F3X12 FLOW3 Project Lifecycle

Project Lifecycle

TheProject LifecycleProject Setup, Deplyoment and Maintenance of FLOW3 projects.

About me Christopher Hlubek CTO networkteam GmbH FLOW3 & TYPO3 Phoenix Core Team

Requirements Support Architecture Deploy Design Test ImplementationSoftwareDevelopmentLifecycle

Code is not everything Architecture Test Deploy SupportSoftwareDevelopmentLifecycle

Non-Functional Project RisksFramework updates and changes Bugs in application code Bugs in framework code Bugs in 3rd party code Erroneous deployment ...

Architecture

Composition of a FLOW3 application Build Application PackagesConﬁguration Community Packages Data Framework Packages Web Distribution

Project Setup

Create a distributiongit clone --recursive -o typo3 git://git.typo3.org/FLOW3/Distributions/Base.git MyDistributiongit remote add origin ssh://myrepo.local/path/to/distribution.git

Versioning with Git simple Distribution Application Packages Your Git Server TYPO3 / Community Git Community Packages Server TYPO3 Git Server Framework Packages

Emergency Hotfix - or - Core Hacks

Versioning with Git more ﬂexible Distribution Application Packages Your Git Server TYPO3 / Community Git Community Packages Server TYPO3 Git Server Framework Packages

Git Vendor BranchingSubmodule Pointer origin/master [TASK] Latest ... vendor/master [FEATURE] Some feature ... [BUGFIX] Some bugﬁx ... [TASK] Lorem ipsum ... Package Repository

Create a hotfixgit checkout mastergit commit ...git push origin master

Git Vendor BranchingSubmodule Pointer origin/master [HOTFIX] Custom patch vendor/master[TASK] Latest ... [FEATURE] Some feature ... [BUGFIX] Some bugﬁx ... [TASK] Lorem ipsum ... Package Repository

Update the Packagegit fetch vendorgit merge vendor/master mastergit push origin master

Git Vendor BranchingSubmodule Pointer origin/master Merge remote-tracking ... vendor/master [TASK] New change ... [HOTFIX] Custom patch [TASK] Latest ... [FEATURE] Some feature ... [BUGFIX] Some bugﬁx ... [TASK] Lorem ipsum ... Package Repository

Unit Tests vs. Functional TestsApplication Class / Unit } Unit Test Application Package Functional Test FLOW3 Framework Database

Unit TestsTest complex logic in isolationFind the source of a problemShould test a restricted set of classes

Functional TestsTest code with the framework and databaseCheck that a feature worksIsolation is difﬁcultUse mocks or ﬁxtures for data or external services

Where to test? High risk of failure High complexity Hard to test manually Less Tests More Tests

Test strategies 101

Don‘t test everythingTest the important stuff

Test every feature with one functional test (at least)

Reproduce bugs with tests(they won‘t come back)

oyment Deployment Deploy Deployment Deployment Deployment

Environments Integration Load-TestingLive Staging Development Development

Manual deployment# ssh testuser@my-staging-server.example.comuser123 $ cd /var/www/projectuser123 $ git pull --rebaseuser123 $ git submodule inituser123 $ git submodule updateuser123 $ rm -rf Data/Temporary/Productionuser123 $ ./flow3 doctrine:migrateuser123 $ ./flow3 cache:warmup# ssh user123@my-live-server1.example.comuser123 $ cd /home/myproject/public_htmluser123 $ git pull --rebaseuser123 $ git submodule inituser123 $ git submodule updateuser123 $ rm -rf Data/Temporary/Productionuser123 $ ./flow3 doctrine:migrateuser123 $ ./flow3 cache:warmup# ssh user123@my-live-server2.example.comuser123 $ cd /home/myproject/public_htmluser123 $ git pull --rebase Lot of workuser123 $ git submodule init Erroneoususer123 $ git submodule updateuser123 $ rm -rf Data/Temporary/Productionuser123 $ ./flow3 doctrine:migrateuser123 $ ./flow3 cache:warmup

AutomateddeploymentA custom script?Rollback on errors?Distributed deployment?

Meet Surf

Deployment with Surf SSH Node Surf CI Server / Node Dev Host Git Repositories Git

The Surf Model Deployment EnvironmentsWorkflow Deployment Application Code / Artifacts Node Node Server

Deployment process initialize Create release structure update Git update migrate Migration (e.g. Doctrine)Stages ﬁnalize Finalize release test Test release (smoke test) switch Publish release to live state cleanup Cleanup old releases

INFO Deploying vagrantINFO Using workflow "Simple workflow"DEBUG ====== Stage initialize ======DEBUG **** Node vagrant ****DEBUG * Application FLOW3 *DEBUG Executing stage "initialize" on "vagrant" for application FLOW3DEBUG Execute task "typo3.surf:createdirectories" on "vagrant" for application "FLOW3"DEBUG $vagrant: "test -d /home/planetflow3/deploy"DEBUG $vagrant: "mkdir -p /home/planetflow3/deploy/releases;mkdir -p /home/planetflow3/deploy/shared;mkdir -p /home/planetflow3/deploy/releases/20120331105449;cd /home/planetflow3/deploy/releases;ln -snf ./20120331105449 next"DEBUG Execute task "typo3.surf:flow3:createdirectories" on "vagrant" for application "FLOW3"DEBUG $vagrant: "mkdir -p /home/planetflow3/deploy/shared/Data/Logs;mkdir -p /home/planetflow3/deploy/shared/Data/Persistent;mkdir -p /home/planetflow3/deploy/shared/Configuration"DEBUG ====== Stage update ======DEBUG **** Node vagrant ****DEBUG * Application FLOW3 *DEBUG Executing stage "update" on "vagrant" for application FLOW3DEBUG Execute task "typo3.surf:gitcheckout" on "vagrant" for application "FLOW3"DEBUG $vagrant: "git ls-remote git://github.com/chlu/Planetflow3-Distribution.git refs/heads/master | awk {print $1 }"INFO > 7662553d5e666261a3a5bc2d6122096e7e21e40aDEBUG $vagrant: "if [ -d /home/planetflow3/deploy/cache/localgitclone ]; then cd /home/planetflow3/deploy/cache/localgitclone && git fetch -q origin && git reset -q --hard7662553d5e666261a3a5bc2d6122096e7e21e40a && git submodule -q init && for mod in `git submodule status | awk { print $2 }`; do git config -f .git/config submodule.${mod}.url `git config -f .gitmodules--get submodule.${mod}.url` && echo synced $mod; done && git submodule -q sync && git submodule -q update && git clean -q -d -x -ff; else git clone -q git://github.com/chlu/Planetflow3-Distribution.git /home/planetflow3/deploy/cache/localgitclone && cd /home/planetflow3/deploy/cache/localgitclone && git checkout -q -b deploy 7662553d5e666261a3a5bc2d6122096e7e21e40a && gitsubmodule -q init && git submodule -q sync && git submodule -q update; fi"INFO > synced Build/CommonINFO > synced Packages/Application/LibtextcatINFO > synced Packages/Application/Planetflow3INFO > synced Packages/Framework/Doctrine.CommonINFO > synced Packages/Framework/Doctrine.DBALINFO > synced Packages/Framework/Doctrine.ORMINFO > synced Packages/Framework/Symfony.Component.YamlINFO > synced Packages/Framework/TYPO3.FLOW3INFO > synced Packages/Framework/TYPO3.FluidINFO > synced Packages/Framework/TYPO3.PartyDEBUG $vagrant: "cp -RPp /home/planetflow3/deploy/cache/localgitclone/. /home/planetflow3/deploy/releases/20120331105449 && (echo 7662553d5e666261a3a5bc2d6122096e7e21e40a > /home/planetflow3/deploy/releases/20120331105449REVISION)"DEBUG Task "typo3.surf:flow3:symlinkdata" after "typo3.surf:gitcheckout" for application FLOW3DEBUG Execute task "typo3.surf:flow3:symlinkdata" on "vagrant" for application "FLOW3"DEBUG $vagrant: "mkdir -p /home/planetflow3/deploy/releases/20120331105449/Data;cd /home/planetflow3/deploy/releases/20120331105449;ln -sf ../../../shared/Data/Logs ./Data/Logs;ln -sf ../../../shared/Data/Persistent ./Data/Persistent"DEBUG Task "typo3.surf:flow3:symlinkconfiguration" after "typo3.surf:gitcheckout" for application FLOW3DEBUG Execute task "typo3.surf:flow3:symlinkconfiguration" on "vagrant" for application "FLOW3"DEBUG $vagrant: "cd /home/planetflow3/deploy/releases/20120331105449/Configuration;rm -f Production/*;rmdir Production;mkdir -p ../../../shared/Configuration/Production;ln -snf ../../../shared/Configuration/Production Production"INFO > rmdir: failed to remove `Production: No such file or directoryDEBUG ====== Stage migrate ======DEBUG **** Node vagrant ****DEBUG * Application FLOW3 *DEBUG Executing stage "migrate" on "vagrant" for application FLOW3DEBUG Execute task "typo3.surf:flow3:migrate" on "vagrant" for application "FLOW3"DEBUG $vagrant: "cd /home/planetflow3/deploy/releases/20120331105449 && FLOW3_CONTEXT=Production ./flow3 typo3.flow3:doctrine:migrate"

Deployment structure < Document Root

Deployment FeaturesClustered deploymentConﬁguration overridesSmoke testsCustom tasksFlexible workﬂows

?Questions?
