SCIM presentation from CIS 2012

Intro to SCIM Travis Spencer, CEO Twobo Technologies

The Problem• Modern systems are massively distributed• Organizations need to automate user/group management across domain boundaries• Large cloud providers have their own APIs• Enterprise-to-enterprise is a dog’s dinner• Identity is the fly in the integration ointment

The Resulting Reality• Tactical, bespoke methods that can’t scale• Expensive integration work & custom development• Systems maintain isolated silos of user data• X-employees continue accessing resources• Solution is automation based on open standards

Banding Together to Solve this Problem• Salesforce, Google, UnboundID, Ping Identity, Sailpoint, Technology Nexus, etc.• Protocol drafted, tested, and released in 2011 Q1 – Initial draft of spec Q2 – Updated draft discussed at IIW Q3 – Consortium formed under OWF, interop tests at IIW Q4 – V. 1 agreed upon by consortium, submitted to IETF

SCIM, a Modern Standard for Automation• The spec formerly known as Simple Cloud…• Provisioning API to manage users & groups• Support bulk updates for ingest & sync• Low-tech barrier, easy w/ curl & JavaScript• Designed w/ mobile in mind• Goes hand-in-glove w/ federation• Secure access using OAuth 2 et. al

SCIM Specification SetREST API for CRUD Federation Binding• JSON & XML • SAML• Response codes • TBD: OpenID ConnectCore Schema• User • Groups• Enterprise Extension • Config

Features of SCIM• Core schema – Models user, groups, etc. – Defines basic user attributes (name, address, etc.)• RESTful API – Defines CRUD to synchronize resources – JSON and XML data formats• Federation bindings – SAML, OIC – Supports JIT provisioning during SSO – Maps SCIM schema to federation protocols

Push ProvisioningIdP Organization SP Organization CRUD of user object SCIM SCIM Client Server Status

JIT ProvisioningIdP Organization SP Organization Create user on the fly IdP SP User data in federation message Browser

JIT + PullIdP Organization SP Organization Create new user User object IdP / SCIM SP / SCIM Get User Server Client Access token in federation message Browser

Overview of API• RESTful• Specifies well known endpoints & HTTP methods for managing core resources – User and group resources correspond to /Users and /Groups, respectively• Responses are returned in the body of the HTTP messages in JSON or XML format

Authentication and Security• Spec does not mandate a particular authentication scheme• OAuth 2 is recommended, but others are not precluded (e.g., HTTP basic)• Client and server must exchange data over SSL/TLS

Supported HTTP VerbsVerb MeaningGET Retrieves a resourcePOST Creates a new resourcePUT Completely update a resourcePATCH Partially update a resourceDELETE Delete a resource

Controlling Responses• Filter (i.e., search) – Find specific resources – Request a subset of attributes• Sorting – Sort by – Sort order• Pagination – Client maintains offset and count – No server-side cursors (v. 2 probably)

Extensible Schema• Protocol defines core schema used to represent resources of various types – Modeled after POCO & others – Also stipulates how to extend• Defines enterprise extensions – Adds manager, department, organization, etc.• Others can be created at will

Includes Mapping from Active DirectoryActive Directory SCIMuserPrincipalName userNamemail email.value@type=workgivenName name.givenNamesn name.familyNamewhenCreated meta.whenCreateduserPassword passwordcn displayName

Retrieving User Data GET request = GET /Users/2819c223-7f76-453a-919d-413861904646 read Host: example.com Accept: application/json User ID Authorization: Bearer h480djs93hd8 Return JSON HTTP/1.1 200 OK Attributes are Content-Type: application/json in JSON format200 = successful Location: response https://example.com/v1/Users/2819c223-7f76- 453a-919d-413861904646 ETag: W/"f250dd84f0671c3" Same User ID { ... "name":{ "formatted":"Ms. Barbara J Jensen III", "familyName":"Jensen", Attributes "givenName":"Barbara" }, "userName":"bjensen",

Updating a Group with a new Member PATCH /Groups/acbf3ae7-8463-4692-b4fd-PATCH = only 9b4da3f908ceupdate what’s Host: example.com Secure access changed Accept: application/json using OAuth 2 Authorization: Bearer h480djs93hd8 ETag: W/"a330bc54f0671c9" { "schemas": ["urn:scim:schemas:core:1.0"], "members": [ { "display": "Babs Jensen", New group "value": "2819c223-7f76-453a…" member; others } are unchanged ] }

SCIM vis-à-vis UserInfo Endpoint in OIC User Agent 1. Get a token AS Client RS 3. Use a token 2. Read a token User- SCIM Info OIC SCIM API Base OAuth

What’s Next for SCIM?• More and more implementations!• PingOne and UnboundID’s synchronization server are already in the market• Major SaaS providers are launching this year• Other IAM vendors releasing soon• IETF working group has been formed – Date of completion projected for 2014 – V. 1 is available today

Support SCIM• SaaS and IdM vendors must implement SCIM for it to solve anything• Demand standards-based automation of identity; demand SCIM • Join IETF mailing list; attend WG meetings

Thank You and More Info• @travisspencer• @pingidentity• simplecloud.info• travisspencer.com• 2botech.com• pingidentity.com
