation. 48
    • Conventional Fine andCoarse Valve Control Large Small (Coarse) (Fine) ZC CV 1-1 Integral only Controller (CV is Implied Fine Control Valve Position) Neutralizer AC ZC speed of response must 1-1 be slow and tuning is difficult Must add feedforward for fast and large influent disturbance PID Controller AT 1-1 49
    • Advanced Fine andCoarse Valve Control manipulated variables Small (Fine) Large (Coarse) MPC Reagent Valve SP Reagent Valve SP controlled variable Small (Fine) null Reagent Valve SP controlled variable Neutralizer pH PV Model Predictive Controller (MPC) setup for rapid simultaneous throttling of a fine and coarse control valves that addresses both the rangeability and resolution issues. This MPC can possibly reduce the number of stages of neutralization needed 50
    • Key Points More so than for any other loop, it is important to reduce dead time for pH control because it reduces the effect of the nonlinearity Filter the feedforward signal to remove noise and make sure the corrective action does not arrive too soon and cause inverse response The effectiveness of feedforward control greatly depends upon the ability to eliminate reagent delivery delays If there is a reproducible influent flow measurement use flow feedforward, otherwise use a head start to initialize the reagent flow for startup The reliability and error of a pH feedforward is unacceptable if the influent or feed pH measurement is on the extremities of the titration curve Use a Coriolis or magnetic flow meter for reagent flow control Every reagent valve must have a digital valve controller (digital positioner) Except for fast inline buffered systems, use cascade control of pH to reagent flow to compensate for pressure upsets and enable flow feedforward Linear reagent demand can restore the time constant and capture the investment in well mixed vessels, provide a unity gain for the process variable, simply and improve controller tuning, suppress oscillations and noise on the steep part of the curve, and speed up startup and recovery from the flat part of the curve 51
    • Key Points Changes in the process dynamics identified online can be used to predict and analyze changes in the influent, reagent, valve, and sensor New adaptive controllers will remember changes in the process model as a function of operating point and preemptively schedule controller tuning Use inline pH control, mass flow meters, linear control valves, and dynamic compensation to automatically identify the titration curve online Use gain scheduling or signal characterization based on the titration curve to free up an adaptive controller to find the changes in the curve Batch samples should be taken only after all the reagent in the pipeline and dip tube has drained into the batch and been thoroughly mixed Use a wide open reagent valve that is shut or turned over to pH loop based on a predicted pH from ramp rate and dead time to provide the fastest pH batch/startup Use online titration curve identification and linear reagent demand pH control for extremely variable and sharp or steep titration curve Use an online dynamic pH estimator to provide a much faster, smoother, and more reliable pH value, if the open loop dead time and time constant are known and there are feed and reagent Coriolis mass flow meters Use linear reagent demand model predictive control for interacting systems and constraint or valve position control 52
    • Section 3: Practical Considerations  Causes and Effects of Drift  Common Problems with Titration Curves  Effect of Measurement Selection and Installation  Options to improve accuracy and maintenance  Effect of piping design, vessel type, and mixing pattern  Implications of oversized and split ranged valves  Online Troubleshooting 53
    • Drift  Reference Liquid Junction is a Porous “Membrane” – Diffusion Rate Must Remain Constant to Eliminate Drift – Coating, Pressure (flow) changes, chemical reactions interfere Concentration Gradient Through Reference Junction (Membrane) H2O in KCl out Other Process Constituents in Inside Sensor Process Reference Gradient Through Reference When Coated Gradient Through Reference When CleanDifference in the Gradient between Clean and Coated Causes Offset
    • High Today may be Low Tomorrow  Calibration adjustments chase short term effects such as: – Imperfect mixing – Ion migration into reference junction – Temperature shifts – Different glass surface conditions – Fluid streaming potentials… A B A B A pH B timeWith just two electrodes, sometimes there are more questions than answers. 55
    • Drift effects on Feedforward control  Normal Condition: inlet pH is 5 and setpoint is 7  Sensor drifts to 4.5 causes overfeed of reagent and outlet to be pH 9 10 pH Feedforward pH Error 8 pH Set Point Influent pH 6 Sensor Drift 4 Reagent to Feed Flow Ratio Flow feedforward (ratio control The error in a pH feedforward calculation of reagent to influent flow) works increases for a given sensor error as the well for vessel pH control if there slope of the curve decreases. This result are reliable flow measurements combined with an increased likelihood of with sufficient rangeability errors at low and high pH means feedforward could do more harm than good when going from the curve’s extremes to the neutral region. Feedforward Reagent Error Feedforward control always requires pH feedback correction unless the set point is on the flat part of the curve, use Coriolis mass flow meters and have constant influent and reagent concentrations 56
    • Common Problems withTitration Curves Insufficient number of data points were generated near the equivalence point Starting pH (influent pH) data were not plotted for all operating conditions Curve doesn’t cover the whole operating range and control system overshoot No separate curve that zooms in to show the curvature in the control region No separate curve for each different split ranged reagent Sequence of the different split ranged reagents was not analyzed Back mixing of different split ranged reagents was not considered Overshoot and oscillation at the split ranged point was not included Sample or reagent solids dissolution time effect was not quantified Sample or reagent gaseous dissolution time and escape was not quantified Sample volume was not specified Sample time was not specified Reagent concentration was not specified Sample temperature during titration was different than the process temperature Sample was contaminated by absorption of carbon dioxide from the air Sample was contaminated by absorption of ions from the glass beaker Sample composition was altered by evaporation, reaction, or dissolution Laboratory and field measurement electrodes had different types of electrodes Composite sample instead of individual samples was titrated Laboratory and field used different reagents 57
    • Horizontal Piping Arrangements flushpressure drop for AEeach branch must throttle valve to adjust velocitybe equal to keep AEthe velocities equal drain AE 20 to 80 degrees The bubble inside the glass bulb can be lodged in tip of a probe 20 pipe diameters 5 to 9 fps to minimize coatings that is horizontal or pointed up or caught at the internal electrode 0.1 to 1 fps to minimize abrasion static mixer of a probe that is vertically down or pump throttle valve to adjust velocity flush AE AE AE 10 OD 10 OD Series arrangement preferred to minimize differences in solids, 20 pipe diameters drain velocity, concentration, and temperature at each electrode! 58
    • Vertical Piping Arrangements throttle valve to throttle valve to adjust velocity adjust velocity Orientation of slot in shroud coating abrasion 5 to 9 fps 0.1 to 1 fps hole AE or 10 OD AE 10 OD slot AE AE AE AE Series arrangement preferred to minimize differences in solids, velocity, concentration, and temperature at each electrode! 59
    • Options for Maximum Accuracy Select best glass and reference electrolyte for process A hemi-spherical glass electrode and flowing junction reference offers maximum accuracy, but in practice maintenance prefers: – A refillable double junction reference to reduce the complexity of installation – often the best compromise between accuracy and maintainability. – A solid reference to resist penetration and contamination by the process and eliminate the need to refill or replace reference particularly for high and nasty concentrations and pressure fluctuations – takes the longest time to equilibrate and is more prone to junction effects. Use smart digital transmitters with built-in diagnostics Use middle signal selection of three pH measurements – Inherent auto protection against a failure, drift, coating, loss in efficiency, and noise (see February 5, 2010 entry on http://www.modelingandcontrol.com/ ) Allocate time for equilibration of the reference electrode Use “in place” standardization on a sample with the same temperature and composition as the process. If this is not practical, the middle value of three measurements can be used as a reference. The fraction and frequency of the correction should be chosen to avoid chasing previous calibrations Keep process fluid velocity constant at the highest practical value for clean and responsive electrodes 60
    • Wireless pH Lab SetupWireless pH measurements offer • Best sensor technology for a wide range of process conditions • Reduced electrical noise from ground issues • Predictive diagnostics using smart pH sensors • Convenient platform to establish specific solution temperature compensation, develop inferential measurements of process concentrations, and relocate the sensor for best results considering velocity, mixing, delay, & bubbles 61
    • Wireless pH Eliminate Ground Spikes Incredibly tight pH control via 0.001 pH wireless resolution setting still reduced the number of communications by 60% Temperature compensated wireless pH controlling at 6.9 pH set point Wired pH ground noise spike 62
    • Wireless BioreactorAdaptive pH Loop Test 63
    • Mistakes in pH System Design Mistake 1: Missing, inaccurate, or erroneous titration curve Mistake 2: Absence of a plan to handle failures, startups, or shutdowns reagent feed tank Mistake 3 (single stage Mistake 7 (gravity flow) for set point at 7 pH) Mistake 8 (valve Mistake 4 (horizontal tank) too far away) AT Mistake 12 (electrode 1-3 Mistake 9 (ball valve Mistake 10 (electrode too far downstream) with no positioner) submerged in vessel) AT Influent (1 pH) 1-1 M Mistakes 5 and 6 (backfilled dip tube & AT 1-2 injection short circuit) Mistake 11 (electrode in pump suction) 64
    • Mixing Pattern and Vessel Geometry Stagnant Stagnant Zone Zone Reagent Feed M Stagnant Plug Short Zone Flow Circuiting AT 1-3 65
    • Oversized Reagent Valves Limit cycle amplitude is operating point dependent and can be estimated as: stick-slip (%) multiplied by valve characteristic slope (pph/%) and by titration curve slope (pH/pph) Dead band is 5% - 50% without a positioner ! Dead band Pneumatic positioner requires a negative % Stroke signal to close valve (%) Digital positioner will force valve shut at 0% signal Stick-Slip is worse near closed position 0 Signal dead band (%) The dead band and stick-slip is greatest near the closed position so valves that ride the seat from over sizing or split ranged operation create a large limit cycle 66
    • Control Valve Rangeabilityand Resolution pH 8 Set point Control Band 6 BEr = 100% * Fimax * ---- Influent pH Frmax B Reagent Flow A Influent FlowFrmax = A * Fimax BEr = ---- ASs = 0.5 * ErWhere:A = distance to center of reagent error band on abscissa from influent pHB = width of allowable reagent error band on abscissa for control bandEr = allowable reagent error (%)Frmax = maximum reagent valve capacity (kg per minute)Fimax = maximum influent flow (kg per minute)Ss = allowable stick-slip (resolution limit) (%) 67
    • Key Points The pH measurement error may look smaller on the flatter portion of a titration curve but the associated reagent delivery error is larger The control system should schedule automated maintenance based on the severity of the problem and production and process requirements pH measurements can fail anywhere on or off the pH scale but middle signal selection will inherently ride out a single electrode failure of any type Equipment and piping should have the connections for three probes but a plant should not go to the expense of installing three measurements until the life expectancy has been proven to be acceptable for the process conditions A series installation of multiple probes insures the electrodes will see the same velocity and mixture that is important for consistent performance 68
    • Section 4: Summary  Extraordinary Sensitivity and Rangeability  Deceptive and Severe Nonlinearity  Extraneous Effects on Measurement  Difficult Control Valve Requirements 69
    • Look at the titration curve 14 13 12 1.10000 11 Equivalence 1.01000 10 1.00100 9 Point 1.00010 8 1.00001pH7 1.00000 6 0.99999 5 0.99990 4 0.99900 3 0.99000 2 0.90000 1 0 Not a 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0 2.1 pipette! ml of base added  pH Control is difficult because of nonlinearity: – Large Amounts of chemical cause little change initially. – Small Amounts cause huge changes near equivalence point.  Titration Curves are essential for pH system modeling
    • Rules of thumb: multiple stagesWhen the process pH mustbe changed by more than 2 pH Hydrogen Ion [H+] Hydroxyl Ion [OH-]units: 0 Acidic 1.0 0.00000000000001 1 0.1 0.0000000000001 2 0.01 0.000000000001Use Multiple Stages! 3 4 0.001 0.0001 0.00000000001 0.0000000001 5 0.00001 0.000000001 6 0.000001 0.00000001Remember that 2 pH units 7 Neutral 0.0000001 0.0000001 8 0.00000001 0.000001is a factor of 100 in 9 0.000000001 0.00001concentration. 10 0.0000000001 0.0001 11 0.00000000001 0.001 12 0.000000000001 0.01 13 0.0000000000001 0.1Can you accurately dilute a 14 Basic 0.00000000000001 1.0concentrated acid by a factor of500 in one step?
    • Rules: Mixing If the sensor does not see a representative sample of the process, it won’t measure correctly. Don’t try to do all the neutralizing in a pipe! pH reagents can be more viscous than water and require time to mix and react. Static mixers are good for first stage treatment, especially in feedforward mode. Achieving a good setpoint will usually require a downstream stabilization tank.
    • Mixing II A system normally considered to be well mixed may be poorly mixed for pH control To be “well mixed” for pH control, the deviation in the reagent to influent flow from non ideal mixing multiplied by the process gain must be well within the control band Back mixing (axial mixing) creates a beneficial process time constant and plug flow or radial mixing creates a detrimental process dead time for pH control The agitation in a vessel should be vertical axial pattern without rotation and be intense enough to break the surface but not cause froth 73
    • Rules: Holdup time1. Use sufficient holdup time to balance throughput and efficiency.2. Prevent short-circuiting by using baffles.3. Locate tank exit lines to give the reagent the maximum time to react (tanks using heavy pH solutions should overflow, not exit the bottom). improve performance provide a better location for a feedback pH loop help prevent overshoot and oscillation
    • Holdup time II Horizontal tanks are notorious for short circuiting, stagnation, and plug flow that cause excessive dead time and an erratic pH response To provide isolation, use a separate on-off valve and avoid the specification of tight shutoff and high performance valves for throttling reagent 75
    • Rules: Minimize deadtime Deadtime is the killer of all good control loops. The response time of a pH sensor depends most on how clean the glass surface is. Install the sensor in a flowing stream at about 5 feet per second velocity for a self-cleaning action. Try to minimize extractive sampling since that is another delay and may not provide a representative sample.
    • Deadtime II The actual equipment dead time is often larger than the turnover time because of non ideal mixing patterns and fluid entry and exit locations The dead time from back filled reagent dip tubes or injection piping is huge 77
    • Rules: Keep your pH sensor clean The biggest maintenance headache for pH sensors is usually just cleaning them off. Some sensors are designed to resist coating by providing large reference areas. Use a retractable sensor when the process cannot be shut down to clean the sensor. Automatic retraction (and cleaning) devices are available to save on labor costs, but can be expensive.
    • Rules: Valve selection  Good control valves have a turndown ratio of about 10:1.  Don’t oversize pH control valves!  Allow for some hysteresis and stiction in your valves to prevent overshoot problems.  Don’t try to control too close to the desired setpoint.  pH control obeys the Uncertainty Principle
    • Valve Selection II Set points on the steep portion of a titration curve require a reagent control valve precision that goes well beyond the norm and offers the best test to determine a valve’s actual stick-slip in installed conditions Reagent valve stick-slip may determine the number of stages of neutralization required, which has a huge impact on a project’s capital cost 80
    • Extreme pH values pH is a very sensitive measure of acid or base. When there is a lot of acid or base (i.e. pH over 13 or under 1), there may be more appropriate methods. Methods based on bulk measurements H2O like electrical conductivity, near infrared, H+ OH- OH- H+ or refractive index may be more accurate since they are linear in concentration.
    • Key Points - Measurement The time that glass electrodes are left dry or exposed to high pH solutions must be minimized for the best performance from the hydrated gel layer Most accuracy statements and tests are for short term exposure before changes in the glass gel layer or reference junction potential are significant The cost of pH sensor maintenance can typically be reduced by a factor of ten with realistic expectations and calibration policies The first sign of coating on the glass measurement electrode is a large increase in its time constant and response time The first sign of a non conductive coating on the reference electrode is usually a large increase in its electrical resistance Non-aqueous and pure water streams require extra attention to shielding, process path length, and velocity to minimize pH measurement noise 82
    • Key Points - Measurement II Slow references may be more stable for short term fluctuations from imperfect mixing and short exposure times from automated retraction The fastest and most accurate reference has a flowing junction but requires regulated pressurization to maintain a small positive flow The best choice might not be the best technical match to the application but the electrode that gets the best support from maintenance, operations, and vendor For non abrasive solids, installation in a recirculation line with a velocity of 5 to 9 fps downstream of a strainer and pump may delay onset of coatings For abrasive solids and viscous fluids, a thicker glass or flat electrode can minimize coatings, stagnant areas, and glass breakage For high process temperatures, high ion concentrations, and severe fouling, use automatic retractable assemblies to reduce exposure When the fluid velocity is insufficient to sweep electrodes clean, use an integral jet washer or a cleaning cycle in a retractable assembly 83
    • Conclusion  pH is a versatile and powerful analytical technique for characterizing your process  Understanding the nonlinear aspect of pH is key to successful implementation  There’s more to pH control than selecting the “best” pH sensor and tuning a PID loop  Rewards for proper pH management far outweigh the small cost of the installed field equipment
    • Where To Get More Information  “What’s the Real pH of that Stream?” – http://www2.emersonprocess.com/siteadmincenter/PM%20Ro semount%20Analytical%20Documents/Liq_Article_61- 2111_200503.pdf  Greg’s excellent book – http://www.amazon.com/Advanced-Measurement-Control-3rd- Edition/dp/1934394432  Emerson Application data sheets – http://www2.emersonprocess.com/en- US/brands/rosemountanalytical/Liquid/Documentation/ADS/Pa ges/index.aspx
