Modelling the Impacts of Electric Vehicles    on Greenhouse Gas Emissions         EPA Transport Seminar                13t...
Overview    •   Background    •   International Roadmap    •   EU Roadmap    •   Ireland Roadmap    •   EV Technologies & ...
Background   Transport, Energy & CO2 – Moving Towards Sustainability, OECD/IEA (2009)A. Foley & B. Ó Gallachóir   Modellin...
International Roadmap   Transport, Energy & CO2 – Moving Towards Sustainability, OECD/IEA (2009)A. Foley & B. Ó Gallachóir...
International Roadmap   International Council on Clean Transportation, 2009A. Foley & B. Ó Gallachóir     Modelling Impact...
International Roadmap                    Energy Technologies Perspective, OECD/IEA (2010)A. Foley & B. Ó Gallachóir       ...
EU & National Roadmap   • Initially Directive 2009/28/EC ~ 10% transport energy     from other renewable sources not just ...
EU & National Roadmap  Directives & policies applicable to the transport sector  in 2020 include:         – 20% reduction ...
EV Technologies & Infrastructure       Two main EV types considered:             – Battery Electric Vehicle (BEV)         ...
EV Technologies & Infrastructure   ESB ecar, 2011A. Foley & B. Ó Gallachóir     Modelling Impact of EVs on GHG Emissions  ...
International Standardisation   ‘tsunami of codes and standards’ ~       Steven Rosenstock, Edison Electric Institute at t...
International Standardisation   • IEEE P2020.1 Guide for Electric-Sourced       Transportation Infrastructure due end 2011...
Manufacturers/Government                                         Roadmaps     Country                    Targets     Austr...
Manufacturers/Government                                        Roadmaps    Car manufacturer         Battery manufacturer ...
Charging Portfolios   • Peak (Uncontrolled/unconstrained)   • Off – peak (Controlled/delayed)   • Opportunistic (Stochasti...
EV Car Stock       Additional CO2 emissions in the Electricity Sector (High, Medium &       Low EV Scenarios), 2010 to 202...
WASP-IV     • Traditional Long Term Generation Model     • WASP IV ~ IAEA (free for academic users)     • 3 optimisation t...
WASP-IV     Scenario ApproachA. Foley & B. Ó Gallachóir   Modelling Impact of EVs on GHG Emissions   18 of 27
WASP-IV                             Total Energy with & without PHEV ChargingA. Foley & B. Ó Gallachóir          Modelling...
WASP-IVA. Foley & B. Ó Gallachóir   Modelling Impact of EVs on GHG Emissions   20 of 27
PLEXOS                             PLEXOS for Power SystemsA. Foley & B. Ó Gallachóir     Modelling Impact of EVs on GHG E...
PLEXOS     • Market based power system model     • Mathematical optimisation:          Linear Programming (LP)          Mi...
PLEXOS                                          10% Renewable Energy   20% Emissions Target                     Wind Varia...
Conclusions    • EV Car Stock          – 1.72% ~ 10% RES-T target by 2020          – 1.4% ~ 20% reduction Non-ETS emission...
Conclusions    • OEM Technology roadmap slower ~ Government      Policy Targets    • All indications off-peak & wind-follo...
Further activities/Next Steps    • Run PLEXOS using Xpress rather than      Mosek    • Stochastic Optimisation    • EV Cha...
Thank You       Acknowledgements             – Paul Deane             –   Patrick Calnan             –   Hannah Daly      ...
