  • 1. Hybrid Approaches to Taxonomy & Folksonomy Semantic Technology 2009 San Jose, CA June 17, 2009 Richard Beatch Paul Wlodarczyk Earley & Associates www.earley.com
  • 2. Agenda
    • The taxonomy/folksonomy debate
    • Tagging pitfalls
    • Social tagging & the enterprise
    • Hybrid approaches to taxonomy/folksonomy
      • Co-existence
      • Tag-influenced taxonomy
      • Taxonomy-influenced tags
      • Tag hierarchies/ontologies
    • Conclusion
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 3. About Earley & Associates
    • Founded in 1994, Earley & Associates is an information management (IM) consulting company specializing in
      • Taxonomy development and management
      • Content management strategy
      • Search integration
      • Usability & Information Architecture
    • Some of our recent clients include:
      • American Greetings, Hasbro, Ford Foundation, Astra Zeneca, Motorola, The Hartford Insurance Group, Urban Land Institute
    • Give us your business card
      • For a free pass to one of our Community of Practice conference calls
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 4. About us
    • Richard Beatch
      • Senior Consultant at Earley & Associates, Inc.
      • Ph.D. in Ontology
      • Specialized in Taxonomy, Search, Metadata, and content architecture.
      • Extensive industry experience leading the implementation and design of taxonomies and search solutions for a range of companies including Apple, McAfee, Allstate, Dell, and AT&T.
      • Blog: http://sethearley.wordpress.com/
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 5. About us
    • Paul Wlodarczyk
      • Director, Solutions Consulting at Earley & Associates, Inc.
      • MBA with BA in Psychology / Cognitive Science
      • Specialized in unstructured content technologies with over 20 years experience in XML / structured authoring, content reuse, ECM, KM, localization, semantic analysis and content enrichment
      • Blogs at http://sethearley.wordpress.com/ and http://thecontentguy.net
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 6. The tired debate Copyright © 2009 Earley & Associates Inc. All Rights Reserved Taxonomy Folksonomy Control Democracy Top-down Bottom-up Arduous process Just do it Accurate Good enough Restrictive Flexible Static Evolving Expensive to maintain Low cost – “crowdsourced”
  • 7. The relevance problem
    • Search results should be relevant to what a searcher wants, but technology can only determine if it is relevant to a search term*
    • Taxonomies and folksonomies = 2 approaches to the problem of relevance with common goal of describing content, each with particular gaps
    *Billy Cripe: Folksonomy, Keywords & Tags: Social & Democratic User Interaction in Enterprise Content Management http://www.oracle.com/technology/products/content-management/pdf/OracleSocialTaggingWhitePaper.pdf Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 8. Taxonomy
    • Added by a small number of individuals: author/originators or “authorized” persons (e.g.librarian)
    • Describes meaning or purpose of content based on a set view point for a specific audience using a controlled vocabulary
    • Relationships between terms defined
      • Hierarchical (e.g. Computer hardware > Keyboard)
      • Associative (e.g. Computer hardware – Software)
      • Equivalent (e.g. Laptop = Notebook Computer)
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 9. Tags
    • Added by authors and consumers (individual motivation)
    • Can connote any type of meaning or purpose
    • No compression around a single viewpoint, no control of vocabulary
    • Self-correcting through volume
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 10. Why tagging is so interesting…
    • Adding individual value to the act of classification – user control over findability
    • Reducing the cognitive burden (i.e. it’s easy)
    • Reduced technological investment (i.e. it’s cheap)
    • Can leverage emergent structure (folksonomy)
    Reno| Tags Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 11. The downside…
    • Neither tags nor taggers are perfect …
    • No language control
      • Guy & Tonkin, 2006.
      • http://www.dlib.org/dlib/january06/guy/01guy.html
    Study: 40% of flickr tags and 28% of del.icio.us tags were flawed in these ways Copyright © 2009 Earley & Associates Inc. All Rights Reserved Misspellings Library vs. libary Plam pilot Compound words TimBernersLee Case & number Folksonomy, Folksonomies Personal tags To read My dog @work Single-use tags Billybobsdog
  • 12. The downside…
    • Varying levels of granularity
    • Same tag, different meanings
    • Lack of relationships between tags – which is broader? Narrower?
    • Lack of consistency/approach to change – even single user can change language and hamper own personal retrieval
    Robin Bird Turdus migratorinus … Known as “tag noise” Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 13. The downside…
    • Most tag search does not account for stemming, plurals, etc.
    E.g. Search on Delicious: Folksonomy: 16049 Folksonomies: 4404 Both: 2642 Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 14. The tagging hype cycle http://www.pui.ch/phred/archives/2007/05/tag-history-and-gartners-hype-cycles.html Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 15. The web vs. the enterprise
    • Shirky: “there is no shelf”
      • Traditional organization schemes are built to deal with physical collections and constraints.
      • They don’t work well on the web
        • large corpus
        • no clear edges
        • no formal categories
        • no authority
    • The enterprise is much more defined
        • smaller corpuses
        • formal entities
        • coordinated users, clear tasks
        • need for reliable retrieval
    E.g. Flickr Delicious Social tagging works well in this context Social tagging is more of a challenge, needs clear arena Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 16. R o le of folksonomy in the enterprise?
    • Tagging external links
      • Seeing what colleagues are interested in
      • Sharing links with a specific team
      • Subscribing to link feeds
      • Monitoring news/blog coverage of the company
      • Consumer/competitor research
      • Tracking industry trends
    • Tagging internal links
      • Finding/facilitating access to most popular pages on the intranet
      • Seeing what intranet pages mean to staff
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 17. Role of folksonomy in the enterprise?
    • Social aspects
      • Identifying subject matter experts
      • Connecting people who share interests
      • Encouraging collaboration & resource sharing
    • Improve your taxonomy, information retrieval
      • User tagging to refine the corporate taxonomy
        • New concepts
        • New terminology
      • Seeing what employees find interesting
      • Distributing tagging tasks
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 18. The downside…
    • Potential issues of security, inappropriateness
      • Can implement some level of vetting
    • Privacy concerns
      • Can be anonymous tagging, although this removes some social value
      • Can create role or team-based collections
    • Need higher ratio of active participants due to population size
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 19. Message text External News Reports Discussion postings Links Engineering document repositories Success Stories Policies Approved Methods Best Practices Key concept: Not all content is created equally The content continuum Copyright © 2009 Earley & Associates Inc. All Rights Reserved Lower Cost Higher Cost Tagging/Organizing Processes Unfiltered Reviewed/Vetted/Approved Lower Value Higher Value
  • 20. What if we blended the two?
    • Folksonomy / Taxonomy
    Low cost Findability Flexible Structured relationships User terminology Oversight Social sharing Consistency Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 21. Hybrid approaches Co-existence Tag-influenced taxonomy Taxonomy-influenced tagging Tag hierarchies/ontologies Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 22. Co-existence
    • Taxonomy and folksonomy are used side by side
    • Strengths of each approach preserved, philosophy of each kept “pure”
    Web example: Flickr & Library of Congress: http://www.flickr.com/photos/library_of_congress/ Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 23. Co-existence – Ann Arbor District Library Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 24. Raytheon – corporate example
    • Used in Raytheon employee portal - website lists (“Suggested sites” feature box)
    • How does it work:
      • inserted “Suggested Sites” in a "feature" box to the right of the regularly ranked results
      • website suggestions (URLs) submitted along with recommended tags/keywords which are subsequently verified and approved by librarians
    http://www.slideshare.net/CJMConnors/i-kms-singapore-presentation Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 25. Variation: Tag mediation
    • Vetting & editing tags
    • Pros:
      • Weeds out potentially inappropriate tags
      • Eliminates misspellings, plural issues, etc.
      • Some can be done automatically (spell-checker, e.g.)
      • Enhances findability
    • Cons:
      • Higher effort/cost
      • Perceived lack of trust
      • Who knows better?
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 26. Tag-influenced taxonomy
    • Taxonomy & tagging co-exist, tags serve as pool of candidate terms to enrich taxonomy, keep it current
      • Find new terminology (synonyms, popular language)
      • Find new concepts
    • Performed as separate processes (taxonomy tagging=formal, tagging=informal) or combined in single interface
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 27. Tag-influenced taxonomy
    • Requires formal vetting process
    • Can be supported by automation (e.g. candidate tags pulled & filtered with script to remove taxonomy terms, stop words)
    • Evaluate candidates based on
      • Frequency (“literary warrant”)
      • Salience within context
    • Look at tags used in conjunction with taxonomy
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 28. Taxonomy-influenced tagging
    • Presenting choices/suggestions to user from controlled set of terms/tags
      • Sometimes users prefer easy choice
        • Drop-down menus
        • Check boxes
        • Type ahead
        • Tree view
      • “ influenced” – option to enter own tag? Good source of new terms
      • Enforces consistency
      • Offers structure
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 29. WWW example: ZigTag Defined Tagging Definitions from Wikipedia & Wordnet Tagging with type-ahead against database of 3M unique concepts & 8M synonyms Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 30. Zigtag
    • Type ahead & synonyms encourage consistency
    • Users can enter new tags
    • Synonyms based on Wikipedia, so can be “dirty data”
    • No hierarchy, only equivalent relationships so far
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 31. Zigtag search Still get problems with uncontrolled tags & recall Interesting relationships from Wikipedia Browse-able tag cloud Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 32. Example: myedna (Education.au) http://www.educationau.edu.au/jahia/webdav/site/myjahiasite/shared/papers/tagging_hayman.ppt Fully taxonomy-directed tagging Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 33. TextWise Semantic Cloud
    • Document (URL or text) is submitted to web service for semantic analysis
    • Category tags from subset of the ODP taxonomy
    • Concept tags are derived from document, persisted, related to ODP categories
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved 1 3 2
  • 34. Buzzillions.com
    • Review site: tags are “controlled” not against a taxonomy, but against other tags – reduces redundancy
    • Only popular tags exposed as faceted navigation
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 35. SharePoint?
    • Plug-ins make taxonomy easy
    • Present the taxonomy like tags
    • E.g. KWizCom: plug-in manages taxonomy and tags in easy interface… can opt-out of letting users create own tags
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 36. Taxonomy-influenced tagging
    • Pros:
      • More consistency
      • Better support for findability
      • Relationships, definitions leveraged – adding meaning to the tags
      • Realistic for the enterprise
    • Cons:
      • Not really folksonomy anymore..
      • Can be forcing terminology on user
      • Need to develop reference list of concepts – manually through taxonomy or need large corpus to derive automatically
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 37. Tag hierarchies
    • Tag hierarchies come in two flavors:
    • User-powered
    • Automatic derivation
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 38. User-powered tag hierarchies
    • User-powered
      • Social approach
      • Bogus hierarchies possible
      • Small population will contribute
    • RawSugar tried it
      • (no longer around)
      • Taggers could specify hierarchy in own account, tags clustered based on common groups
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 39. User-powered tag hierarchies
    • E.g. LibraryThing
    LibraryThing allows any use to combine (or uncombine) 2 tags that are semantically equivalent. www.librarything.com Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 40. User-powered tag hierarchies: Intelligent tags
    • Move toward more semantic tagging with machine-readable tags, e.g. Flickr machine tags in “triple” format: [namespace]:[key]=[value]
      • geo:neighborhood=SoHo, geo:lat=58.41618, etc.
      • flickr:user=mortimer
      • taxonomy:common=grevyszebra
      • lastfm:event=34640
        • makes your photo appear on a lastfm event page
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 41. User-powered tag hierarchies: Intelligent tags
    • MOAT: Meaning of a tag – part of linked data movement, mapping tags to semantic web
      • http://moat-project.org/
    • Adding to the triplet
      • User – resource – tag – meaning
      • Meaning = URI to a resource containing meaning (e.g. DBPedia)
    <tag:RestrictedTagging> <tag:taggedResource rdf:resource=&quot;http://example.org/post/1&quot;/> <foaf:maker rdf:resource=&quot;http://apassant.net/alex&quot;/> <tag:associatedTag rdf:resource=&quot;http://tags.moat-project.org/tag/ apple &quot;/> <moat:tagMeaning rdf:resource=&quot;http://dbpedia.org/resource/Apple_Records&quot;/> </tag:RestrictedTagging> Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 42. Automatically derived tag hierarchies
    • Tag hierarchies, facets, ontologies, or “folksontology”
    • Done through statistical/clustering algorithms
    http://www.pui.ch/phred/automated_tag_clustering/ Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 43. Delicious & citeulike hiearchy http://heymann.stanford.edu/taghierarchy.html Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 44. Clustering at flickr Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 45. Auto clustering/facets
    • Still not very mature
    • Time-sensitive
    • Community- sensitive
    • Ambiguous tags
    • Improve with volume (self-correcting)
    http://www.pui.ch/phred/automated_tag_clustering/ Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 46. Tag hierarchy pros and cons
    • Pros:
      • Relationships, definitions leveraged – adding meaning to the tags
      • Provides a basis for application behavior in the absence of taxonomy (e.g. Flickr maps, clusters)
      • Self-correcting with volume
    • Cons:
      • Automatically derived relationships (clusters) can be bogus or time-sensitive
      • Folksonomic relationships can be esoteric (just like tags)
      • Small population of contributors
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 47. Conclusion
    • Not all content is created equal – tags and taxonomies have their sweet spots
    • Hybrid approaches are emerging
      • taxonomy-influenced tagging leading the pack in popularity on the web
      • co-existence in the enterprise
    • Look for more developments on the semantic web/linked data front for making tags more intelligent
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 48. Questions? Richard Beatch [email_address] Paul Wlodarczyk [email_address] Web : www.earley.com Blog : sethearley.wordpress.com Twitter : earleytaxonomy Give us your business card for a free pass to one of our Community of Practice conference calls (a $50 value).
  • 49. Appendix: Corporate social tagging tools
  • 50. Corporate social tagging software http://www.connectbeam.com/ Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 51. Corporate social tagging software http://www.cogenz.com/ Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 52. Corporate social tagging software http://www-306.ibm.com/software/lotus/products/connections/dogear.html Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 53. Corporate social tagging software
    • BEA AquaLogic Pathways
        • http://www.bea.com/framework.jsp?CNT=index.jsp&FP=/content/products/aqualogic/pathways/
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
  • 54. Corporate social tagging software
        • http://www.newsgator.com/business/socialsites/default.aspx
    Copyright © 2009 Earley & Associates Inc. All Rights Reserved
