Secure Mobility in CiscoUnified WLAN NetworksBRKEWN-2018Jake WoodhamsSenior Manager/Architect, Technical MarketingJuly 201...
Abstract•  The proliferation of Wi-Fi enabled devices creates important   challenges for IT, perhaps the chief challenge b...
Session Agenda•  Anatomy of a Device Connection•  Anatomy of a Device Roam•  Design and Deployment ConsiderationsBRKEWN-20...
Anatomy of a DeviceConnectionBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   4
Section Agenda•  802.11 Architecture and Services Basics•  802.11i Addendum•  EAP Types and Key Management•  Device Mobili...
802.11 Architecture Basics   BSS – Basic Service Set   SSID – Service Set Identifier   BSSID – Basic Service Set Identi...
802.11 Architecture Basics   ESS – Extended Service Set   DS – Distribution System                                      ...
802.11 ServicesService                                            Description                          Implementation     ...
802.11 Services     Service                                              Description                          Implementati...
802.11 Services     Service                                              Description                          Implementati...
802.11 Services     Service                                              Description                          Implementati...
802.11 Services     Service                                              Description                          Implementati...
802.11 Distribution ServicesAssociation Service               802.11 Association Request:              “Can I Associate to...
802.11 Distribution ServicesDisassociation Service               802.11 Disassociation Request:              “You Cannot B...
802.11 Distribution ServicesReassociation Service (Roaming Context)                   802.11 Disassociation Request:      ...
802.11 Services      Service                                              Description                          Implementat...
802.11 Services     Service                                              Description                          Implementati...
How STAs Connect to a WLAN SecurelySTA Services•  802.11 spec defines authentication, deauthentication, and   privacy serv...
WPA/WPA2                                                 •  A snapshot of the 802.11I Standard               WPA          ...
Authentication Best Practices:WPA2-Enterprise        Strong Authentication       •  Extensible Authentication Protocol (EA...
802.1X/EAP Choreography802.1X/EAPThree Party Model                                                                        ...
802.1X/EAP Choreography                                                                                                   ...
EAP Types: EAP-FASTBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   23
EAP Types: PEAPBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   24
EAP Types: EAP-TLSBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   25
802.1X/EAP ChoreographyBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   26
Key Management –Four-Way HandshakeBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   27
Key Management – Pairwise TransientKey (PTK)BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco...
Key Management – Group Transient Key(GTK)BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Pu...
Key Management – GTK DistributionBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   30
802.1X/EAP Choreography                                                                                                   ...
802.11 Services        Service                                             Description                          Implementa...
802.11 Architecture Basics   ESS – Extended Service Set   DS – Distribution System                                      ...
802.1X/EAP ChoreographyBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   34
Device Mobility Problem Statement:• Specification for how STAs association,authenticate, and protect data privacy defined ...
Device Mobility Problem Statement:• Wireless devices move by definition• Applications require session persistence, whilema...
Anatomy of a Device RoamBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   37
Section Agenda•  CUWN Architecture Review•  Basic Roaming Walkthrough•  Fast Secure Roaming TechnologiesBRKEWN-2018   © 20...
CUWN Architecture ReviewReal-Time 802.11/MAC Functionality:      •  Beacon Generation      •  Probe Response              ...
802.1X/EAP Choreography RevisitedBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   40
Anatomy of a STA RoamInitial Device Connection to NetworkBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights rese...
Anatomy of a STA RoamClient RoamBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   42
Anatomy of a STA RoamSummary of Important Points•  The STA chooses when to roam•  Each time the STA connects to a new BSSI...
How Long Does an STA Roam Take?•  Time it takes for:       Client to disassociate +       Probe for and select a new AP + ...
How Are We Going to MakeRoaming Faster?Focus on Where We Can Have theBiggest Impact…    Eliminating the (re)IP address ac...
Roaming: Intra-Controller•  Intra-controller roam   happens when a STA   moves association   between APs joined to the   s...
Roaming: Inter-ControllerLayer 2BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   47
Roaming: Inter-ControllerLayer 2•  L2 inter-controller roam: STA moves association between APs   joined to the different c...
Roaming: Inter-ControllerLayer 3BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   49
Roaming: Inter-ControllerLayer 3•  L3 inter-controller roam: STA moves association between APs joined   to the different c...
How Are We Going to MakeRoaming Faster?Focus on Where We Can Have theBiggest Impact…    Eliminating the (re)IP address ac...
Cisco Centralized Key Management(CCKM)•  Cisco introduced CCKM in CCXv2 (pre-802.11I), so widely   available, especially w...
PMKID Caching•  Optional component of 802.11I specification•  Defines a “PMK Security Association” (PMKSA) that gets store...
Opportunistic/Proactive Key Caching Basic Mechanics                                                                       ...
Proactive Key Caching Basic Mechanics BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Publi...
OKC/PKCKey Data Points•  Requires client/supplicant support•  Supported in Windows since XP SP2•  Many ASDs support OKC an...
Standardization! 802.11R•  802.11R is a ratified IEEE standard, based in large part on   CCKM•  802.11R: “Fast (Basic Serv...
How Are We Going to MakeRoaming Faster?Focus on Where We Can Have theBiggest Impact…    Eliminating the (re)IP address ac...
Design and DeploymentConsiderationsBRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public  ...
Section Agenda•  Roaming Domains•  Design Considerations for Roaming•  Client Roaming Behavior•  Special Case: H-REAP Grou...
Roaming Domains  Mobility Group•  Mobility Group – cluster of   up to 24 controllers   (regardless of type) that   create ...
Roaming Domains  Mobility Domain  •  Mobility Domain is a seamless     roaming domain of up to 3     Mobility Groups  •  M...
How Long Does a Client Really Take toRoam?•  Time to roam =       Client to disassociate +       Probe for and select a ne...
How Often Do Clients Roam?•  It depends… types of clients and applications•  Most client devices are designed to be “nomad...
Designing a Mobility Group/DomainDesign Considerations•  Less roaming is better – clients and apps are happier•  While cli...
Special Case: FlexConnect Groups  •  Support for up to 20 FlexConnect Groups of up to 25     FlexConnect APs each  •  APs ...
Questions?BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   67
Complete Your OnlineSession Evaluation  Receive 25 Cisco Preferred Access points for each session   evaluation you comple...
Visit the Cisco Store for               Related Titles        http://theciscostores.comBRKEWN-2018   © 2011 Cisco and/or i...
BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   70
Thank you.BRKEWN-2018   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   71
