Phil Trinder &  Computer Science Department Heriot-Watt University, UK David King Software & Systems Engineering Research ...
High-Level Techniques for Distributed Telecoms Software <ul><li>EPSRC (UK Govt) Project, Dec 2002 – Feb 2006 </li></ul><ul...
High-Level Techniques for Distributed Telecoms Software <ul><li>EPSRC (UK Govt) Project, Dec 2002 – Feb 2006 </li></ul><ul...
Erlang Comparisons <ul><li>A number of sequential comparisons, e.g. Computer Language Shootout </li></ul><ul><li>Very few ...
Research Questions: Potential Benefits <ul><li>RQ1: Can robust, configurable systems be readily developed? </li></ul><ul><...
Research Questions: Feasibility <ul><li>High-level distributed languages: </li></ul><ul><li>abrogate control of low-level ...
Research Strategy <ul><li>Reengineer some telecoms application components in GdH and Erlang </li></ul><ul><ul><li>Dispatch...
1 st  Component Engineered:  Data Mobility Component (DM) <ul><li>Product Component </li></ul><ul><li>Communicates with Mo...
2 nd  Component Engineered:  Despatch Call Controller (DCC) <ul><li>Handles mobile phone calls </li></ul><ul><li>A process...
Two Erlang DM Implementations <ul><li>1. Pure Erlang DM </li></ul><ul><li>2. Erlang/C DM </li></ul><ul><li>reuses some C D...
RQ3 Performance 1: Throughput <ul><li>Maximum DM Throughput at 100% QoS </li></ul><ul><li>Platform: 167MHz, 128Mb Sun Ultr...
RQ3 Performance 1: Throughput <ul><li>Maximum DM Throughput at 100% QoS </li></ul><ul><ul><li>Pure Erlang DM is  twice as ...
Performance 2: Round Trip Times Pure Erlang is approximately  3 times faster Erlang/C is  26% - 50% slower ms
Performance Analysis <ul><li>Pure Erlang DM is faster due to fast lightweight process management </li></ul><ul><li>Erlang/...
Performance 3: Memory Residence <ul><li>Erlang DMs use 170% more memory </li></ul><ul><li>Erlang runtime sys (ERTS) has a ...
RQ1 Robustness 1: Resilience Load (queries/s) Throughput (queries/s)
RQ1 Robustness 1: Resilience <ul><li>When overloaded:  </li></ul><ul><li>C++ DM fails catastrophically  </li></ul><ul><li>...
DCC Resilience
Robustness 2: Availability <ul><li>Erlang systems  </li></ul><ul><li>remain available despite repeated hardware & software...
Robustness 2: Availability <ul><li>Erlang Systems resists the simultaneous failure of multiple components </li></ul><ul><l...
Robustness 3: Dynamic Configurability <ul><li>Erlang Systems dynamically adapt to the available hardware resources. </li><...
RQ2: Productivity & Maintainability <ul><li>Shorter programs are </li></ul><ul><li>Faster to develop </li></ul><ul><li>Con...
Productivity: Source Code Sizes DM Implementations DCC Implementations Erlang DCC and DM are less than 1/3 rd  of size of ...
<ul><li>Erlang/C DM is 1/3rd of the size of the C++ DM </li></ul><ul><li>Pure Erlang DM is 1/7th of the size of the C++ DM...
Reasons for difference in Code Size <ul><li>Erlang programmers can </li></ul><ul><ul><li>rely on fault tolerance and code ...
DM Code Breakdown
Code Difference Example void DataMobilityRxProcessor::processUnsupVer(void) { MSG_PTR  msg_buf_ptr;  MM_DEVICE_INFO_MSG  *...
Erlang DCC Reusability Considerable potential for reuse 36% 11 1741 Testing/Stat.s 3% 1 147 Specific Services 61% 26 2994 ...
Summary <ul><li>Investigated high-level distributed language technology for telecoms software </li></ul><ul><li>Reengineer...
RQ1: Robust & Configurable Systems <ul><li>Improved resilience:  </li></ul><ul><ul><li>Erlang DM and DCC sustain throughpu...
RQ2: Productivity & Maintainability <ul><li>Erlang DM and DCC: </li></ul><ul><ul><li>Less than 1/3 rd  size of C++  implem...
RQ3: Distributed Functionality <ul><li>Even though Erlang abstracts over low-level coordination, the required DM and DCC f...
RQ4: Performance <ul><li>Time: </li></ul><ul><ul><li>Max. throughput at 100% QoS: </li></ul></ul><ul><ul><ul><li>Pure Erla...
RQ5: Interoperation Costs <ul><li>Erlang DMs interoperate with a C test harness, and Erlang/C DM incorporates C drivers & ...
RQ6: Pragmatics <ul><li>Erlang is available on several HW/OS platforms, including the Sun/Solaris DM product platform </li...
Conclusions <ul><li>Erlang offers robustness & productivity benefits for distributed telecoms software (RQs 1 & 2) </li></...
Further Information <ul><li>Web sites/Seminars </li></ul><ul><li>Erlang Site:  www.erlang.org/ </li></ul><ul><li>Project S...
