0
<ul><li>Developing occlusion </li></ul><ul><li>Facial form analysis </li></ul><ul><li>Mixed dention analysis </li></ul><ul...
The examination should begin with a complete history and an evaluation of the patient’s past & present systemic diseases
<ul><li>There is a close relationshipe between the development of occlusion and the development of the face . </li></ul><u...
<ul><li>An analysis of facial form will serve to appraise the harmony of  growth  and  development  of the facial skeleton...
<ul><li>B- The exam iner  should  not base  his entire evaluation of malocclusion on the relationshipe of the first perman...
<ul><li>*  An appraisal of the profile may be made by use of the  Frankfort horizontal  ( eye – ear)plane and a plane perp...

<ul><li>Four points  of reference may be used to evauate changes in the anteroposterior relationship of  of the parts </li...
<ul><li>Displacement of the mandible may be :- </li></ul><ul><li>Skeletal , dental or fuunctional  </li></ul><ul><li>Retro...

<ul><li>Visual inspection  of the space occupied by the  nose,upper lip,lower lip & chin  while the lips are brought toget...
<ul><li>Asymmetries of the frontal facial form are best considered relative the midsagital plane </li></ul><ul><li>Systema...

<ul><li>The typical adenoid facies is characterized by thin face,pinched nose,high arched palate& often  retrognathia </li...
Hatched face,flat face,mouse face,dish face,are obvoius indications for an analysis of the facial form
<ul><li>In children 8-12 years of age  </li></ul><ul><li>The angle made by the base of the mandible and the ascending ramu...







<ul><li>1- the primary dentition </li></ul><ul><li>2- The mixed dentition  </li></ul><ul><li>3- The occlusion of the perma...
<ul><li>3 -5 year  </li></ul><ul><li>More stable, ovoid arch </li></ul><ul><li>Fewer anomalies than either the mixed or pe...

<ul><li>The length of the arch, from the distal surface of the second primary molar around to the distal surface of the op...

<ul><li>The primary dentition  is characterized by a straight axial inclination of the incisors with an </li></ul><ul><li>...


1-Early loss of primary teeth 2-Prolonged retention of the primary teeth  3-Oral habits ( sucking)
Where the anterior relationship is  normal ,an  open-bite  of this type may be  self - correcting ,provided that the child...
<ul><li>The first permanent molar erupt  at 6-7 y. </li></ul><ul><li>Crowded & rotated position  </li></ul><ul><li>Tooth e...






<ul><li>Prediction of malocclusion based on :- </li></ul><ul><li>sequence of eruption without a consideration of such fact...
Crowded,permenent incisors erupt lingually to decideus teeth, Diastema – leeway space
<ul><li>Etiologic factors that can contribute to a  loss of space :- </li></ul><ul><li>1-the premature loss of primary tee...
A harmonious balance between the oral and facial musculature and the teeth  are very important .









<ul><li>Contributes to :- </li></ul><ul><li>1- facial asymmetry </li></ul><ul><li>2- TMD </li></ul><ul><li>3- disturbances...


Lateral&other abnormal shifts of the mandible ( protrusion) may be observed by the examiner when the patient is requested ...
An occlusion that is  considered normal  at the age of  18  years  cannot  be considered normal for the same individual at...
Extraction, replacement of teeth, attration,extrusion,tipping,migration
It is a systematic examination of the anatomy and function of the masticatory system with special consideration given  to ...
<ul><li>1- Complete case history  </li></ul><ul><li>2- Mastictory system (joints,muscles,psychic factors,fatigue,anaxiety,...
<ul><li>A diagnosis of occlusal trauma must be made on the basis of an analysis of the occlusion during empty movement ( s...
<ul><li>Increased tooth mobility </li></ul><ul><li>Migration of teeth </li></ul><ul><li>Root resorption </li></ul><ul><li>...
Pain in and around the joints  Restriction of mandibular movements Tenderness of masticatiory muscles Clicking noises in t...
<ul><li>Etiologic factors  responsible for disharmony of the masticatory system as well as for traumatic TMJ arthritis are...
<ul><li>non-functional  grinding of the teeth is an important predisposing factor in occlusal trauma and  dysfunctional  d...
<ul><li>1-Occlusal interferences </li></ul><ul><li>2-Psychic tension  </li></ul><ul><li>3-Periodontal diseases </li></ul>
<ul><li>1- nonfunctional facets of occlusal wear </li></ul><ul><li>2- tenderness of masticatory muscles </li></ul><ul><li>...
<ul><li>Examination of the edentulous and partially edentulous mouth </li></ul>
Sharpnes,flatness,height and relation to the opposing arches, nasal spine,zygomatic process of the maxilla,hamulus,mental ...
The main difference lies in the analysis. the  analysis of the areas  to recive  dentures relates to effective impressions...
*Areas required relief  *Hard & soft tissue  *Dentures already being worn
Bony spines,unerupted teeth,retained roots,hyperplastic tissue,tori,protuberant alveolar ridges,frenula,inadequate buccal ...
<ul><li>Midline ,anterior nasal spine,concavity of the canine fossa,maxillary buttress of zygomatic arch,labial & buccal f...
<ul><li>Palpation of anterior border of the ramus </li></ul><ul><li>At rest & during movement of the mandible </li></ul><u...
The separation of complaints of organic origin from those caused by lack of adjustment often taxes the skull and patience ...
<ul><li>1-sorness of tissues </li></ul><ul><li>(Break of mucosa,tenderness,ulceration ) </li></ul><ul><li>2-Contact dermat...
<ul><li>1-vitality of teeth,caries,attrition </li></ul><ul><li>2-condition of the supporting tissues </li></ul><ul><li>3-s...
<ul><li>8-form of roots & crowns to be used as abutments </li></ul><ul><li>9- relationship of the alveolar ridge to frenul...
<ul><li>DENTUER STOMATITS </li></ul><ul><li>ACRYLIC RESIN BURN </li></ul>
<ul><li>ATROPHY OF MAXILLARY ALVOLAR RIDGE </li></ul><ul><li>DENTURE  FISSURATUM </li></ul>
