Transcript

  • 1.
  • 2. Agenda December 03, 2008 Carbon Limits AS
    • The use of non-associated gas in open-cycle gas-lift
    • Example case from Democratic Republic of Congo
    • Conceptual framework for a new CDM baseline methodology
    • Key characteristics of the proposed methodology
    • Conclusions
  • 3. The use of non-associated gas for gas-lift leads to flaring and substantial GHG emissions December 03, 2008 Carbon Limits AS
    • Gas-lift is a commonly used artificial-lift method by which high-pressure gas assists in bringing oil to the surface
    • High-pressure gas can be provided from either associated or non-associated sources
    • Non-associated gas is often at higher pressure than associated gas and typically require less treatment than associated gas
    • Where gas has low value, non-associated gas is often the lowest cost of supply of high-pressure gas for gas-lift
    • When non-associated gas is used as gas-lift gas, there is often higher, absolute volumes of gas flared
  • 4. Offshore oilfield in DRC utilizing non-associated gas for gas-lift as it represents the lowest cost of supply December 03, 2008 Carbon Limits AS All numbers in MSCF/day Original situation:
  • 5. Project for optimization of gas utilization on-site developed based on potential CDM benefits: 30,000 tCO2e/month December 03, 2008 Carbon Limits AS All numbers in MSCF/day Pilot CDM project activity:
  • 6. The characteristics of the DRC project provides the conceptual framework for a new CDM methodology December 03, 2008 Carbon Limits AS
    • Non-associated gas can be the lowest cost option to provide high-pressure gas for gas-lift of oil wells (i.e. an open-cycle gas-lift system)
    • Gas from oil wells that is currently flared can be recovered and used to substitute for the non-associated gas, thus reducing flaring of gas
    • The volume of gas recovered for use for gas-lift serves as a one-to-one proxy for the volume of non-associated gas that would have been used in the baseline to provide the same service
    • Projects will take place in complex brownfield developments and could require utilization of both new and existing gas infrastructure
    • A change in the supply to the gas-lift system will by itself not end gas flaring at the field
  • 7. December 03, 2008 Carbon Limits AS End-use (i.e. gas-lift system) included within project boundary and in the baseline selection
  • 8. Highlights December 03, 2008 Carbon Limits AS
    • Substitution of non-associated gas with recovered gas for gas-lift leads to a measurable reduction in flaring and thus GHG emissions in situations with very limited opportunities to market gas
    • CDM can alter the economic balance in favor of gas from oil wells given that the motivation for using non-associated gas is lower cost (example in DRC has an abatement cost of 2.9 USD/tCO 2e )
    • Procedure for selection of baseline scenario in NM0277 can be further improved to expand the applicability of AM0009/AM0037 to allow for the recovery of gas-lift gas as well as associated gas
