Improving QA on PHP projects - confoo 2011

Improving QA on PHP projects Confoo 2011, Montreal (Canada)

Michelangelo van Dam• Independent Consultant• Zend Certiﬁed Engineer (ZCE)• President of PHPBenelux

What’s the beneﬁt of QA?• early detection of issues• cleaner & consistent code• knowledge about the codebase• increase of conﬁdence

Sebastian Bergmann• QA expert• wrote the tools• speaker and inspirer

Usual Suspects PHP_CodeSniffer

Example Code•- Zend Framework QuickStart app http://framework.zend.com/manual/en/learning.quickstart.intro.html

VirtualHost Settings<VirtualHost *:80> DocumentRoot /srv/www/quickstart/public ServerName quickstart.local ServerAdmin root@localhost <Directory /srv/www/quickstart/public> Options Indexes FollowSymlinks AllowOverride All Order allow,deny Allow from all DirectoryIndex index.php </Directory> Alias /reports /srv/www/quickstart/reports <Directory /srv/www/quickstart/reports> Options Indexes FollowSymlinks AllowOverride All Order allow,deny Allow from all DirectoryIndex index.php index.html </Directory></VirtualHost>

Showtime

Syntax Checking•- PHPLint comes with PHP binary - validates code for syntax errors• Website - http://www.icosaedro.it/phplint/

Demo PHPLint

Code Documentation•- PHPDocumentator creates automated API documentation - based on inline code blocks• Installation - pear install PhpDocumentor• Website - http://www.phpdoc.org

Demo PHPDoc

Output PHPDoc

Coding Standards•- PHP_CodeSniffer sniffs for coding standard violations - ensures code is clean and consistent - using standard and custom coding standards• Installation - pear install PHP_CodeSniffer• Website - http://pear.php.net/package/PHP_CodeSniffer

Demo PHP_CodeSniffer

PHPCPD•- PHP Copy/Paste Detector detects code duplication•- Installation pear channel-discover pear.phpunit.de - pear channel-discover components.ez.no - pear install --alldeps phpunit/phpcpd• Website - http://github.com/sebastianbergmann/phpcpd

Demo PHPCPD

Output

Mess Detection•- PDepend & PHPMD detects code mess•- Installation pear channel-discover pear.pdepend.org - pear install pdepend/PHP_Depend - pear channel-discover pear.phpmd.org - pear install phpmd/PHP_PMD• Websites - http://www.pdepend.org - http://www.phpmd.org

Demo detecting mess

Output codesize

Output unused code

Unit Testing•- PHPUnit tests code on unit level - includes database tests - integrates well with many PHP frameworks• Installation - pear channel-discover pear.phpunit.de - pear install phpunit/PHPUnit• Website - http://www.phpunit.de

See other presentation http://slideshare.net/DragonBe/unit-testing-after-zf-18

Packaging•- Phar PHP Archive (equivalent of Java jar) - compresses and collects like - included in PHP build (as of PHP 5.3.0)• Installation (before PHP 5.3.0) - pecl install phar• Website: - http://php.net/phar

Code example<?phpinclude_once ‘phar://MyApp.phar/path/to/Class.php’;$application = new Class;$application->run();

Usage• libraries• modules• images• plugins• deployment

Automated builds•- Phing automated build tool - like Apache Ant - integrates well with other PHP tools• Installation - pear channel-discover pear.phing.info - pear install phing/phing• Website - http://phing.info

build.xml<?xml version="1.0"?><project name="zfqs" description="Zend Framework QuickStart" default="build" > <target name="version"> <version releasetype="Bugfix" file="build.version" property="version.number"/> </target> <target name="phplint"> <mkdir dir="./reports/phplint" /> <phplint file="./application/models" haltonfailure="false" tofile="./reports/phplint/errors.txt"/> </target> <target name="pdepend"> <mkdir dir="./reports/pdepend" /> <copy file="./build_pdepend.html" tofile="./reports/pdepend/index.html" overwrite="true" /> <exec command="/usr/bin/pdepend --summary-xml=./reports/pdepend/summary.xml --jdepend-chart=./reports/pdepend/jdepend.svg --overview-pyramid=./reports/pdepend/pyramid.svg ./application/models" dir="./" /> </target> <target name="phpmd"> <mkdir dir="./reports/phpmd" /> <exec command="/usr/bin/phpmd ./application/models html codesize --reportfile ./reports/phpmd/codesize.html" dir="./" /> <exec command="/usr/bin/phpmd ./application/models html unusedcode --reportfile ./reports/phpmd/unusedcode.html" dir="./" /> </target> <target name="phpcs"> <mkdir dir="./reports/phpcs" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=summary ./application/models > ./reports/phpcs/summary.txt" dir="./" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=source ./application/models > ./reports/phpcs/source.txt" dir="./" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=checkstyle ./application/models > ./reports/phpcs/checkstyle.xml" dir="./" /> </target> <target name="phpcpd"> <mkdir dir="./reports/phpcpd" /> <exec command="/usr/bin/phpcpd --log-pmd ./reports/phpcpd/pmd-cpd.xml ./application/models" dir="./" /> </target> <target name="phpdoc"> <mkdir dir="./reports/phpdoc" /> <exec command="phpdoc -d ./application/models -q -t ./reports/phpdoc -o HTML:frames:earthli" dir="./" /> </target> <target name="build" depends="version,phplint,pdepend,phpmd,phpcs,phpcpd,phpdoc"> <echo msg="Finishing build process ${version.number}" /> </target></project>

project deﬁnition<?xml version="1.0"?><project name="zfqs" description="Zend Framework QuickStart" default="build" >…</project>

target version<target name="version"> <version releasetype="Bugfix" file="build.version" property="version.number"/></target>In file “build.version” we have the version number as the following sequence:MAJOR.MINOR.BUGFIX (starting at 0.0.0)

target phplint<target name="phplint"> <mkdir dir="./reports/phplint" /> <phplint file="./application/models" haltonfailure="false" tofile="./reports/phplint/errors.txt"/></target>

target pdepend<target name="pdepend"> <mkdir dir="./reports/pdepend" /> <copy file="./build_pdepend.html" tofile="./reports/pdepend/index.html" overwrite="true" /> <exec command="/usr/bin/pdepend --summary-xml=./reports/pdepend/summary.xml --jdepend-chart=./reports/pdepend/jdepend.svg --overview-pyramid=./reports/pdepend/pyramid.svg ./application/models" dir="./" /></target>

target phpmd<target name="phpmd"> <mkdir dir="./reports/phpmd" /> <exec command="/usr/bin/phpmd ./application/models html codesize --reportfile ./reports/phpmd/codesize.html" dir="./" /> <exec command="/usr/bin/phpmd ./application/models html unusedcode --reportfile ./reports/phpmd/unusedcode.html" dir="./" /></target>

target phpcs<target name="phpcs"> <mkdir dir="./reports/phpcs" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=summary ./application/models > ./reports/phpcs/summary.txt" dir="./" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=source ./application/models > ./reports/phpcs/source.txt" dir="./" /> <exec command="/usr/bin/phpcs -n --standard=Zend --report=checkstyle ./application/models > ./reports/phpcs/checkstyle.xml" dir="./" /></target>

target phpcpd<target name="phpcpd"> <mkdir dir="./reports/phpcpd" /> <exec command="/usr/bin/phpcpd --log-pmd ./reports/phpcpd/pmd-cpd.xml ./application/models" dir="./" /></target>

target phpdoc<target name="phpdoc"> <mkdir dir="./reports/phpdoc" /> <exec command="phpdoc -d ./application/models -q -t ./reports/phpdoc -o HTML:frames:earthli" dir="./" /></target>

target build<target name="build" depends="version,phplint,pdepend,phpmd,phpcs,phpcpd,phpdoc"> <echo msg="Finishing build process ${version.number}" /></target>

Demo building all

Demo building target

Our reports section

Summary PHP offers lots of toolsmore consistent and clean code automated process

Questions• http://www.slideshare.net/DragonBe/improving-qa-on- php-projects-confoo2011• http://twitter.com/DragonBe• http://facebook.com/DragonBe• http://joind.in/2822
