Living Streamside    A workshop presented by the          Abington TownshipEnvironmental Advisory Council (EAC)           ...
Welcome to Living Streamside        Commissioner John Carlin (Ward 15)            andthe members of the EAC               ...
Living StreamsideThis workshop has been funded by a grant fromWater Resources Education Network,a program of the League of...
Living StreamsideA   special thanks to:    The Roslyn Boys and Girls Club    Our speakers and partners      •   Delawar...
Abington EAC – Upcoming Events   Earth “Day” Cleanups       Cleveland Avenue near        Roychester Park         • Satur...
Abington EAC – Upcoming                  Events   Arbor Day Celebration at Ethel Jordan Park       April 30th 10:00am   ...
Abington EAC – Upcoming   Rain Barrel Art Contest       Submit a photo of your        decorated rain barrel by        Ap...
Abington EAC   Learn more about the EAC, upcoming events and    ways you can help Abington “Go Green”       www.eac-abin...
Why Should I be Concerned?               Rivers and streams are a major                source of drinking water.         ...
Water Resources 101
What is a Watershed?AWatershedis an areaof landthat drainsto a singleoutlet.
Abington Township Watersheds Pennypack Creek (Ogontz Campus) Tookany/Tacony-Frankford Creek  (AHS) Wissahickon Creek (B...
Pennypack Creek Watershed56.5 Square MilesDrains into the Delaware RiverImage from Philadelphia WaterDepartment:www.philly...
Tookany/Tacony-FrankfordCreek Watershed38.7 Square Miles – Drains intothe Delaware RiverImage from Philadelphia WaterDepar...
Wissahickon Creek Watershed63.8 square miles – drains intothe Schuylkill RiverImage from Philadelphia WaterDepartment: www...
Wissahickon Watershed
Non-Point Source Pollution Basics
“Old” Efforts              Focused on Point Sources                  of Water PollutionPhotos used with permission from va...
Polluted Runoff isthe #1 Water QualityProblem in the U.S.*                       * USEPA
Development Impacts on the       Water Cycle10%                       50%                             55%                 ...
The Effects of Urbanization                                                                          Trout                ...
Improving Watershed Health – What Can You Do At Home??
What is a Riparian Buffer?  An area of  vegetation that is  maintained along  the shore of a water  body to protect  strea...
Where Found Permanent or Intermittent Streams Lakes and Ponds Wetlands Seeps                     In your backyard !
Types of Buffers Forested Wetland Meadow
Forested Buffer is most       effective             Healthy forest               community              shade from canopy...
….even a thin forested  buffer adds value              shade for the               stream              aesthetics       ...
Buffer Benefits Help Stabilize Streambanks Buffer Against Pollution Impacts Help reduce flood related damage  to proper...
Lawns Don’t Make Good Buffers             Shallow roots do little to              prevent erosion             Short gras...
Can you find the typical lawn grass root system?….      Native Plant Guide for Streams and Stormwater Facilities in Northe...
Lawns don’t infiltrate water well                                    Infiltration Rates                               20  ...
Lawn and Garden Care - Fertilizing Use    fertilizers sparingly –  follow directions Don’t fertilize before a  rainstorm...
Lawn and Garden Care - Fertilizing Let your grass clippings lay! Wash your spreader equipment on a  pervious surface Ne...
Buffer Issues and    Misuses
Issues with Vegetated Buffers Landowner   misuses Unkempt appearance Crime / Illegal use Critters
Landowner abuses Dumping yard    waste   many think natural materials don’t hurt    stream   nutrients, lawn chemicals ...
Public concerns about vectors   associated with buffers   Potential Vector   Health Risk   rats & mice        various   ge...
Realities Rats and mice are attracted to trash not riparian  vegetation Riparian vegetation discourages geese using  are...
More realities Mosquitoes     need standing water to breed     healthy stream ecosystem increases predation      by drag...
Why to Go Wild with the Natives   Low maintenance   The birds and the    bees (and more!!)   Heritage
Natives are pretty!!PA has a wide variety of natives          Redbud photo by Road Fun www.flickr.com/photos/guest_family/...
Native Trees and Shrubs for    Streamside Buffers             Wettest Areas                    Sycamore                ...
No Mow Establishment   How wide?       Goal 50’ but 15’ will help   Establishment       Remove turf and invasives    ...
www.flickr.com/photos/randysonofrobert/2434950739/Phragmites                                                              ...
www.flickr.com/photos/ashevillein/4602174643/                      Multiflora rose     www.flickr.com/photos/urtica/295742...
www.flickr.com/photos/blueridgekitties/5114420288   /Oriental bittersweet                                                 ...
Japanese Knotweed                                                  Control early!!Photos from: www.environet-uk.co.uk/grap...
Common Garden Escapees to Avoid   Herbaceous       English ivy       Pachysandra       Periwinkle       Wisteria    ...
Stream Bank and Channel                ErosionWhy do we care?   Property loss   Sediment is a    pollutant   Decreased ...
Fixed It ?                                 Valley Creek, Chester County, PAPine Run, Montgomery County,PA
All photos Sandy Run in Abington, PA
Bank Stabilization   Solution versus Band-Aid   BEWARE: Streams are a    dynamic, interconnected    system   Consult a ...
Soil Bioengineering                                 Photos from NRCS© 2004 Salix Applied Earthcare
Bank Grading Valley Creek, PA  Stony Creek, PA
Instream Structures                                               Perkiomen Creek, PA Nevada Creek, MTPhoto by Beth Porter...
Instream StructuresSprogels Run, PA           Darby Creek, PAManatawny Creek, PA    Darby Creek, PA                       ...
No Permit Required Buffer planting No-mow Tree removal Live stakes Erosion control  blankets
Permit Required Bank  grading Gravel removal Tree revetment Placement of rock  or other material  along the channel  b...
Stormwater 101 Photo courtesy of thirteen of clubs
Stormwater Runoff  from roads, houses, parking lots,  lawns, etc. Impervious surfaces increase volume and  rate of runof...
Stormwater can cause floodingPhoto: Schuylkill River by riverparkalliancewww.flickr.com/photos/23704434@N04/5041096375/
Stormwater can cause erosionRoychester Park, Abington, PA
How to Manage Stormwater   Slow down and    infiltrate   Keep it clean       Pick up pet waste       Maintain your veh...
Stormwater Management   Slow down and infiltrate    – make an asset   Direct into gently sloped    vegetated areas   Pr...
Stormwater Management           Rain BarrelsSouthampton Township, PA   Abington Township,                           PA
Stormwater Management                    Rain GardensPhotos from Roslyn Park in AbingtonTownship, PA
Backyard Buffer Program       Abington Township Environmental Advisory Council          April 9, 2011                     ...
Backyard Buffer Program       Website                          70
What is a Backyard Buffer?                                                                       71Source: “Conservation B...
72Source: Philly H2O The History of Philadelphias Watersheds and Sewers
73
Backyard Buffer Program Tip Sheets                                     74
Saint Christopher School Lawns to Meadow       (No-Mow Zone Tip Sheet #1)                                           75
Green Lawn Basics (Tip Sheet #2)          General lawn care practicesPromote less maintenance & cleaner environment.   Nat...
Tree & Shrub Planting Basics       (Tip Sheet #4)        Invasive Species                                 Removal         ...
Composting  (Tip Sheet #5)  Rain Barrel(Tip Sheet #6)                   78
Rain Gardens    A planted shallow depression designed to catch & filter rainfall runoff.                                  ...
Roslyn Park Rain Garden & Infiltration Trench Design         Sandy Run                                                    ...
Roslyn Park Rain Garden & Infiltration Trench Design  Outlet Pipe to Sandy Run                                         New...
82
83
Installation September 2008                              84
85
86
87
1.5 inch precipitation January 25, 2010                                          88
January 27, 2010 (48 hours post event)                                         89
Backyard Buffer Program       Website                          90
So Now What?!?? Keep  a buffer between your yard and the  stream (the wider and denser the better) Embrace the natives ...
And Then What?? Enjoyyour creek and know that you are helping keep Philadelphia’s water clean
QUESTIONS?Turn in your survey as you leave.         THANK YOU!
