  • 1. pushing the web forward socket.io withFriday, April 6, 12
  • 2. who am i a socket.io core developer winner node knockout 2011 early node user since 0.1.3 founder observe.itFriday, April 6, 12
  • 3. github @3rd-eden & @3rdeden twitterFriday, April 6, 12
  • 4. i the state of real-time ii socket.io iii socket.io nextFriday, April 6, 12
  • 5. the state of real-timeFriday, April 6, 12
  • 6. the pastFriday, April 6, 12
  • 7. the past comet, polling and other methods to abuse the web can i has data browser serverFriday, April 6, 12
  • 8. the past comet, polling and other methods to abuse the web can i has data nope, dun has dataz ;( browser serverFriday, April 6, 12
  • 9. the past comet, polling and other methods to abuse the web can i has data nope, dun has dataz ;( can i has data pretty plx browser serverFriday, April 6, 12
  • 10. the past comet, polling and other methods to abuse the web can i has data nope, dun has dataz ;( can i has data pretty plx yes, i has ur dataz browser serverFriday, April 6, 12
  • 11. the past comet, polling and other methods to abuse the web can i has data nope, dun has dataz ;( can i has data pretty plx yes, i has ur dataz ohi can i has dataz browser serverFriday, April 6, 12
  • 12. the past used transport methods XHR & JSONP polling can be used cross domain, JSONP connections usually use an iframe to post messagesFriday, April 6, 12
  • 13. the past used transport methods iFrame / HTMLFile streaming HTMLFile is used to hide the loading indicators as the connection with server is never closed so it can stream in new messagesFriday, April 6, 12
  • 14. the past used transport methods Plugins, Java, Flash, Silverlight everybody has this awesome bloatware installedFriday, April 6, 12
  • 15. the past used transport methods EventSource and multipart XHR EventSource was actually implemented in opera 9 and combined with XHR multi-part from firefox we got two good streaming read only solutionsFriday, April 6, 12
  • 16. the past used transport methods window.name used to create cross-domain browser transport, first used in DojoFriday, April 6, 12
  • 17. HTML5 the futureFriday, April 6, 12
  • 18. websockets the good parts ™Friday, April 6, 12
  • 19. ™ the good parts ™ BidirectionalFriday, April 6, 12
  • 20. ™ the good parts ™ Bidirectional PersistentFriday, April 6, 12
  • 21. ™ the good parts ™ Bidirectional Persistent Light weightFriday, April 6, 12
  • 22. ™ the good parts ™ Bidirectional Persistent Light weight Blazing fastFriday, April 6, 12
  • 23. websockets the bad parts ™Friday, April 6, 12
  • 24. ™ the bad parts ™ No full browser coverageFriday, April 6, 12
  • 25. ™ the bad parts ™ No full browser coverage Browser issuesFriday, April 6, 12
  • 26. ™ the bad parts ™ No full browser coverage Browser issues Connection blockageFriday, April 6, 12
  • 27. ™ the bad parts ™ No full browser coverage Browser issues Connection blockage Bad server HTTP proxy supportFriday, April 6, 12
  • 28. ™ the bad parts ™ no full browser support yet 16+ 8+ 11.6+ 5+ 10+ RFC RFC HIXIE HIXIE RFCFriday, April 6, 12
  • 29. ™ the bad parts ™ browser issuesFriday, April 6, 12
  • 30. ™ the bad parts ™ browser issues Usage or detecting a HTTP proxy (AutoProxyDiscovery) crashes < Safari 5.1.4 and Mobile Webkit your fucked or use user agent sniffingFriday, April 6, 12
  • 31. ™ the bad parts ™ browser issues Writing to a closed WebSocket connection can crash the browser & tabs check for connection state with a setTimeoutFriday, April 6, 12
  • 32. ™ the bad parts ™ browser issues 3G connections can crash WebSocket fucked, again, disable websockets on portable devices, until netinfo API is supportedFriday, April 6, 12
  • 33. ™ the bad parts ™ browser issues Pressing ESC in Firefox will drop the established connection. Even after the page has fully loaded. capture the event early and try to cancel itFriday, April 6, 12
  • 34. ™ the bad parts ™ browser issues Sending invalid UTF-8 drops the connection escape & encodeURI your dataFriday, April 6, 12
  • 35. ™ the bad parts ™ browser issues TCP socket leaks in Chrome if you get disconnected from the internet you’re fucked, no way to detectFriday, April 6, 12
  • 36. ™ the bad parts ™ browser issues Firefox doesn’t connect to ws:// from a secure https page. can be detected <3!Friday, April 6, 12
  • 37. ™ the bad parts ™ connection blockage firewall browser anti-virus server pluginsFriday, April 6, 12
  • 38. ™ the bad parts ™ connection blockage 3% of all requests on port 4000 were blocked out of the unique 100k connections tested enterprise proxies usually block everything except port 80,443,843 and virus scanners usually target port 80 for scanning & blockingFriday, April 6, 12
  • 39. Friday, April 6, 12
  • 40. ™ the bad parts ™ connection blockage to minimize the impact use SSL by default if this is not possible fallback from different ports 4000 843 80Friday, April 6, 12
  • 41. go hybridFriday, April 6, 12
  • 42. socket.ioFriday, April 6, 12
  • 43. socket.io Full hybrid real time server blurring the differences between transport methods 100% JavaScript powered by Node.js <3, npm install socket.io and your done, but it’s also ported to different languages Open Souce MIT license github.com/LearnBoost/socket.io(-client)Friday, April 6, 12
  • 44. socket.io Comes with tons of features encoding, multiplexing, heartbeats, authentication, scalingFriday, April 6, 12
  • 45. socket.io high performance, lower is better Google Chrome 16 x wsFriday, April 6, 12
  • 46. socket.io autobahn testsuite wsFriday, April 6, 12
  • 47. socket.io how does it work visitor socket.ioFriday, April 6, 12
  • 48. socket.io how does it work handshake request visitor socket.ioFriday, April 6, 12
  • 49. socket.io how does it work accepted transports, connection id and config is returned handshake accepted visitor socket.ioFriday, April 6, 12
  • 50. socket.io how does it work feature detection is used to find a working transport layer visitor socket.ioFriday, April 6, 12
  • 51. socket.io supported transport methods Web Socket HIXIE 75/76 HIBIFriday, April 6, 12
  • 52. socket.io supported transport methods Web Socket HIXIE 75/76 HIBI Flash Socket FLASH 10+Friday, April 6, 12
  • 53. socket.io supported transport methods Web Socket HIXIE 75/76 HIBI Flash Socket FLASH 10+ HTML File IE 5.5+Friday, April 6, 12
  • 54. socket.io supported transport methods Web Socket HIXIE 75/76 HIBI Flash Socket FLASH 10+ HTML File IE 5.5+ XHR Polling IE6,FF,OPERA,WEBKITFriday, April 6, 12
  • 55. socket.io supported transport methods Web Socket HIXIE 75/76 HIBI Flash Socket FLASH 10+ HTML File IE 5.5+ XHR Polling IE6,FF,OPERA,WEBKIT JSONP Polling EVERYONEFriday, April 6, 12
  • 56. socket.io how does it work real time connection is established with the server visitor using the transport socket.ioFriday, April 6, 12
  • 57. socket.io how does it work heartbeats are send to ensure proper connection visitor socket.ioFriday, April 6, 12
  • 58. live CODINGFriday, April 6, 12
  • 59. socket.io next a.k.a engine.io & websocket.ioFriday, April 6, 12
  • 60. engine.io & websocket.io Transport upgrading instead of downgrading faster connection times, less prone to errorsFriday, April 6, 12
  • 61. engine.io & websocket.io Transport upgrading instead of downgrading faster connection times, less prone to errors Smaller because theres no sugar on top and transports can be lazy loadedFriday, April 6, 12
  • 62. engine.io & websocket.io Transport upgrading instead of downgrading faster connection times, less prone to errors Smaller because theres no sugar on top and transports can be lazy loaded WebSocket only interface for those of your who think websockets are good enough, but you really shouldn’tFriday, April 6, 12
  • 63. Q&Awill be answered in real time talk nerdy to meFriday, April 6, 12
  • 64. github @3rd-eden & @3rdeden twitterFriday, April 6, 12
