Crowdsourcing, Collaborations And Text Mining In A World Of Open Chemistry Crowdsourcing, Collaborations And Text Mining In A World Of Open Chemistry Presentation Transcript

  • Crowdsourcing, Collaborations and Text-Mining in a World of Open Chemistry Antony Williams
  • Imagine a time when ….
    • The internet is searchable by chemical structure and substructure (e.g.Wikipedia, Google Scholar)
    • Chemistry articles are indexed and searchable by a free online service
    • Publicly funded research data can be shared and discussed in the Open, maybe as ONS?
    • Cheminformatics has as much of a public face as bioinformatics and protectionism of data related to “structures” has waned
  • ChemSpider - A Search Engine for Chemists
    • Questions a chemist might ask…
      • What is the melting point of n-butanol?
      • What is the chemical structure of Xanax?
      • Chemically, what is phenolphthalein?
      • What are the stereocenters of cholesterol?
      • Where can I find publications about xylene?
      • What are the different trade names for Ketoconazole?
      • What is the NMR spectrum of Aspirin?
      • What are the safety handling issues for Thymol Blue?
      • ChemSpider can answer all of these questions
  • ChemSpider Data Content
    • Over 21.5 million unique chemical structures from ca. 150 data sources
      • Online Databases –PubChem, Drugbank, KEGG, Wikipedia
      • Literature – PubMed, J Het Chem, Nature, RSC, Open Access
      • Chemical Vendors – over 40 different vendors and growing
      • Personal Depositions – individual contributions
      • Content database vendors
      • Analytical data collections
      • Patents
      • Web scraping
      • Content is linked back to the original data sources
  • Tell me about Aspirin
  • Tell me about Aspirin
  • Link outs
  • Links out to KEGG Kyoto Encyclopedia of Genes and Genomes
  • Tell me about Aspirin
  • Tell me About Aspirin
  • Tell me about Aspirin
  • Tell me about Aspirin
  • Tell me about Aspirin
  • Text- Indexing and ChemSpider?
    • ChemSpider text-indexes almost 500,000 Open Access and Free Access articles
    • Collection is growing and more publishers have already agreed. Including theses in the future.
  • Open Access Literature Search
  • Search PubMed – ChemSpider
  • Other Searches
    • What compounds have a mass of 300+/-0.001?
    • or search a combination of intrinsic/predicted properties
  • Other Searches
  • Complex Search
  • The Quality of Data Online…
    • Aggregating data opens up quality issues
    • Structure-identifier associations are “dirty”
    • Structures are COMMONLY incorrect
    • Manual curation of small databases is enough work – what about millions of structures?
    • Structures are far from perfect. What is a “correct structure”?
      • Full stereochemistry?
      • Historical timeline of structure?
      • Who is the authority?
  • Who holds THE Quality Authority?
    • Chemical Abstracts Service is the structural authority today. 1400 (?) employees, world standard in chemistry information
    • 101 years of knowledge, process and expertise.
    • MANUAL curation is key. Robotic curation is enabling – Chloride with no Cl
    • How can an online, free access system peacefully co-exist with the authority?
  • Quality is a Major Issue- Search Butanol OLD EXAMPLE..now fixed
  • Wikipedia Chemistry Curation project
    • Only ca. 5000 organic structures, 7000 total structures
    • Almost a year of work so far for a team of 6 people
    • Many errors removed in the process. Curation process is a daily event for users/depositors
    • Slow and torturous process
    • http://en.wikipedia.org/wiki/Talk:Tacrolimus#IUPAC_Name_and_structure
  • Wikipedia Curation
    • Looking for self-consistency across a Wikipedia Page
    • Primary key is the article TITLE
    • The chemical shown needs to match the title – then registry numbers, names, identifiers, outlinks need to match the chemical shown.
    • Cyclic self-consistency – and decisions must get made
  • Viagra
    • Viagra is sildenafil…
  • Viagra is Sildenafil Citrate
    • Sildenafil may be shown in the Wikipedia record but their might be a redirect from a search on Viagra
    • CAS registry Number: 139755-83-2, 171599-83-0 (as citrate). If structure box shows neutral compound then CAS Number must match neutral compound OR annotate
  • Other issues…
    • If structure shows no stereo then don’t put stereo in name
    • Outlinks to external databases – links should be structure to structure not name to name
    • Tautomers
  • Charges
  • Sugars – Machine Readable vs Aesthetics Fischer Stereo Haworth
  • Wikipedia – Crowdsourcing Chemistry
  • Thymol Blue on ChemSpider
    • Data online includes:
      • UV-vis spectrum
      • Measured experimental properties
      • Link to Wikipedia article
      • Links to chromatography details
      • Multiple identifiers/trade names etc.
      • Links to vendors/suppliers/other databases
      • Safety information
      • http://www.chemspider.com/q/thymol%20blue
  • Differences between ChemSpider/Wikipedia No, but links. Analytical Data Active editors > 50 (?) Active depositors/curators – 30 No Prediction of properties ???? 6000 people/day; 1900 registered Detailed compound monographs Compound monographs linked Text Complex queries – Properties, Text, structure/substructure, OA publishers, Data Sources, … ~5000 organics, 2000 others >21 million unique structures Wikipedia ChemSpider
  • Differences between Wikipedia/ChemSpider Growing reputation as focused on quality Worldwide reputation as quality source – good and bad Chemistry is the focus of ‘Spider Chemistry is a subset of the ‘Pedia Mixed “licensing” GFL licensing for everything Growing team of advocates, curators and users Strong team of WP:Chem advocates, curators and admins “ Out of a basement” on three servers and 5 volunteers Established infrastructure and Wikipedia Foundation Team Primarily Microsoft .NET technologies with OS components Supported by tried and tested Media-Wiki platform. ChemSpider Wikipedia
  • Usage Growth – Representative Plot
  • Crowd-sourcing Curation
    • How to curate data for millions of structures?
    • Robot processes can clean up depositions
      • Search for Chloride and check molecular formula for Cl
      • Check for stereochemistry and remove names with stereo
    • Provide a simple-to-use platform to curate, annotate and tag data
    • Provide curator administration to prevent vandalism (Veropedia)
  • Multi-level Curation and Approval
  • Post Comments
    • Anyone can “Post Comments” associated with a structure. To curate data we require login to track
  • Crowd-sourcing Chemistry
    • Crowd-sourced curation: identify and tag errors, edit names, synonyms, identify records for deprecation
    • ALSO
    • Crowd-sourced deposition: anyone can deposit data (structures, text, images, analytical data)
  • Structure-Centric
    • We want to search Open-Access articles by structure, substructure, similarity of structure
    • Standard approaches would be:
      • Identify chemical names “entity extraction”
      • Convert chemical names to structures and index
    • ChemSpider has a validated dictionary of structure-name pairs
    • Use name extraction, name-conversion and dictionary look-up. THEN curate.
  • “Entity Extraction”
    • Rule-based recognition of systematic names:
      • Use a lexeme of name fragments
      • Rules for identifying bounds of a name
    • Look-up dictionary:
      • Drug Names
      • Trivial Names
      • Numbers : Registry IDs, EINECS/ELINCS/Beilstein IDs
      • Massive look-up dictionary of validated identifiers on ChemSpider
  • Name-to-Structure and Lexemes
  • Name Recognition
    • Azo aldehyde 2   was  synthesized according to a reported  method [17]. To  a stirred  solution  of azo aldehyde 2   (1.08 g, 3.76 mmol )  in  dry CH2Cl2  (30.00 mL) at  0 oC  were  successively  added (3,4-diaminophenyl)phenyl methanone 1 (0.40 g, 1.88 mmol) and a excces of anhydrous MgSO4 (2.00 g,16.67 mmol) .
    • The resulting  mixture  was  stirred  for  6 hours  at room temperature [18]. The mixture was  filtered and washed with dichloromethane . Then the solvent was  evaporated under reduced pressure to  give azo Schiff base 3   as a red solid which was recrystalized from ethanol 95%    (1.28 g, 91 %)
  • Name Recognition
    • Azo aldehyde 2   was  synthesized according to a reported  method [17]. To  a stirred  solution  of azo aldehyde 2   (1.08 g, 3.76 mmol )  in  dry CH2Cl2   (30.00 mL) at  0 oC  were  successively  added  (3,4-diaminophenyl)phenyl methanone 1 (0.40 g, 1.88 mmol) and a excess of anhydrous MgSO 4 (2.00 g,16.67 mmol) .
    • The resulting  mixture  was  stirred  for  6 hours  at room temperature [18]. The mixture was  filtered and washed with dichloromethane . Then the solvent was  evaporated under reduced pressure to  give azo Schiff base 3   as a red solid which was recrystalized from ethanol 95%    (1.28 g, 91 %)
  • How Many Chemical Names?
    • “ She had the drive to derive success in any venture and was well versed in Karate. When the man in the tartan shirt approached her with a dagger in his hand she spat in his face, took the stance of a commando and took advantage of his shock to release the dagger from his grip and causing him to recoil. He went home and took an aspirin after the beating.”
  • How Many Chemical Names?
    • “ She had the drive to derive success in any venture and was well versed in Karate . When the man in the tartan shirt approached her with a dagger in his hand she spat in his face, took the stance of a commando and took advantage of his shock to release the dagger from his grip and causing him to recoil . He went home and took an aspirin after the beating.”
  • ChemMantis
    • Chem ical M arkup A nd N omenclature T ransformation I ntegrated S ystem
  • Making Open Access Articles Searchable Proof of Concept
    • Can we HOST Chemistry Open Access articles on ChemSpider and add-value
    • Can we identify chemical names in Open Access articles in a user-friendly manner
    • Can we convert names to structures in Open-Access articles and expand ChemSpider and provide structure searching of Open Access chemistry articles?
    • Can we provide an environment for chemists to mark-up their own articles and crowd-source markup of an archive?
  • Document markup
    • ChemSpider now hosting Open Access articles from MDPI, Molecular Diversity Preservation International
    • Hosting the Molbank collection at present
  • A Standard for Document Markup?
    • NLM-DTD: National Library of Medicine; Document Type Definition
    • Approved markup definitions to apply to journal articles – extended as necessary for our purposes
  • NLM/DTD markup
  • Chemistry and Biology
    • Menus can be extended as necessary
  • Document markup
  • Markup – 3 seconds!
  • On the fly conversion
  • Shorthand Formulae Supported
  • Curators Tools During Markup
  • One Click to more Info…
  • Coming Soon….
  • Structure Image Conversion
  • Two Seconds Later
  • Not Always Perfect….
  • A Platform for Markup
    • Can we provide a platform for document markup for chemists?
    • Workflow:
      • Upload word docs, RTF files or point to HTML and load
      • Apply entity extraction, convert names to structures, mark-up automatically and ask for user participation
      • Publish final version with NLM-DTD markup
      • Deposit all structures on ChemSpider under embargo and wait for article DOI to release
  • Challenges
    • Computer software can generate chemical names better than the majority of chemists
    • The majority of chemical names are generated by humans, and Incorrect – convert to the wrong structure or are ambiguous
    • One name, Multiple Structures
  • Names and Structures
    • Dichloroacetone
    • Trichloromethylsilane
  • Ambiguity
  • Ambiguity in Abbreviations - DPA
  • Ambiguity in Abbreviations - THF
  • Import is Easy
    • Make articles Public/Private (embargo date soon)
    • Auto-markup and check by user
  • IUPAC PAC Articles
  • Supports Word .DOC, HTML, RTF
  • Drexel University Documents
  • Drexel University Documents
  • Drexel University Documents
  • Patents
  • Organism Markup
  • Extensible Markup Process
    • Markup process is easily extendable
    • Configurable from one XML file
    • NLM/DTD is incorporated but is easy to extend
  • Markup Movie
  • DailyMed
  • DailyMed on ChemSpider
  • Quality of Structures!!!
  • Quality of Structures
  • DailyMed
  • Remaining Issues in Markup
    • Ongoing curation of look-up dictionaries – one name linked to multiple structures…which is right? Remember tautomers!
    • Import and markup of large documents – tested up to 2Mbyte. Needs extending for larger documents
    • Add comments/tags to documents where markup finds issues.
  • Oops…
    • Online document markup and indexing is a very disruptive offering and a natural extension for ChemSpider
  • What’s Coming?
    • Agreement with Royal Society of Chemistry that we can add their structure-based RSS feeds to ChemSpider
    • Agreement with Nature Publishing Group to add their Nature Chemical Biology structure collections to ChemSpider as they issue
    • Presently indexing Acta Chemica Scandanavica, 1947-1999 PDF backfile – our first foray into OCR
    • Presently indexing PLoS journals directly
    • More publishers have agreed…
  • What’s Coming?
    • Now working on “organism” extraction in document markup to identify organisms and link out to external resources – bacteria, fungi, viruses
    • Open platform for users to deposit and markup their documents
    • Export the markup in XML format and then map to the NLM-DTD
    • Extract machine-readable structures directly
  • Conclusions
    • The quality of structure-based data online should always be questioned – that includes ChemSpider
    • Robots and software algorithms can help but eyeballs are necessary
    • Data on ChemSpider are being added and curated on a daily basis but we need more eyeballs helping always
    • ChemSpider now has a large validated structure-name dictionary
    • Chemical name extraction and document markup is very enabling
  • Further reading
    • www.chemspider.com/blog
    • Internet-based tools for communication and collaboration in chemistry, Drug Discovery Today, Volume 13, Numbers 11/12, June 2008 502-506, doi:10.1016/j.drudis.2008.03.015
    • A perspective of publicly accessible/open-access chemistry databases, Drug Discovery Today, Volume 13, Numbers 11/12, June 2008, 495-501, doi:10.1016/j.drudis.2008.03.017
  • ChemSpider Forums/Blogs
    • Forum.chemspider.com
    • ChemSpider Blog
    • Open Chemistry Web
    • ChemConnector Blog
    • www.chemspider.com/blog
