AMD DESKTOP PLATFORMS2012 AMD A-Series

AGENDA•Platform Overview•2012 AMD A-Series Accelerated Processors•Summary2 | 2012 AMD A-Series Presentation

AMD DELIVERS WHAT CUSTOMERS WANT Unlocked1 Unlocked Performance Latest Tech and World’s Highest Frequencies2 with Maximum Cores Up to 8 CPU Cores More Speed and Cores Ideal Platform with Better Video and Gaming with AMD Radeon™ up to $100 Graphics Easy Upgrades Cool & Quiet Inexpensive Every Day PC E-SERIES Best Online Entertainment Experiences Amazing Price / PerformanceAMD Internal Research3 | 2012 AMD A-Series Presentation

2012 AMD A-SERIES OVERVIEW CPU Discrete Class Graphics (“Piledriver” Cores) AMD Radeon™ HD 7000 “Trinity” Details Core 1 Core 2 Core 3 Core 4 • 32nm • ~1.3B transistors • 246mm2 L2 Cache L2 Cache • Up to 4 x86 Cores FM2 Socket4 | 2012 AMD A-Series Presentation

A-SERIES EVOLUTION 2011 A-Series “Llano” 2012 A-Series “Trinity” Socket FM1 Socket FM2 1150 3DMark 11 1570 3230 PCMark 7 4040Numbers rounded to nearest tens digit5 | 2012 AMD A-Series Presentation See endnotes for more information

BUILD A BETTER PC WITH AMD More Speed & Better Video & Gaming Easy Upgrade Path More Cores Featuring AMD Featuring AMD Featuring A85X, A75, Turbo Core 3.0 Radeon™ Graphics and A55 Platforms6 | 2012 AMD A-Series Presentation

MORE CORES & MORE SPEED Intel Core i3 2120/3220 X86 Cores 4 2 Max Frequency (GHz) 4.2 3.3 Powered by AMD Turbo Core 3.07 | 2012 AMD A-Series Presentation

MORE SPEED WITH AMD ACCELERATED PROCESSORSWINZIP 16.5 Winzip 16.5 Compression of 1015 Wave Files 9 FASTER Measured in SECONDS (Lower Is Better) 8 7 6 5 4 • OpenCL Accelerated 3 Encode and Decode • Additional AES 2 Acceleration 1 AMD A10 AMD A8 AMD A6 AMD A4 Pentium Pentium 5800K 5600K 5400K 5300 Core i3 G860 G630 08 | 2012 AMD A-Series Presentation See endnotes for more information

MORE SPEED WITH AMD ACCELERATED PROCESSORSGIMP GIMP Bilateral Filter Completion Time on a 1732x2592.bmp OpenCL™ Enabled 9 Measured in SECONDS (Lower Is Better) 8 7 6 5 FASTER • OpenCL™ accelerated 4 rendering, color conversion, and image 3 computation • 19 filters accelerated 2 with OpenCL™ 1 AMD A10 AMD A8 AMD A6 AMD A4 Pentium Pentium 5800K 5600K 5400K 5300 Core i3 G8x0 G6x0 09 | 2012 AMD A-Series Presentation See endnotes for more information

OVERCLOCKING1 CAPABILITIESBUILD A BETTER PC WITH AMD Overclock the CPU and GPU GPU @ 1 GHz CPU* @ 6.5 GHz GPU @ 1.05 GHz Memory @ 2133 +68% +11% +22.4% Cinebench 3DMark 3DMark 11.5 11(P) 11(P)*Performed with LN2 (liquid nitrogen)10 | 2012 AMD A-Series Presentation See endnotes for more information

YOUR FAVORITE TITLES ACCELERATED DOMINATING 1080P GAMING COMPARED TO AN INTEL HD 4000+102% +79% +77% +107% +101% +93% +82% +82%2xAA 8xAF Medium Medium Max with Low Low High Low Low Shadows Very Low 11 | 2012 AMD A-Series Presentation See endnotes for more information

ACCELERATED PROCESSORS DELIVER THE BEST GAMING EXPERIENCEWHY BUY THEIR MAINSTREAM GRAPHICS 90 Intel Core i5 3450 + NV GT 630 2GB DDR3 +$65 80 AMD A10 5800K 70 60 Get a Better Value with AMD 50 40 30 20 10 0 AvP Benchmark Call of Duty: Crysis 2 Deus Ex: DirtShowdown Just Cause 2 Left 4 Dead 2 Metro2033 Shogun 2 Skyrim: StarCraft II Black OpsPricing based off of AMD SEPP and Pricewatch.com on 8/28/1212 | 2012 AMD A-Series Presentation See endnotes for more information

AMD THE BETTER PLATFORM MAKE AMD RADEON <$100 GRAPHICS SHINE 70 Diablo III: 1920x1080 Max Settings 60 AMD A-Series 50 Discrete Advantage 40 FPS 30 AMD A-Series APU 20 Advantage• Additive Performance3• Supports DirectX® 9, 10, 11 10• Over 100 titles accelerated! 0 AMD A10 5800K Intel Core i3 Core i3 + GT 630 AMD A10 5800K + AMD A10 5800K + Core i3 + GT 640 Graphics AMD Radeon™ HD AMD Radeon™ HD 6570 (Dual 6670 (Dual Graphics) Graphics) Graphics Card Pricing: +$65 +$63 +$92 +$102 13 | 2012 AMD A-Series Presentation Pricing based off of Pricewatch.com on 8/28/12 See endnotes for more information

EASY UPGRADESAMD EYEFINITY3 TECHNOLOGY IN THE APU 32 fps Torchlight II: Max Settings AMD 10 5800K with AMD Radeon™ HD 7660D Discrete Class Graphics Native Widescreen Entertainment on an Accelerated Processor14 | 2012 AMD A-Series Presentation See endnotes for more information

2012 A-SERIES APUS FOR DESKTOPMULTI MONITOR TECHNOLOGY @1080P X3 Native Windows 8 Widescreen Enhancements15 | 2012 AMD A-Series Presentation

EASY UPGRADE PATHINTRODUCING OUR NEW FM2 PLATFORM 2011 2012 Future “Llano” “Trinity” “…” FM1 Socket FM2 Socket AMD A55 Chipset AMD A75 Chipset AMD A85X Chipset FM2 Socket FM2 Socket FM2 Socket FM2 Entry Ideal Entertainment Targeted for Platform Platform Performance16 | 2012 AMD A-Series Presentation

EASY UPGRADE PATHAMD MEMORY PROFILES Accelerated Processors Scale with Memory Frequency FPS 35 30 25 20 Easily Set 1866 MHz 15 Bios Default Bios Default Bios Default Performance 1600MHz 1600MHz 1600MHz 10 Dirt Showdown @1080P StarCraft II @1080P High Elder Scrolls: Skyrim 2AA 8AF Medium @1080P Medium17 | 2012 AMD A-Series Presentation See endnotes for more information

INTRODUCING AMD RADEON™ RAMDISK AMD A10 APU + AMD Memory = Up to 64 GB RAMDisk Features and Benefits Loading Times 160 (lower is faster)  Faster web page and application loading 140  Auto load and save 120 Normal RAM Disk 100  Maximum Security 80  No disk fragmentation 60  Extends the life of SSDs 40  Extreme Performance 20  Experience up to 525% faster loading of PC games 0 Crysis Shogun 2 Arma 2 Dirt Showdown Less waiting and more doing with PC-compatible RAMDisk18 | 2012 AMD A-Series Presentation

EASY UPGRADE PATHBUILD A BETTER SYSTEM WHEN CHOOSING <$100 GRAPHICS SOLUTIONS fps 60 Sleeping Dogs (1080P Medium Preset) +$92 50 40 +$63 +$105 30 +$65 20 10 0 HD 4000 GeForce GT 630 AMD A10-5800K APU GeForce GT 640 A10-5800K + HD6570 A10-5800K + HD 6670Pricing based off of AMD SEPP and Pricewatch.com on 8/28/1219 | 2012 AMD A-Series Presentation See endnotes for more information

INTRODUCING THE FM2 PLATFORM Build a Better PC with AMD More Speed & Best Video & Gaming Easy Upgrades More Cores Featuring Featuring Featuring A85X, A75, AMD Turbo Core 3.0 AMD Radeon™ Graphics and A55 Platforms20 | 2012 AMD A-Series Presentation

FM2 SOCKET ACCELERATED PROCESSORS AND PROCESSORS SKU INFORMATION APU Model A10-5800K A10-5700 A8-5600K A8-5500 A6-5400K A4-5300 AMD Radeon™ Graphics Brand HD 7660D HD 7660D HD 7560D HD 7560D HD 7540D HD 7480D TDP 100W 65W 100W 65W 65W 65W AMD Radeon™ Cores 384 384 256 256 192 128 GPU Clock Speed 800 MHz 800 MHz 760 MHz 760 MHz 760 MHz 723 MHz CPU Cores 4 4 4 4 2 2 3.9/ 3.7/ 3.8/ 3.6/ CPU Clock (Max Turbo/Base) 4.2/3.8 GHz 4.0/3.4 GHz 3.6 GHz 3.2 GHz 3.6 GHz 3.4 GHz Total Cache 4MB 4MB 4MB 4MB 1MB 1MB Max DDR3 1866 1866 1866 1866 1866 1600 AMD Turbo CORE 3.0 Yes Yes Yes Yes Yes Yes Unlocked1 Yes No Yes No Yes No21 | 2012 AMD A-Series Presentation

BACK UP SLIDES22 | 2012 AMD A-Series Presentation

FOOTNOTESAdditional hardware (e.g. Blu-ray drive, HD or 10-bit monitor, TV tuner, wirelessly enabled HDTV) and/or software (e.g. multimedia applications) arerequired for the full enablement of some features. HD Video display requires an HD video source. Not all features may be supported on all componentsor systems - check with your component or system manufacturer for specific model capabilities and supported technologies.1. AMD’s product warranty does not cover damages caused by overclocking, even when overclocking is enabled with AMD hardware or software2. Based on a shipping frequency of 4GHz – the highest shipping frequency of a consumer desktop processor as of September 5th, 20123. AMD Eyefinity technology works with games that support non-standard aspect ratios, which is required for panning across multiple displays. To enable more than two displays, additional panels with native DisplayPort™ connectors, and/or DisplayPort™ compliant active adapters to convert your monitor’s native input to your cards DisplayPort™ or Mini-DisplayPort™ connector(s), are required. Support for six simultaneous displays may require complementary products compatible with DisplayPort 1.2 Multi-Stream Transport. Maximum number of configured displays may vary - check with your component or system manufacturer for specific model capabilities and supported technologies. SLS (“Single Large Surface”) functionality requires an identical display resolution on all configured displays4. AMD Radeon™ Dual Graphics requires an AMD “A” series APU plus an AMD Radeon™ discrete graphics configuration and is available on Windows® 7 Professional, Windows 7 Ultimate, Windows® 7 Home Premium, and/or Windows® 7 Home Basic OS. Linux OS supports manual switching which requires restart of X-Server to engage and/or disengage the discrete graphics processor for dual graphics capabilities. With AMD Radeon™ Dual Graphics, full enablement of all discrete graphics video and display features may not be supported on all systems and may depend on the master device to which the display is connected. Check with your component or system manufacturer for specific mode capabilities and supported technologies. For All-In-One systems AMD Radeon™ “D” series and AMD Radeon™ “D2” Dual Graphics series do not support AMD Eyefinity technology. Always check with your system manufacturer for specific model capabilities and supported technologies.23 | 2012 AMD A-Series Presentation

ENDNOTESSlide 5: A-Series Evolution AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7 AMD A8-3850 with AMD Radeon™ HD 6550D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7Slide 8 & 9: More Cores and Faster Speeds with AMD Accelerated Processors AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.3 AMD A8-5600K with AMD Radeon™ HD 7560D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4 AMD A6-5400K with AMD Radeon™ HD 7540D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4 AMD A4-5300 with AMD Radeon™ HD 7480D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4 Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712 Intel Pentium G850 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712 Intel Pentium G620 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712Slide 10: Overclocking Capabilities AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7Slide 11: Your favorite Titles Accelerated AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8 Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712Slide 12: Accelerated Processors Deliver The Best Gaming Experience AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8 Intel Core i5-3450 with NV GT630 2GB DDR3, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. Driver 304.4824 | 2012 AMD A-Series Presentation

ENDNOTESSlide 13: Better Platform AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7 AMD A10-5800K with AMD Radeon™ HD 6570 or AMD Radeon™ HD 6670 Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7 and AMD Dual graphics enabled Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712 Intel Core i3-2120 with NV GT 630 2GB DDR3 or NV GT 640 2GB DDR3, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 304.48 DriverSlide 14: Easy Upgrades: Eyefinity technology in the APU AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8Slide 16: Easy Upgrade Path: AMD Memory Profiles AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866 (AMP enabled), A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866 (Bios default left at 1600), A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8Slide 18: AMD RAMDisk AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x8 GB DDR3-1600, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.825 | 2012 AMD A-Series Presentation

ENDNOTES Slide 19: Easy Upgrade Path: Build a better system with AMD and <$105 graphics  AMD A10-5800K with AMD Radeon™ HD 7660D or AMD Radeon™ HD 6570 or AMD Radeon™ HD 6670 or AMD Radeon™ HD 7770 Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7 and AMD Dual graphics enabled for AMD Radeon™ HD 6570 and AMD Radeon™ HD 6670.  Intel Core i5-3570K with HD 4000 on driver 8.15.10.2712 or Intel Core i5-3450 with GeForce GT 630 2GB DDR3 or GeForce GT 640 2GB DDR3 with Driver 304.48 or AMD Radeon™ HD 7770 Graphics with Catalyst 12.8, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows® 7 64bit.26 | 2012 AMD A-Series Presentation
