Chapter 8                                    Lecture                             Structure and Synthesis                  ...
Bonding in Ethylene  C=C bond is shorter than C—C bond  a) sp2 hybrid orbitals have _______ s character than the sp3  hybr...
Cis and trans isomers cannot be                interconverted without breaking the pi                         bond (264 kJ...
Elements (degrees) of Unsaturation. Also             called index of hydrogen deficiency.   • Unsaturation: A structural e...
• For each Group VA atom increase Hs in reference by one       • For each halogens decrease Hs atoms in reference by      ...
IUPAC and New IUPAC                                 In a ring the                                 double bond is          ...
Polyenes: se di-, tri-, tetra- before the ending -ene to specify how many double                                  bonds ar...
EZ nomenclature: Use the Cahn–Ingold–Prelog rules to assign priorities to  groups attached to each carbon in the double bo...
Heat of Hydrogenation can provide valuable data as to the stability of the   double bond. The more substituted the double ...
Stability: cis-2-butene<iso-butene<trans-2-butene                     -120 kJ >-117 kJ > -116 kJ    Cyclopropene is highly...
• Cis isomer is ______ stable than trans in small cycloalkenes.• Must have at least _________carbons to form a stable tran...
Bredt’s Rule: A bicyclic compound cannot have a double   bond at a bridgehead position unless one of the rings   contains ...
Summary stability          •    How is it quantitated?          •    Substitution          •    Stereochemistry          •...
Alkenes have relatively low boiling points which depend on       surface area and polarizability (______________ forces   ...
Alkene Synthesis                                     Overview    1. R-X ----E2 dehydrohalogenation (-HX) Alkene    2. R-X...
1. Dehydrohalogenationby the E2                   Mechanism   • Strong_________ abstracts H+ as double bond forms     and ...
Bulky Bases for E2 Reactions          • If the substrate is prone to substitution, a bulky base            can minimize th...
Hofmann Product         Bulky bases, such as potassium tert-butoxide, abstract the         least hindered H+,giving the le...
E2 Reactions Are Stereospecific: The stereochemistry of the      product depends on the stereochemistry of the reactant© 2...
Show that the dehalogenation of 2,3-dibromobutane by             iodide ion is stereospecific by showing that the two     ...
E2 Reactions of                  bromocyclohexane is slow        • An anti-coplanar conformation (180°) can only be       ...
Explain why the following deuterated 1-bromo-2-      methylcyclohexane undergoes dehydrohalogenation by the       E2 mecha...
2. Debrominationof Vicinal Dibromides: reduction             with iodide ion in acetone follows an an E2                  ...
3. E1 reaction  •     Tertiary reacts faster than secondary alkyl halides:  •     Carbocationintermediate; Rearrangements ...
4. Dehydration of Alcohols• Use concentrated H2SO4 or H3PO4 and remove low-boiling  alkene as it forms to shift the equili...
Dehydration Mechanism: E1  Step 1:Protonation of the hydroxyl group (fast equilibrium).    Step 2: Ionization to a carboca...
In acid-catalyzed mechanisms,                    the first step is often addition of                      H+, and the last...
Propose a mechanism for the sulfuric acid–catalyzed dehydration of t-butyl alcohol.   The first step is protonation of the...
Other Industrial methods:                        a) Catalytic Cracking of Alkanes  • Long-chain alkane is heated with a ca...
b) Dehydrogenation of Alkanes          • Dehydrogenation is the removal of H2 from a            molecule, forming an alken...
Methods to synthesize alkenes                                 Chapter 7   31© 2013 Pearson Education, Inc.
Upcoming SlideShare
Loading in...5
×

08 alkesynth

1,522

Published on

08 alkesynth

Published in: Education, Technology, Business
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
1,522
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
9
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

Transcript of "08 alkesynth"

  1. 1. Chapter 8 Lecture Structure and Synthesis of Alkenes Alkenes are also called olefins, meaning ―oil-forming gas. © 2013 Pearson Education, Inc.© 2013 Pearson Education, Inc.
  2. 2. Bonding in Ethylene C=C bond is shorter than C—C bond a) sp2 hybrid orbitals have _______ s character than the sp3 hybrid orbitals. They are __________ to the nucleus. b) Pi overlap brings carbon atoms _______ Bonding requires two p orbitals overlapping __________© 2013 Pearson Education, Inc. Chapter 7 2
  3. 3. Cis and trans isomers cannot be interconverted without breaking the pi bond (264 kJ/mole). No rotation around the carbon–carbon bond is possible giving rise to Cistrans geometric isomers© 2013 Pearson Education, Inc. Chapter 7 3
  4. 4. Elements (degrees) of Unsaturation. Also called index of hydrogen deficiency. • Unsaturation: A structural element that decreases the number of hydrogens in the molecule by two. • Double bonds and rings are elements of unsaturation (can not distinguish with calculation Calculate the degrees of unsaturation for a compound with formula C5H8 and propose a structure • Reference (saturated compound CnH2n+2) • Compound© 2013 Pearson Education, Inc. Chapter 7 4
  5. 5. • For each Group VA atom increase Hs in reference by one • For each halogens decrease Hs atoms in reference by one • Group of oxygen does not change the C:H ratio, ignore oxygen in the reference formula. Calculate the IHD for a Compound with Formula C4H7Br. C6H7N. C5H4O.© 2013 Pearson Education, Inc. Chapter 7 5
  6. 6. IUPAC and New IUPAC In a ring the double bond is given carbon 1 and carbon 2.© 2013 Pearson Education, Inc. Chapter 7 6
  7. 7. Polyenes: se di-, tri-, tetra- before the ending -ene to specify how many double bonds are present. Give the double bonds the lowest numbers possible.© 2013 Pearson Education, Inc. Chapter 7 7
  8. 8. EZ nomenclature: Use the Cahn–Ingold–Prelog rules to assign priorities to groups attached to each carbon in the double bond. If high-priority groups are on the same side, the name is Z (for zusammen). If high-priority groups are on opposite sides, the name is E (for entgegen). E-1-bromo-1-chloropropene© 2013 Pearson Education, Inc. Chapter 7 8
  9. 9. Heat of Hydrogenation can provide valuable data as to the stability of the double bond. The more substituted the double bond, the ___________its heat of hydrogenation.© 2013 Pearson Education, Inc. Chapter 7 9
  10. 10. Stability: cis-2-butene<iso-butene<trans-2-butene -120 kJ >-117 kJ > -116 kJ Cyclopropene is highly strained. Rings that are five-membered or larger can easily accommodate double bonds, and these cycloalkenes react much like straight-chain alkenes.© 2013 Pearson Education, Inc. Chapter 7 10
  11. 11. • Cis isomer is ______ stable than trans in small cycloalkenes.• Must have at least _________carbons to form a stable trans double bond.• For cyclodecene (and larger), the trans double bond is almost as stable as the cis.• All cycloalkenes are assumed to be cis unless otherwise specifically named trans.© 2013 Pearson Education, Inc. Chapter 7 11
  12. 12. Bredt’s Rule: A bicyclic compound cannot have a double bond at a bridgehead position unless one of the rings contains at least eight carbon atoms. Which of the following alkenes are stable?© 2013 Pearson Education, Inc. Chapter 7 12
  13. 13. Summary stability • How is it quantitated? • Substitution • Stereochemistry • Ring size • Cisvs trans cyclos • Bredt’s rule Chapter 7 13© 2013 Pearson Education, Inc.
  14. 14. Alkenes have relatively low boiling points which depend on surface area and polarizability (______________ forces _______ dense than water _________ on water Slightly polar:  Pi bond is polarizable, so instantaneous dipole– dipole interactions occur.  Alkyl groups are electron-donating toward the pi bond, so may have a small dipole moment. • Cisalkenes have a greater dipole moment than trans alkenes, so they will be slightly polar and have higher bp© 2013 Pearson Education, Inc. Chapter 7 14
  15. 15. Alkene Synthesis Overview 1. R-X ----E2 dehydrohalogenation (-HX) Alkene 2. R-X ----E1 dehydrohalogenation (-HX) Alkene 3. Vic dibromide---Dehalogenation (-X2) Alkene 4. Alcohol ---Dehydration (-H2O) Alkene© 2013 Pearson Education, Inc. Chapter 7 15
  16. 16. 1. Dehydrohalogenationby the E2 Mechanism • Strong_________ abstracts H+ as double bond forms and X- ___________ from the adjacent carbon. • __________ and hindered ______________ alkyl halides give alkenes in good yields.Tertiary halides are the best E2 substrates because they cannot undergo __________substitution.© 2013 Pearson Education, Inc. Chapter 7 16
  17. 17. Bulky Bases for E2 Reactions • If the substrate is prone to substitution, a bulky base can minimize the amount of substitution. • Large alkyl groups on a bulky base hinder its approach to attack a carbon atom (substitution), yet it can easily abstract a proton (elimination).© 2013 Pearson Education, Inc. Chapter 7 17
  18. 18. Hofmann Product Bulky bases, such as potassium tert-butoxide, abstract the least hindered H+,giving the less substituted alkene as the major product (Hofmann product).© 2013 Pearson Education, Inc. Chapter 7 18
  19. 19. E2 Reactions Are Stereospecific: The stereochemistry of the product depends on the stereochemistry of the reactant© 2013 Pearson Education, Inc. Chapter 7 19
  20. 20. Show that the dehalogenation of 2,3-dibromobutane by iodide ion is stereospecific by showing that the two diastereomers of the starting material give different diastereomers of the product. Rotating meso-2,3-dibromobutane into a conformation where the bromine atoms are anti and coplanar, we find that the product will be trans-2-butene. A similar conformation of either enantiomer of the (±) diastereomer shows that the product will be cis-2-butene. (Hint: Your models will be helpful.) Meso-2,3-dibromobutane (R,R)-2,3-dibromobutane© 2013 Pearson Education, Inc. Chapter 7 20
  21. 21. E2 Reactions of bromocyclohexane is slow • An anti-coplanar conformation (180°) can only be achieved when both the hydrogen and the halogen occupy ___________ positions. • The chair must flip to the conformation with the axial halide in order for the elimination to take place.© 2013 Pearson Education, Inc. Chapter 7 21
  22. 22. Explain why the following deuterated 1-bromo-2- methylcyclohexane undergoes dehydrohalogenation by the E2 mechanism, to give only the indicated product. Two other alkenes are not observed. In an E2 elimination, the hydrogen atom and the leaving group must have a trans-diaxial relationship. In this compound, only one hydrogen atom—the deuterium—is trans to the bromine atom. When the bromine atom is axial, the adjacent deuterium is also axial, providing a trans-diaxial arrangement.© 2013 Pearson Education, Inc. Chapter 7 22
  23. 23. 2. Debrominationof Vicinal Dibromides: reduction with iodide ion in acetone follows an an E2 mechanism© 2013 Pearson Education, Inc. Chapter 7 23
  24. 24. 3. E1 reaction • Tertiary reacts faster than secondary alkyl halides: • Carbocationintermediate; Rearrangements are possible. • Solvolysis reactions in solvents as water or alcohols • Usually have SN1 products, too, since the solvent can attack the carbocation directly.© 2013 Pearson Education, Inc. Chapter 7 24
  25. 25. 4. Dehydration of Alcohols• Use concentrated H2SO4 or H3PO4 and remove low-boiling alkene as it forms to shift the equilibrium and increase the yield of the reaction.• E1 mechanism.• Carbocation intermediate. Rearrangements can occur.• Reaction obeys Zaitsev’s rule.© 2013 Pearson Education, Inc. Chapter 7 25
  26. 26. Dehydration Mechanism: E1 Step 1:Protonation of the hydroxyl group (fast equilibrium). Step 2: Ionization to a carbocation (slow; rate limiting). Step 3: Deprotonation to give the alkene (fast).© 2013 Pearson Education, Inc. Chapter 7 26
  27. 27. In acid-catalyzed mechanisms, the first step is often addition of H+, and the last step is often loss of H+.© 2013 Pearson Education, Inc. Chapter 7 27
  28. 28. Propose a mechanism for the sulfuric acid–catalyzed dehydration of t-butyl alcohol. The first step is protonation of the hydroxyl group, which converts it to a good leaving group. The second step is ionization of the protonated alcohol to give a carbocation. Abstraction of a proton completes the mechanism.© 2013 Pearson Education, Inc. Chapter 7 28
  29. 29. Other Industrial methods: a) Catalytic Cracking of Alkanes • Long-chain alkane is heated with a catalyst to produce an alkene and shorter alkane. • Complex mixtures are produced.© 2013 Pearson Education, Inc. Chapter 7 29
  30. 30. b) Dehydrogenation of Alkanes • Dehydrogenation is the removal of H2 from a molecule, forming an alkene (the reverse of hydrogenation). • This reaction has an unfavorable enthalpy change but a favorable entropy change.© 2013 Pearson Education, Inc. Chapter 7 30
  31. 31. Methods to synthesize alkenes Chapter 7 31© 2013 Pearson Education, Inc.
