Safe and Reliable Embedded Linux Programming: How to Get There Safe and Reliable Embedded Linux Programming: How to Get There Presentation Transcript

  • 7 June 2012 Safe and Reliable Embedded Linux Programming How to Get There José F. Ruiz Senior Software Engineer AdaCore EWiLi 2012, LorientCopyright © 2012 AdaCore Slide: 1
  • Outline • Safety issues – Language matters • Concurrent execution on monoprocessors – Ada Ravenscar Profile • Tasking on linux • Parallel execution on multiprocessors – Processor affinitiesCopyright © 2012 AdaCore Slide: 2
  • SafetyCopyright © 2012 AdaCore Slide: 3
  • Safety-Critical Software: Background • What is “safety critical” software? – Failure can cause loss of human life or have other catastrophic consequences • How does safety criticality affect software development? – Regulatory agencies require compliance with certification requirements – Safety-related standards may apply to the finished product, to the development process, or both • Choice of programming language has large impact on the cost of developing / certifying safety-critical systems – Dilemma: modern features that help in developing maintainable systems interfere with safety certification – Examples: Object-Oriented Programming, generics, exceptions, concurrency – Traditional approach: select subset (profile) amenable to safety certification – Chosen features depend on the analysis methods to be used (or dictate which methods are feasible)Copyright © 2012 AdaCore Slide: 4
  • Some language requirements (I) • Reliability – Support for development of readable, correct code – No “traps and pitfalls” – Intuitive lexical and syntactic features – Support for good software engineering practice – Encapsulation – Avoidance of concurrency bugs – Race conditions – Deadlock / livelock – Early error detection – Compile-time checking whenever possible – Run-time checking, at least • Predictability – Unambiguous language semantics – No undefined / implementation-dependent behavior – Ability to demonstrate statically that time and space constraints will be satisfied – Deadlines will be met – Stack and heap space will not be exhaustedCopyright © 2012 AdaCore Slide: 5
  • Some language requirements (II) • Analyzability – Control and data flow analysis – Detects / prevents references to uninitialized data – Information flow analysis – Identify dependencies between a routine’s inputs and outputs – Formal code verification – Range checking – Traceability between program representations and different levels – Dynamic analysis (testing) • Expressiveness – General-purpose features consistent with the above requirements – Support for specialized processing typical in embedded systems (safety) – Interrupt handling – Low-level programming – Fixed-point arithmeticCopyright © 2012 AdaCore Slide: 6
  • Modern programming languages • Many features help – Encapsulation / namespace control – Limit data coupling – Strong typing, compile-time checking – Early error detection • Some features present difficulties – High expressive power vs. need to constrain feature – Dynamic flexibility vs. need for static analysis – High-level features vs. need to certify the code that actually runs – Generated code may contain implicit loops, conditionals – Run-time library, API need to be certifiable – How, if at all, use features such as exceptions, concurrency, dynamic allocationCopyright © 2012 AdaCore Slide: 7
  • Modern programming languages – basic issues • No general-purpose language is appropriate for highest safety/security levels – Conflicts with reliability, predictability, analyzability • Key issue: can the language be subsetted so that applications restricted to the subset can be certified – Is/are the subset(s) precisely defined? – Can compliance with the subset(s) be enforced by a tool? – Who defines the subset(s)? – Standards agency? Tool/compiler vendor? Application developer? – Are there intrinsic problems with the language that cannot be solved by subsetting? • Current approaches – C-based – MISRA C / C++ – Ada-based – Ada profiles – SPARK Ada – Java-based – Real-Time / Safety-Critical Java TechnologyCopyright © 2012 AdaCore Slide: 8
  • MISRA C • Intended for embedded automotive systems – Around 170 rules • Prevent or restrict usage of C constructs with unpredictable behavior • Encourage static checking tools that enforce compliance with the subset Strengths Weaknesses – “Best practices” for C programming – C was not designed to meet the – General good style needs of high-integrity systems – Avoids C features intrinsically non- – Error-prone portable / ill-defined – Lacks features such as – Simplicity of C compared with other encapsulation, namespaces languages – C (and thus MISRA C) does not – Smaller run-time library – Easier certification “scale up” to large systems – Large population of candidate users – C standard has ambiguities and thus – And tools, service providers, etc. so does MISRA C – May be appropriate for small systems – Some rules are not enforceable by on specialized hardware lacking static tools compilers for alternative languages – Usage of MISRA C requires license – MISRA-C code may be produced as from MISRA output of source-to-source translatorCopyright © 2012 AdaCore Slide: 9
  • Ada – introduction • What is Ada? – General-purpose methodology-neutral strongly-typed ISO standard language – Intended for large, long-lived systems – Fits reliability-critical embedded real-time applications • Ada in a nutshell – Pascal-style foundation (syntax, basic data types) – Exception handling – Packages / encapsulation – Generic templates – Concurrency support (“tasking”) – Object-Oriented Programming – Support for “contracts” – Since Ada 2012 – Specialized support for particular domains, including: – Systems programming – Real-time systems – High-Integrity applicationsCopyright © 2012 AdaCore Slide: 10
  • Ada for safety-critical systems (I) • Full Ada not appropriate – Run-time library too large / complex – High level features interfere with traceability and analyzability • Why consider Ada for safety/security-critical software – General design philosophy promotes sound software engineering – Successful history from Ada 83 • Standard support for safety/security-critical systems – High-Integrity Systems Annex – Contracts – Profiles – Such as the Ravenscar profile – User-defined tailoring, specifying features that are not used (pragma Restrictions) – Compiler rejects programs that use these features – Executable program excludes run-time libraries for these features • Guidelines documents – Guide for Ada in High-Integrity Systems (an ISO Technical Report) – Guide for Ada Ravenscar Profile in High-Integrity SystemsCopyright © 2012 AdaCore Slide: 11
  • Ada for safety-critical systems (II) • Reliability – Very few features have surprising effects – Prevention of dangling references to declared objects, subprograms – Specification of intent on operation inheritance – Contracts – No garbage collection – Programmer responsible for memory management • Predictability – Language semantics are generally well-defined, in an ISO standard – But there are features whose effects are implementation defined, implementation dependent, unspecified, or “bounded errors” – Implementation decisions can affect time or space predictability – Functions returning unconstrained arrays – Solutions in practice – Analyze source program (e.g. no read of uninitialized object) – Adhere to subset (no functions returning unconstrained arrays) – Analyze object code so that implementation decision is knownCopyright © 2012 AdaCore Slide: 12
  • Ada for safety-critical systems (III) • Analyzability – Some features help analyzability – Child units may be used for testing packages with encapsulated state – But full language is too complex; need to subset – Key features are pragma Restrictions and pragma Profile – Ada is in effect a family of profiles, where user can select features à la carte – No such thing as the safety-critical Ada profile – Troublesome OOP features are easily avoided – But no standard annotation facility • Expressibility – Support for low-level and real-time programming – Ravenscar Profile for certifiable concurrent applications – Good inter-language interfacing facilities, to incorporate certifiable libraries from other languages – Some weaknesses – Limited support for distribution / networkingCopyright © 2012 AdaCore Slide: 13
  • Ada examples Configuration Spec (design by contract) pragma Profile (Ravenscar); package Arith is -- Only Ravenscar tasking allowed procedure Double (X : in out Integer) with Pre => X >= IntegerFirst / 2 and then pragma Restrictions (No_Allocators); X <= IntegerLast / 2, -- Avoid dynamic memory Post => X = 2 * XOld; end Arith; pragma Restrictions (No_Access_Subprograms); -- No pointers to subprograms System programming type Parity_Kind is (Even, Odd); for UART_Data_Register use record type Reserved_21 is mod 2**21; Data at 0 range 0 .. 7; for Reserved_21Size use 21; Data_Ready at 0 range 8 .. 8; Parity at 0 range 9 .. 9; Type UART_Data_Register is Parity_Error at 0 range 10 .. 10; record Reserved at 0 range 11 .. 31; Data : Character; end record; Data_Ready : Boolean; for UART_Data_RegisterSize use 32; Parity : Parity_Kind; Parity_Error : Boolean; UART_A : UART_Data_Register; Reserved : Reserved_21; pragma Atomic (UART_A); end record; for UART_A’Address use To_Address (16#8000_0100#);Copyright © 2012 AdaCore Slide: 14
  • Ada evaluation • Strengths – Sound base language for programming high-reliability systems – Allows construction of tailored high-integrity subsets that are: – Powerful enough to use for real systems – Simple enough to be amenable to certification – Scales up to large systems – ISO Standard – Concurrency support / Ravenscar Profile – Design by contract – Free and publicly available documents – Ada Reference Manual, Rationale – Guidelines documents – Good track record in avionics, train control, other safety-critical domains • Weaknesses – Whole language is too large, so must be subsetted – Aside from the standard Ravenscar Profile, others are vendor specific – Language has some features with implementation-dependent or unspecified behavior – Such as referencing a variable before its initialization – Smaller user / tool vendor community than other languagesCopyright © 2012 AdaCore Slide: 15
  • SPARK introduction (I) • SPARK is – A language, plus – Static analysis tools based on underlying principle of correctness by construction • Facilitate rigorous, static demonstration that program does what it is supposed to do – And only that • Guarantee bounded time and space requirements • Allow simple run-time library amenable to certification • Ada-based language – Ada plus contracts minus features that interfere with above principle – Contracts are special comments handled by the SPARK tools • Language restrictions (Ada features intentionally omitted) – Features that complicate analysis / formal proofs, e.g.: – Exceptions, goto statement, generic templates, function side effects – Features that interfere with bounded time / space requirement, e.g.: – Recursion, pointers, dynamically-sized arraysCopyright © 2012 AdaCore Slide: 16
  • SPARK introduction (II) • Language features include: – Most of Ada’s “static semantic” features, including packages, private types, unconstrained array types, “OOP Lite” – Concurrency (Ravenscar tasking profile) • Contracts – Data / information flow (use of global variables, formal parameters) – Inter-module dependencies – Specification of dynamic behavior (pre / post-conditions, assertions) • Analysis performed by SPARK tools – Static semantic analysis – detect aliasing, function side effects, … – Control flow analysis – detect dead code, banned constructs (goto, …) – Data-flow analysis – detect unused or uninitialized variables, … – Information-flow analysis – check input / output variable coupling – Verification condition generation – generate theorems – Theorem provingCopyright © 2012 AdaCore Slide: 17
  • SPARK example Contracts and flow information procedure Process (Output : out T; Input1, Input2 : in T); --# global out Global_Output; --# in Global_Input; --# derives Output from Input1, Input2 & --# Global_Output from Global_Input, Input2; --# pre Input1 /= 0; --# post Output = Input2 / Input1;Copyright © 2012 AdaCore Slide: 18
  • SPARK for safety-critical systems • Reliability – Inherits Ada’s general advantages (few syntactic surprises) – Avoids some errors that may occur in full Ada – Reference to uninitialized variable • Predictability – Unambiguous specification with no implementation dependencies – But not a formal standard – Contracts allow statically checkable assertions about resource requirements • Analyzability – SPARK Ada subset eliminates features that are complicated to analyze • Expressibility – Missing some useful functionality (e.g. generics) but does include some tasking featuresCopyright © 2012 AdaCore Slide: 19
  • SPARK evaluation • Strengths – Designed from the start to satisfy high-integrity requirements – Language rules are unambiguous, implementation independent – Insecurities (e.g., “aliasing” of formal parameter and global variable) and many kinds of hard-to-detect bugs (e.g. use before initialization) are prevented – Contracts show programmer’s intent, aid readability – Support for concurrency (Ravenscar profile) – Tedious aspects of constructing proofs are automated – Positive experience across a range of high-integrity projects – Lower certification costs and post-delivery bug rates – Excellent reference material • Weaknesses – Language lacks some useful features – No “pointers”, but in many kinds of safety critical systems a restricted style for pointers is permitted • Pointers to statically declared data • Dynamic allocation at system startup – Some restrictions (e.g. no recursion) require stylistic workarounds – Contracts require different development style than what most programmers are used to – Relatively small user community – Small number of suppliers for tools, servicesCopyright © 2012 AdaCore Slide: 20
  • ConcurrencyCopyright © 2012 AdaCore Slide: 21
  • Concurrency in Ada (short history) • Concurrency a first-class citizen in Ada – Easy to use and analyze – Since the beginning – Well-developed tasking in Ada 83 – Ada 95, Ada 2005 , Ada 2012 improved and extended tasking Ada Decades of experience in using Ada on multiprocessorsCopyright © 2012 AdaCore Slide: 22
  • Why Ravenscar • Use concurrency in embedded real-time systems – Verifiable – Simple – Implemented reliably and efficiently • Scheduling theory for accurate analysis of real-time behavior – Preemptive fixed priority scheduling – Rate Monotonic Analysis (RMA) – Response Time Analysis (RTA) – Priority Ceiling Protocol (PCP) – Avoids unbounded priority inversion and deadlocks • Tool support – RMA and RTA – Static simulation of concurrent real-time programsCopyright © 2012 AdaCore Slide: 23
  • What is the Ravenscar profile • A subset of the Ada tasking model • Defined to meet safety-critical real-time requirements – Determinism – Schedulability analysis – Memory-boundedness – Execution efficiency and small footprint – Suitability for certification • State-of-the-art concurrency constructs – Adequate for most types of real-time softwareCopyright © 2012 AdaCore Slide: 24
  • Tasks • Fixed set of tasks – Only at library level – No dynamic allocation – No nested declaration of tasks – Statically created – Task descriptors, stacks, … • Each task is infinite loop – Single “triggering” action (delay or event) • Task creation and activation is very simple and deterministic – All tasks are created at initialization – Then all activated and executed according to their priorityCopyright © 2012 AdaCore Slide: 25
  • How tasks look like in Ravenscar Time-triggered task Event-triggered task task body Cyclic is Period : constant Time_Span := Milliseconds (10); Activation : Time := Clock; task body Sporadic is begin begin loop loop delay until Activation; Monitor.Wait_Event; -- Protected entry -- Do something -- Do something Something; Something; end loop; -- Compute next activation time end Sporadic; Activation := Activation + Period; end loop; end Cyclic;Copyright © 2012 AdaCore Slide: 26
  • Periodic activity in Ada and C static void *periodic (void *arg) { struct timespec activation; clock_gettime (CLOCK_REALTIME, &activation); C Periodic while (1) { clock_nanosleep (CLOCK_REALTIME, TIMER_ABSTIME, &activation, NULL); Freq = 10 Hz /* Do something */ something (); /* Compute next activation time */ if (1000000000 - activation.tv_nsec < 100000000) { task body Periodic is activation.tv_sec += 1; Activation : Time := Clock; activation.tv_nsec += 100000000 - 1000000000; begin } else { loop activation.tv_nsec += 100000000; delay until Activation; } } -- Do something } Something; int main(void) { pthread_t thread; -- Compute next activation time pthread_attr_t attr; Activation := pthread_attr_init (&attr); Activation + Milliseconds (100); end loop; pthread_create (&thread, &attr, &periodic, NULL); end Periodic; … }Copyright © 2012 AdaCore Slide: 27
  • Synchronization in Ravenscar protected body Buffer is protected Buffer is procedure Put (Element : Item) procedure Put (Element : Item); is entry Get (Element : out begin Item); Container := Element; private Received := True; Container : Item; end Put; Received : Boolean := False; end Buffer; Pr Buffer entry Get (Element : out Item) when Received is Put begin Get Element := Container; Received := False; C Producer end Get; end Buffer; S Consumer task body Producer is Period : constant Time_Span := Milliseconds (10); Activation : Time := Clock; Element : Item; begin loop task body Consumer is delay until Activation; Element : Item; begin Element := Produce_It; loop Buffer.Get Buffer.Put (Element); (Element); Activation := Activation + Period; Consume (Element); end loop; end loop; end Producer; end Consumer;Copyright © 2012 AdaCore Slide: 28
  • Interrupt support in Ravenscar protected Monitor is pragma Priority (Interrupt_Priority’Last); Pr Monitor procedure Handler; External Interrupt pragma Attach_Handler (Handler, Handler Interrupt_ID); Wait entry Wait; private Signaled : Boolean := False; end Monitor; S Interrupt_Task protected body Monitor is task body Interrupt_Task procedure Handler is is begin begin Signaled := True; loop end Put; Monitor.Wait; entry Wait when Signaled is Handle_Interrupt; begin end loop; Signaled := False; end Interrupt_Task; end Wait; end Monitor;Copyright © 2012 AdaCore Slide: 29
  • Concurrency on linuxCopyright © 2012 AdaCore Slide: 30
  • The model – Ada tasks • Ada task runs on top of operating system thread – One-to-one correspondence • Task dispatching policy – Can be selected with pragma Dispatching_Policy – SCHED_OTHER by default – Preemptive priority scheduling – pragma Dispatching_Policy (FIFO_Within_Priorities) • pthread_setschedparam (Thread, SCHED_FIFO, Param’Access) – Means run until blocked (or preempted), no time slicing – Reduces non-determinism – NOTE!!: Requires special (root) privileges • Xenomai – Real-time behavior – The Ada run-time library can call the Xenomai API to create tasks in kernel domainCopyright © 2012 AdaCore Slide: 31
  • The model – Synchronization • A protected type is a data object with locks – Data encapsulation, accessible through interface (locked access routines) – functions (read the data with read lock) – procedures (read/write the data with write lock) – entries (wait until some condition is met, then read/write the data with write lock) • Priority inheritance – Guard against priority inversion – low priority task grabs resource X – high priority task needs resource X, waits – medium priority task preempts low priority task, and runs for a long time, holding up high priority task – Solution, while high priority task is waiting, lend high priority to low priority task • Implementation – Mutual exclusion – Mutex – Waiting / Signaling operations – Conditional variableCopyright © 2012 AdaCore Slide: 32
  • The model – System programming • Clock and delay – Clock uses gettimeofday – Delay operations use timed conditional variables – We can wakeup the task before expiration if needed • Interrupt handling – Underlying signal mechanism – A server task per interrupt served – With specific mask to serve the required signal – Call to sigwaitCopyright © 2012 AdaCore Slide: 33
  • MultiprocessorsCopyright © 2012 AdaCore Slide: 34
  • Why addressing multiprocessors? • The answer to increasing processing demands – We cannot increase the clock frequency forever – We cannot increase the instruction-level parallelism forever – Provides higher performance for less consumed energy Courtesy IEEE Computer, January 2011, page 33.Copyright © 2012 AdaCore Slide: 35
  • Periodic activity in Ada and C (multiprocessor version) static void *periodic (void *arg) { struct timespec activation; clock_gettime (CLOCK_REALTIME, &activation); while (1) { C Periodic clock_nanosleep (CLOCK_REALTIME, TIMER_ABSTIME, &activation, NULL); Freq = 10 Hz /* Do something */ CPU affinity = 1 something (); /* Compute next activation time */ if (1000000000 - activation.tv_nsec < 100000000) { activation.tv_sec += 1; activation.tv_nsec += 100000000 - 1000000000; task Periodic with CPU => 1; } else { activation.tv_nsec += 100000000; task body Periodic is } Activation : Time := Clock; } begin } loop delay until Activation; int main(void) { cpu_set_t cpuset; -- Do something pthread_t thread; pthread_attr_t attr; Something; CPU_ZERO (&cpuset); -- Compute next activation time CPU_SET (0, &cpuset); pthread_attr_init (&attr); Activation := pthread_attr_setaffinity_np Activation + Milliseconds (100); (&attr, sizeof (cpu_set_t), &cpuset); end loop; end Periodic; pthread_create (&thread, &attr, &periodic, NULL); … }Copyright © 2012 AdaCore Slide: 36
  • Some advantages of Ada • Better readability – No doubts, right? • Semantics – The Ada run time enforces required dispatching policy, signal mask, master-dependent tasks, … • Portability Platform Ada C Linux Solaris Windows VxWorks Bare boardCopyright © 2012 AdaCore Slide: 37
  • Ada 2012 • Ada 2012 added explicit support for controlling processor allocation – Dispatching_Domain • Ravenscar profile for multiprocessors • Parallel task synchronization • Memory barriersCopyright © 2012 AdaCore Slide: 38
  • Concurrent / parallel execution in Ada • Ada has always taken into account parallel architectures – Allow concurrent/parallel execution – Multicomputers, multiprocessors, interleaved execution – Even allow parallel execution of a single task – … if its effect is as executed sequentially – A task can be on the ready queues of more than one processor – Many partitioning schemes allowed – Via implementation-defined pragmas or non standard library packagesCopyright © 2012 AdaCore Slide: 39
  • Synchronization and communication of parallel activities • Task synchronization – Protected objects – No language-defined ordering or queuing presumed for tasks competing to start a protected action • Tasks are intended to spin lock on multi-processors – Shared variables – Cache coherence – Rendezvous – The call to the task entry is blockingCopyright © 2012 AdaCore Slide: 40
  • Symmetric Multi-Processor (SMP) • Several similar processors – All processors can perform the same functions • Centralized memory with uniformed access time – Problem of cache coherence Processor Processor Processor Processor One or One or One or One or more cache more cache more cache more cache levels levels levels levels Main memory I/O SystemCopyright © 2012 AdaCore Slide: 41
  • Partitioned versus global scheduling Partitioning Global Scheduling • Tasks assigned to a given • Task migration is permitted processor – Overhead of task migration • How to schedule a group of tasks increases with the number of CPUs on a processor is known – Reduced cache performance – Rate Monotonic Scheduling (static priorities) – Earliest Deadline First (dynamic None is better than the other in priorities) terms of guaranteed CPU utilization • But, dividing the tasks into groups is NP-hardCopyright © 2012 AdaCore Slide: 42
  • Typical OS support for multiprocessors • Set CPU affinity – Allocate tasks to one CPU (or to a group of CPUs) • Get CPU affinity • Task migration – From one CPU to another – Either user-requested or performed by the OS • Spin locks – Tasks wait in a loop until lock is free (busy waiting) – Multiprocessor synchronizationCopyright © 2012 AdaCore Slide: 43
  • Support for multiprocessors in Ada 83, 95, 05 • Ada has always allowed a program’s implementation to be on a multiprocessor system – Real parallelism – Inter-processor synchronization • No direct support for affinities – The OS can decide the best allocation – The developer – Implementation-defined pragmas or non standard library packages • Allows the full range of partitioning – But no user control defined in the standardCopyright © 2012 AdaCore Slide: 44
  • Explicit support for multiprocessors in Ada 2012 • Notion of dispatching domain • Safe multiprocessor tasking • Parallel task synchronization • Memory barriersCopyright © 2012 AdaCore Slide: 45
  • Ada 2012 dispatching domains • Focus on SMPs • Handle mapping of tasks to processors – Support all schemes – Partitioned • Tasks allocated to a subset of CPUs – Global • Implicit task migration supported • Explicit task migration allowed • Notion of processor dispatching domain – Group of processors across which global scheduling occurs – Non-overlapping dispatching domains – Tasks are assigned to an unique dispatching domain – A task may be allocated to a given processor within the dispatching domain – Or free to be in any of the domainCopyright © 2012 AdaCore Slide: 46
  • Static allocation to processors task type Allocated_Task (Affinity : CPU) with CPU => Affinity; T1 : Allocated_Task (1); T2 : Allocated_Task (2); T3 : Allocated_Task (3); T4 : Allocated_Task (4); GroupA : aliased Dispatching_Domain := Create (1, 2); GroupB : aliased Dispatching_Domain := Create (3, 4); GroupC : aliased Dispatching_Domain := Create (5, 6); GroupD : aliased Dispatching_Domain := Create (7, 8); task type Grouped_Task (Group : access Dispatching_Domain) with Dispatching_Domain => Group.all; T1, T2, T3, T4 : Grouped_Task (GroupA’Access); T5, T6 : Grouped_Task (GroupB’Access); T7, T8, T9 : Grouped_Task (GroupC’Access); T10, T11 : Grouped_Task (GroupD’Access);Copyright © 2012 AdaCore Slide: 47
  • Dynamic affinity handling GroupA : Dispatching_Domain := Create (1, 2); GroupB : Dispatching_Domain := Create (3, 4); GroupC : Dispatching_Domain := Create (5, 6); GroupD : Dispatching_Domain := Create (7, 8); task body T_In_A is Current_CPU : CPU; begin -- In processor 1 or 2 Do_Something; task T_In_A with Dispatching_Domain => GroupA; -- In processor 1 only task T_Non_Allocated; Set_CPU (1); task body Driver is Do_Something; begin -- Allocate T_Non_Allocated to GroupB -- In processor 2 only Assign_Task Set_CPU (Get_Last_CPU (GroupA)); (GroupB, 3, T_Non_Allocated’Identity); Do_Something; Do_Something; -- Now again in processor 1 or 2 -- Move it to a different processor Set_CPU (Not_A_Specific_CPU); if Proc_3_Overloaded then Do_Something; Set_CPU (4, T_Non_Allocated’Identity); end if; -- Now I am lost. Where am I? Do_Something; Current_CPU := Get_CPU; end Driver; pragma Assert (Current_CPU = Not_A_Specific_CPU); end T_In_A;Copyright © 2012 AdaCore Slide: 48
  • Handle affinity and dispatching policy • What I want – Create a group of processors – Define an specific scheduling policy for the group pragma Priority_Specific_Dispatching (FIFO_Within_Priorities, 20, 25); – Execute a set of tasks within the group Group : Dispatching_Domain := Create (1, 2); task T1 • What I have to do with Dispatching_Domain => Group, Priority => 22; – Create a dispatching domain – Define a non-overlapping priority band task T2 with Dispatching_Domain => Group, – Allocate tasks to the dispatching domain Priority => 23, CPU => 1; – Use priorities in the priority band task T3 with Dispatching_Domain => Group, Priority => 24;Copyright © 2012 AdaCore Slide: 49
  • Synchronization on multiprocessors • Protected objects – There is a lock-free optimization for monoprocessors (using priorities) – No longer viable on multiprocessors – Currently Ada advise that tasks should busy-wait (spin) at their active priority for the lock • Task entries – Requires internal synchronization primitives aware of multiprocessor – Spin locksCopyright © 2012 AdaCore Slide: 50
  • Multicores for real-time safety-critical embedded systems • We need to address: – Reliability – Predictability – Analyzability • The Ravenscar profile for monoprocessors is – Deterministic – Time analyzable – Simple to use and implement • Extend the Ravenscar profile model from monoprocessor to multiprocessor – Fully partitioned model – Fixed-priority scheduling – Static model • Allow for – Simple implementation – Verifiable – Schedulability analysisCopyright © 2012 AdaCore Slide: 51
  • Static model • Concurrent entities fixed and static – Tasks and shared memory defined before execution • Static fixed priority scheduling algorithm – Preemptive fixed priority scheduling in each CPU – Analyzable as in Ravenscar for monoprocessors – Dynamic-priority scheduling algorithms could increase CPU utilization but: – Higher complexity – Higher run-time overhead – Lower predictability, lower robustness in case of overload • Partitioned – Each task allocated to an user-defined processor forever – CPU utilization of partitioned scheduling is neither better nor worse than global – It relies on very well known monoprocessor techniques for priority allocation and timing analysis – It is much simpler to implement – No task migrationCopyright © 2012 AdaCore Slide: 52
  • Task scheduling • Tasks statically allocated to processors Ravenscar system on monoprocessor – No task migration • Preemptive fixed-priority scheduling 0 1 • Single shared run time 2 – Per-CPU ready queues – Spin-locks to protect shared data 3 – Disabling interrupts is not enough task Cyclic with Priority => 100, • Operations on a different CPU => 3; end Cyclic; processors – Triggering an special interrupt in the target processorCopyright © 2012 AdaCore Slide: 53
  • Task synchronization • Library-level protected objects – Shared data with mutual exclusion – Both for inter- and intra-processor communication • Simple and efficient mutual exclusion changing priority for intra-processor communication – As in Ravenscar monoprocessor – Could be statically detected – Efficiency – Simple timing analysis • Spin-locking for inter-processor synchronization • Awaking tasks from other processors – Inter-processor interrupt facility to modify the ready queuesCopyright © 2012 AdaCore Slide: 54
  • Parallel task synchronization • Goal – Effective parallel task synchronization – Set of tasks blocked and released at once • Typical case – A group of tasks must wait until all of them reach a synchronization point – And then be released together to work in parallel • Mimic the POSIX barrier mechanismCopyright © 2012 AdaCore Slide: 55
  • Parallel barrier example package Ada.Synchronous_Barriers is pragma Preelaborate (Synchronous_Barriers); subtype Barrier_Limit is Positive range 1 .. <imp- def>; type Synchronous_Barrier (Release_Threshold : Barrier_Limit) is limited private; procedure Wait_For_Release (The_Barrier : in out Synchronous_Barrier; Notified : out Boolean); Number_Of_Tasks : constant := 8; private Barrier : Synchronous_Barrier (Number_Of_Tasks); -- not specified by the language end Ada.Synchronous_Barriers; task type Worker (Affinity : CPU) with CPU => Affinity; task body Worker is Notified : Boolean; begin loop Wait_For_Release (Barrier, Notified); -- Do something in parallel at the same time Something; if Notified then -- Only one task does this Ask_For_More_Work; end if; end loop; end Worker;Copyright © 2012 AdaCore Slide: 56
  • Memory barriers • Goal – Have control over cache memories • Typical case – Non-blocking algorithms to effectively exploit hardware parallelism – lock-free and wait-free • Problem to solve – How to ensure the correct order of loads and stores with multi-level caches – Modern multicores do not guarantee this ordering between processors – Optimizations that can result in out-of-order execution – Unless special instructions are used • How to do it with Volatile – Until Ada 2005 – They can never be in cache or registers – The Ada 2012 (more realistic) approach – Volatiles can be handled in cache memories, but – Guarantee serial ordering • All tasks of the program (on all processors) that read or update volatile variables see the same order of updates to the variables • May need the use of an appropriate memory barrier to flush the cacheCopyright © 2012 AdaCore Slide: 57
  • Example of memory barriers Shared_Data : Integer; pragma Volatile (Shared_Data); • In Ada 83, 95, 2005 Barrier : Boolean := False; pragma Volatile (Barrier); – Shared_Data and Barrier can never be in cache task Producer with CPU => 1; task Consumer with CPU => 2; • In Ada 2012 task body Producer is begin – Shared_Data and Barrier can be in cache … Produce (Shared_Data); Barrier := True; … end Producer; task body Consumer is begin … while not Barrier loop null; end loop; -- If we see that Barrier has been updated, -- we must see the produced value of -- Shared_Data. Use(Shared_Data); … end Consumer;Copyright © 2012 AdaCore Slide: 58
  • Conclusion • There is support in programming environments for high-integrity • Embedded programming can use high-level abstraction constructs • Real-time support – Computational model amenable to timing analysis • Ada has supported execution on parallel architectures since its inception – Ada 2012 dispatching domains – Good flexibility and analyzability – Implementable on top of typical operating systems and kernels – Ravenscar for multiprocessors – Simple extension to Ravenscar on monoprocessors – Partitioning into a set of monoprocessor Ravenscar systems – Keep desired properties found in monoprocessor RavenscarCopyright © 2012 AdaCore Slide: 59
