  • The European Geostationary Navigation Overlay Service (EGNOS) is Europe’s first venture into satellite navigation. It augments the two military satellite navigation systems now operating, the US GPS and Russian GLONASS systems, and makes them suitable for safety critical applications such as flying aircraft or navigating ships through narrow channels.   Consisting of three geostationary satellites and a network of ground stations, EGNOS achieves its aim by transmitting a signal containing information on the reliability and accuracy of the positioning signals sent out by the Global Positioning System (GPS) and the Global Orbiting Navigation Satellite System (GLONASS). It allows users in Europe and beyond to determine their position to within 2 metres, compared with about 20 metres for GPS and GLONASS alone.
  • GSTB V1 objectives GPS measurements collected world-wide by a network of stations and processed off-line to verify GALILEO Timing, Navigation and Integrity concepts Successful completion in December 2004 with the provision of validated prototype algorithms and models to the Ground Mission Segment IOV Phase CDE1 Contract GSTB V2 objectives Experimental GALILEO Satellite programme Precursor of the IOV Phase Securing GALILEO filings and validating on-board technology in the MEO radiation environment IOV Objectives Verification of all space, ground and user components, including their interfaces, prior to full system deployment Analysis of system performance with the view to refine the FOC system prior to full system deployment Verification of the adequacy of the siting requirements Verification of Navigation Processing Verification of integrity processing regarding the establishment of SISA and IF confidence levels, characterisation of feared events and TTA analysis UERE budget characterisation Deployment risk reduction Verification of operational procedures FOC
  • Mapping segment entry positive feedbacks at Intergeo event from Users and GNSS opinion leader (GPS World Editor) Slide 10

EGNOS growing market in Agriculture and fostering new opportunities in Mapping EGNOS growing market in Agriculture and fostering new opportunities in Mapping Presentation Transcript

  • EGNOS: Growing market in Agriculture and fostering new opportunities in Mapping GeoFARMatics, Cologne, 25 November 2010 Reinhard Blasi, Market Development Officer European GNSS Agency, GSA
    • Satellite Based Augmentation System (SBAS)
    • Measures GPS performance
    • Sends corrections to users via satellite or terrestrial links (EDAS)
    • Covers most of EU
    • Expansion to Africa, Middle East and Eastern Europe planned
    • Officially operational since 2009
    • Certified for Safety Of Life by 2010
    • Global Navigation Satellite Systems (GNSS)
    • Compatible with most other GNSS
    • Inter-operable with GPS
    • 2 prototypes launched (GIOVE)
    • 4 IOV satellites planned
    • Operational system planned for 2014
    • Will support 5 services
    The European Satellite Programme: EGNOS/EDAS and Galileo
  • EGNOS System Architecture and Service Area EGNOS Service Area EGNOS Satellite Footprints 3 GEO Satellites 2 Support Facilities 6 Navigation Land Earth Stations GPS signals 34 Ranging & Integrity Monitoring Stations (RIMS) 4 Mission Control Centres
    • Soon to be replaced by
    • ASTRA SIRIUS 5
    • ASTRA 5B
    • 3 Geostationary satellites
    • INMARSAT 3F2 AOR-E (15.5°W)
    • ARTEMIS (21.3°E)
    • INMARSAT 4F2
  • Galileo implementation plan
  • High precision sensitive markets Users communities AGRICULTURE SURVEYING MAPPING CONSTRUCTION MINING Main applications
      • Machine guidance
      • Autonomous machine guidance
      • Asset tracking
      • Machine guidance
      • Autonomous machine guidance
      • Asset tracking
      • Metrology
      • Seismology
      • Cadastral surveying
      • GIS
      • Utilities (e.g., electric networks)
      • Municipality (e.g., forestry)
      • Truck dispatch
      • 3D positioning of mine machinery
      • Autonomous mining vehicles
    MACHINE CONTROL SURVEYING & MAPPING Relevance of EGNOS augmentation services
  • Agri Mapping
  • Agri Mapping
  • L EGNOS “ Precision Agriculture is about doing the right thing, in the right place, in the right way, at the right time” EGNOS: the most affordable solution for a wide range of applications c.1m Low-value crop cultivation (e.g. cereals) Low-accuracy operations (fertilising and reaping) c.2.5m Field measurement Boundary mapping and updating Legislation/ management c.2.5m Land parcel identification/ geo-traceability Post harvest pick-up Supervised tracking of livestock, manure, etc. Agro-logistics 2-5m Individual livestock positioning and virtual fencing Dairy c.2cm High-value crop cultivation (potatoes, vegetables) Precision operations (sowing and transplanting) Arable Required accuracy level Application field Application category
  • Why EGNOS in Agriculture? High Precision, Low Cost Link to Video of EGNOS in Agriculture
  • 0 GNSS-equipped tractors forecast (2009E-12F) 09E Thousands of units 12F 11F 10F Rest of the World Europe 78% 23% GNSS cumulated revenues 2010-2030 Total = €20 billion 8% of tractors are equipped with a GNSS device in EU Expected 13% in 2013 The number of GNSS devices in precision agriculture is increasing fast
    • No installation costs neither annual subscription costs are required
    EGNOS is the best GNSS technology to be applied on a 16 HA farm: on average European farms are 16 HA wide EGNOS is free EGNOS is widely available all over Europe EGNOS is convenient
    • 1 on 10 tractors in Europe are equipped today with GNSS receivers, most of them are EGNOS enabled
    • The application of EGNOS involves:
      • 2,36% reduction in time, fuel and seed quantity
      • 2,49% reduction in fertilize and Plant Production Products quantities
    A practical example
  • Promotion Partnership with industry players Leverage Framework Programme Test and exploit new service (EDAS) “ Harvesting” EGNOS potential
  • Service Providers Application providers Tractor Manufacturers Device Vendors Co-marketing with EGNOS market players to support EGNOS introduction CBA to support adoption decision and quantify the benefits Leading industry players have already bet on EGNOS
  • MowBySat ; GNSS in domestic robots to achieve greater precision at low cost. I2GPS: SAR calibrator with GNSS receiver for precision studies of geodynamics GOLDEN-ICE : improvinG the efficiency Of saLt-spreaDing (de-icing) sErvices and emergeNcy call management on wInter professional vehiCles using EGNOS ASPHALT: High precision applications in road construction, fleet management and logistics using EGNOS just-in-time process chain. FIELDFACT: Promoting the benefits and opportunities of GNSS in agriculture. 1 st Call 2 nd Call R&D fill technical gaps and pave the way to adoption in High Precision
  • Agri Mapping
  • GNSS provides an efficient technology for mapping and are widely used by organisations such as utility companies as well as regional and local authorities. The use of GNSS in mapping often means services with centimetre level accuracy and substantial costs (e.g., infrastructure, equipment, software, service). Now EGNOS can contribute in growing the use of GNSS in real time EGNOS and Mapping - providing free accuracy that is widely available
  • For many mapping applications meter level accuracy is sufficient Applications such as thematic mapping for small and medium municipalities, forestry and park management as well as surveying of utility infrastructures can benefit from EGNOS. Most of the devices used for mapping are already EGNOS-ready. Thus, EGNOS also allows more and more non-professionals to access GNSS mapping technologies. Free accuracy…
    • EGNOS with constant level of position
    • accuracy throughout most of Europe.
    • EGNOS corrections can be received via
    • different means:
    • directly via EGNOS satellites without any communication costs
    • via terrestrial communication means such as internet or cellular networks, thanks to EDAS, the EGNOS Data Access Service.
    • EDAS is the single point of access for the
    • data generated and collected by EGNOS.
    • EDAS is freely available and currently in a
    • test service phase.
    ... widely available Southern Europe/MEDA Middle-East Northern & Eastern Europe
  • ... widely available
    • EGNOS with constant level of position
    • accuracy throughout most of Europe.
    • EGNOS corrections can be received via
    • different means:
    • directly via EGNOS satellites without any communication costs
    • via terrestrial communication means such as internet or cellular networks, thanks to EDAS, the EGNOS Data Access Service.
    • EDAS is the single point of access for the
    • data generated and collected by EGNOS.
    • EDAS is freely available and currently in a
    • test service phase.
    Southern Europe/MEDA Middle-East Northern & Eastern Europe
  • Mapping: a new promising EGNOS segment “ GSA folks provide a dynamic and effective service in educating the community of ground users (…) Yes, my European brethren, EGNOS can be used reliably for sub-meter mapping.” Eric Gakstatter GPS World Editor Survey & Construction “ We think EGNOS can play a role in the Mapping sector and are happy to help exploring this by promoting the GSA-survey amongst our partners across Europe.” Jean-Yves Pirlot President of the Council of the European Geodetic Surveyors
    • Positioning, delivering 50 cm - 1m accuracy, is well received already at launch (INTERGEO)
    • Device manufacturers give positive feedback
    • Users, i.e. Surveyors, municipalities…, show strong interest
    • Experts confirm SBAS is used for sub-meter mapping in US, with similar potential in EU
    Eric Gakstatter GPS World Editor Survey & Construction Jean-Yves Pirlot President of the Council of the European Geodetic Surveyors
  • EGNOS is… … an effective option for a wide range of mapping applications with meter accuracy … free; it does not require installation of hardware nor ongoing subscriptions. … in most of the new GNSS devices … covers the majority of Europe - no white spots … permitting real time positioning. … thanks to EDAS, also receivable by terrestrial communication means, (e.g., internet or GPRS) … providing system integrity, supplying information on the reliability of GPS signals. In summary: why EGNOS? EGNOS is Europe’s first venture into the field of GNSS and a precursor to Galileo, Europe’s global satellite navigation system, currently under development. EGNOS is an open system, now operational and available for use.
  • Final Proposal Evaluation Ranking & decision Negotiations Project Start Stage 1 proposal (SME) Stage 1 evaluations (SME) Oct 5 th End Oct 16 Dec or 13 Jan 14 Feb Mid April Overall, about 30 mio € for innovative ideas… For more information on Europe´s FP7-Programme, visit: www.gsa.europa.eu The EU-Framework Programme for EGNOS and Galileo: from proposal to project
    • Reinhard Blasi
    • Market Development Officer
    • European GNSS Agency
    EGNOS, it’s there. Use it. www.egnos-portal.eu Navigation solutions powered by Europe THANK YOU FOR YOUR ATTENTION
