welcome toHOW TO MAKE A BEAUTIFUL THESIS  “Impressive Meyers, but let’s stick to your quantitative projections”
Hmy name O ELL is             I AM A
	   gestalt	   information design principals	   some typographic principals
	   information design is the study and practice     of bringing clarity and comprehensibility to     visual materials th...
(NOT JUST A DESIGNER THING)
CAN BE QUITE IMPORTANT ACTUALLY
WHAT’S WRONG WITH THIS INFOGRAPHIC?          Scale           2003   2004   2005   2006   2007   2008   2009   Skill Develo...
ANY BETTER?
WE LOOK FOR PATTERNS
WE WANT PATTERNS TO MEAN SOMETHING
WE WANT CHANGE TO MEAN SOMETHING
GESTALT LAWS OF PERCEPTION       (not a nasty infection)
SIMILARITY   PROXIMITY   FIGURE/GROUND
SIMILARITY	 more important should be visually ‘louder’
PROXIMITY                                              A label gets lost hereA label goes nicely here	 put stuff next to ...
PROXIMITY	 always align stuff
FIGURE/GROUND    Inctium sinctat voluptatur?       Inctium sinctat voluptatur?    Arumquam ellaut aruptam sum       Arumqu...
	serif    OR   sans serif / we read best what we read most	   Typefaces communicate	   contrast between thick and thin ...
SIGNAL TO NOISE RATIO	 information = signal	 everything else = noise
SIGNAL TO NOISE RATIO	 minimize pattern and line thickness	 remember figure/ground
LETS SEE WHAT THAT LOOKS LIKE
there are only five waysTO ORGANIZE INFORMATIONL ATCH
LOCATIONALPHABETICALT IMECATEGORYHIERARCHY
ALPHABETICAL	 arrange by sequence	 for non linear information	 or no other way to organize it
TIME	 arrange by chronological sequence	 timelines, step by step instructions, calendars time tables
LOCATION	 arrange by geographical or spatial reference	 for data flow about distance / geography
CATEGORY	 arrange by similarity or relatedness	 users looking for information in this form	 library catalog, periodic t...
HIERARCHY	 compared sequentially by common measures	 highest to lowest, best to worst
LET’S TRY IT OUTmake a graphic of “I will survive” using the LATCH methodFirst I was afraid                      Go on now...
SURVIVED!            LEARNED TO CARRY ON            GREW STRONG            NIGHTS SPENT FEELING SORRY FOR MYSELF          ...
WHAT INFOGRAPHIC SHOULD I USE?	   bivariate (one thing is compared to another)     use a table	   multivariate (more tha...
QUANTITATIVE	   show measurements and quantities
QUALITATIVE	   show processes and connectedness
WHICH CHART SHOULD I USE?      and how can I make it look good?
BAR CHARTS                                        APRIL                                        MAYSALES $US               ...
LINE GRAPHSALES $US                               TROLLS                               GNOMES                             ...
PIE CHART    example by Seth Godin	 bar chart implies importance	 pie chart shows extent of the troll problem in proport...
DESIGNING TABLES	 one dataset per table!	 notice information, NOT the table structure	 decrease the noise	 make the ba...
DESIGNING TABLES	 use dashes or ellipses for missing data	 tints help the eye read across or down	 	 se fonts with open...
DESIGNING BAR CHARTS	 don’t always need a frame or increment marks	 differences of height should be discernible	 type s...
PIE CHARTS	 don’t use an ellipse—it distorts the data	 don’t use busy patterns or 3D effect	 make sure colors are tonal...
LINE GRAPHS	 background and labels should not overwhelm the lines	 the scale should allow us to see variation   without ...
CAN WE MAKE THIS BETTER NOW?
100                                                                SKILL DEVELOPMENT 95                                   ...
    Questions?
B            YEGOOD                      e]          our name her[insert y
This presentation was created for non-profit educational purposes. These image credits are best guess based onwhere they w...
