Presented by Emerson's Alan Dewey at the 2011 Emerson Exchange in Nashville, TN USA....

Presented by Emerson's Alan Dewey at the 2011 Emerson Exchange in Nashville, TN USA.

Abstract: Emerson has recently introduced a quick and easy way for users to connect directly to a FOUNDATION fieldbus segment with their portable laptop or notebook computer. Using Emerson's newly available USB Fieldbus Interface, users can easily connect their laptop or PC to a fieldbus network either in the field or on the bench. This enables users to experience the benefits of applications such as AMS Device Manager without having to use the control system. This workshop will highlight the capabilities of this useful new device and provide a live demonstration of how it can be used.

Statistics

Views

Total Views
9,270
Views on SlideShare
3,982
Embed Views
5,288

Actions

Likes
1
Downloads
74
Comments
0

13 Embeds 5,288

http://www.emersonprocessxperts.com 5190
http://www.emersonprocessexperts.com 24
http://prsync.com 21
http://feeds.feedburner.com 14
http://emersonprocessexperts.com 11
http://translate.googleusercontent.com 11
http://emersonexperts.com 5
http://172.19.56.7 3
http://webcache.googleusercontent.com 3
http://207.46.192.232 2
http://199.59.199.178 2
http://www.emersonprocessxperts.com. 1
http://www.emersonexperts.com 1
More...

Accessibility

Upload Details

Uploaded via as Microsoft PowerPoint

Usage Rights

© All Rights Reserved

Report content

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
  • Full Name Full Name Comment goes here.
    Are you sure you want to
    Your message goes here
    Processing…
Post Comment
Edit your comment

    A Quick and Easy Way to Connect to FOUNDATION fieldbus using Emerson’s USB Fieldbus Interface A Quick and Easy Way to Connect to FOUNDATION fieldbus using Emerson’s USB Fieldbus Interface Presentation Transcript

    • A Quick and Easy Way to Connect to F OUNDATION fieldbus using Emerson’s USB Fieldbus Interface Emerson User Exchange, 2011 Nashville, TN
    • Presenters
      • Alan Dewey
    • Introduction
      • Background
      • Features
      • Using with AMS Device Manager
      • Utility Program
      • Packaging
      • Fieldbus Foundation Profiles
      • Demonstration
    • Background
      • Originally available internally from Rosemount as 770
      • Original objective was to help Rosemount sales force demonstrate F OUNDATION fieldbus devices
    • “ Productizing” by Emerson AO
        • Packaging
        • Enhancements to Utility
        • Official Device Manager Support
        • Documentation
        • Pricing
        • Support
        • Agency Approvals
        • Additional Testing and Beta Testing
    • Objective of Product
      • Provide a convenient means to connect a standard PC or laptop computer to a F OUNDATION fieldbus segment.
      • Not intended to be used to implement a permanent fieldbus Host system.
    • Features
      • Fully compliant with FF Specifications
      • Joins the fieldbus segment as a Visitor
      • Two Power Modes
        • USB provides power to FF segment (85 ma)
        • Use with segments that are already powered
      • Provides two Fieldbus terminators for segment
      • Does not draw more than 12 ma from FF Segment
      • CE and UL/CSA Approval
      • Indicator lights for communication and power
      • Uses standard USB cable
      • Uses standard leadset (like the 475 Field Communicator)
    • Power Mode Handling No Power Detected Power Detected on Segment USB is Providing Power (will not be allowed if power detected). Default Case
    • Approvals IEC 61626-1 EMC Immunity IEC 60950-1 IEC/UL/CSA Safety Approvals Also: FCC 47CFR FF Physical Layer Test
    • Use with AMS Device Manager - Simple
    • Full Featured Device Dashboard Displays
      • Supported starting with Version 11.5 of AMS Device Manager
      • Shows up under the “FF HSE” branch
      • Requires AMS Device Manager HSE License
        • Special Pricing Available
      • Consistent Functionality with other FF interfaces supported in AMS Device Manager
      Deployment with AMS Device Manager
    • Utility Program Features
      • Sets Power Mode
      • Show Devices Connected to the segment
      • Allows User to:
        • Set the Device Tag
        • Set the Device Address
        • Commission / Decommission a Device
        • Change Device from Link Master to Basic
      • Provided on CD with product
      Not provided in AMS Device Manager
    • Utility Program Display – Simple! One Device on Segment (TT-101) Address of USB Interface on FF Segment Indicates that segment is already powered.
    • Utility Program Display – Simple! Select this if you want laptop to provide power to the segment via USB. A message warns you not to connect power to segment that is already powered.
    • Utility Program Display – Simple! Simply Select this to commission device Enter Device Tag Here. Device Address will be selected automatically or can be entered.
    • Future Supported Applications
      • Rosemount Radar Master
      • Fisher Valvelink
    • Product Positioning
    • Packaging
      • Interface Module
      • USB Cable
      • Fieldbus Lead Set
      • Installation CD
      • User Manual
    • Fieldbus Foundation Profile Coverage USB Fieldbus Interface (with AMS Device Manager) will initially conform to this profile
    • Summary
      • The previous Rosemount 770 Fieldbus Modem is now available as the USB Fieldbus Interface to customers.
      • Extend your laptop with AMS Device Manager beyond HART to F OUNDATION fieldbus devices
    • Where To Get More Information AMS Device Manager Web Site
    • Expected Release Date – Spring, 2012 .
