HTML5 Essentials
        by Marc Grabanski
• Less Header Code
• More Semantic HTML tags
• Media Tags
• Geolocation
• Canvas
• Input Types
• Form Validation
• Draggab...
Less Header Code

<!DOCTYPE HTML>
<html>
<head>
  <meta charset=”utf-8”>
  <title>foo</title>
</head>
...
No need for type attribute

<script src=”foo.js”>
</script>

<link href=”foo.css”></link>
More Semantic HTML tags
           <div id=”header”>

             <div id=”nav”>

 <div id=”article”>    <div id=”sidebar...
More Semantic HTML tags
              <header>

               <nav>

 <section>               <aside>

  <article>




  ...
Fix IE for HTML5 elements

document.createElement(‘header’);
HTML5 Shiv
<!--[if lte IE 8]>
<script src="http://html5shiv.googlecode.com/
svn/trunk/ html5.js"></script>
<![endif]-->

o...
Output
<output name="result"></output>
Progress
<progress id="p" max=100><span>0</span>%</progress>
Progress in Action
<p>Progress: <progress id="p" max=100><span>0</span>%</
progress></p>
 <script>
  var progressBar = doc...
Progress is for status of a set of tasks

Meter is for a gauge of measure
Meter

Storage space usage:
<meter value=6 max=8>6 blocks used (out of 8 total)
</meter>

Voter turnout:
<meter value=0.75...
Details and Summary
<details>
 <summary>Copying... <progress max="375505392"
value="97543282"></progress> 25%</summary>
 <...
Address

<address>
 <a href="../People/Raggett/">Dave Raggett</A>,
 <a href="../People/Arnaud/">Arnaud Le Hors</A>,
 conta...
Data Attributes
<div class="spaceship" data-ship-id="92432"
   data-weapons="laser 2" data-shields="50%"
   data-x="30" da...
Section
<article>
<hgroup>
 <h1>Apples</h1>
 <h2>Tasty, delicious fruit!</h2>
</hgroup>
<p>The apple is the pomaceous frui...
Good
       <body>
        <h4>Apples</h4>
        <p>Apples are fruit.</p>
        <section>
        <h2>Taste</h2>
     ...
Better
         <body>
          <h1>Apples</h1>
          <p>Apples are fruit.</p>
          <section>
          <h2>Tast...
Figure and Figure Caption

<figure>
 <img src="bubbles-work.jpeg"
    alt="Bubbles, sitting in his office chair, works on ...
Figure and Figure Caption
<p>In <a href="#l4">listing 4</a> we see the primary
core interface
API declaration.</p>
<figure...
Time and Publish Date Attribute
<time pubdate datetime="2009-10-09T14:28-08:00"></time>
<article>
 <header>
  <h1>The Very First Rule of Life</h1>
  <p><time pubdate datetime="2009-10-09T14:28-08:00"></time></p...
Breadcrumb Navigation
<nav>
 <p>
 <a href="/" rel="index up up up">Main</a> >
 <a href="/products/" rel="up up">Products</...
Menu and Command

<menu type="toolbar">
<command type="radio" radiogroup="alignment" checked="checked"
     label="Left" i...
Menu (continued)
 <menu type="toolbar">
 <li>
 <menu label="File">
  <button type="button" onclick="fnew()">New...</button...
Mark is highlighting something
<p><mark>Momentum is preserved across the wormhole.
Electromagnetic
radiation can travel in...
Not all Navigation should use <nav>

          <nav></nav>

only main navigation, for instance
footer nav is secondary
Article is unique content to the page.

       <article></article>
Hgroup, highest rank group of headings

        <hgroup></hgroup>
Itemscope and Itemprop

  <div itemscope>
  <p>My name is <span itemprop="name">Elizabeth</span>.</p>
  </div>

  <div ite...
Media Tags

<video src=” cat.ogg” />

add native controls
<video src=”cat.ogg” controls />
Media Tags


<video controls/>
 <source src=”cat.mp4” />
 <source src=”cat.ogg” />
</video>




http://camendesign.com/cod...
Video Format Support

Ogg Theora/Voribs

 - Firefox 3.5+
 - Chrome
 - Opera

MPEG-4 H.264/AAC

 - Safari
 - Chrome
 - Opera
Native Video          Fallback with Flash
- Safari (v4.0.4+)
- Google Chrome (v4.0+)
- Firefox (v3.6+)

 http://jilion.com...
Media Tags

<audio src=”test.ogg”></audio>

<audio src=”test.ogg” autoplay controls loop>
 <a href=”test.ogg”>download</a>...
Native GeoLocation

navigator.geolocation.getCurrentPosition(
   function(position){
     position.coords.latitude,
     p...
GeoLocation w/ Google Ajax API fallback
   if (navigator && navigator.geolocation) {
     // HTML5 GeoLocation
     functi...
Canvas

<canvas id=”square”>
 fallback content
</canvas>

<script>
canvas = canvas.getElementById(‘square’);
context = can...
Canvas Internet Explorer Support

ExplorerCanvas
http://code.google.com/p/explorercanvas/
Input Types

   <input type=”email” />

    tel          datetime
    search       date
    email        range
    url    ...
Input Types
Input type changes keyboard on iphone.
Input Type Range
Input Type Range + Datalist

<input type="range" min="-100" max="100"
value="0" step="10" name="power" list="powers">
<dat...
Input Type Number + Output

<input name=a type=number step=any> +
 <input name=b type=number step=any> =
 <output onformin...
File Upload Multiple


   <input type=file multiple>
Input Type Email + Multiple


<label>Cc: <input type=email multiple name=cc></label>
Datalist

<label>Homepage: <input name=hp type=url list=hpurls></label>
<datalist id=hpurls>
 <option value="http://www.go...
Form Validation


<input name="custname" required>

<script>
form.checkValidity();
</script>
Custom Validation

<label>Feeling: <input name=f type="text" oninput="check(this)"></label>
<script>
 function check(input...
Storage


sessionStorage.setItem(key, value);
sessionStorage.getItem(key);

localStorage.setItem(key, value);
localStorage...
Local Storage in Yahoo! Search Pad
Local Storage in Yahoo! Search Pad




    http://www.jstorage.info/
Application Storage / Offline


<html manifest=”cache.manifest”>

detect online or offline

window.addEventListener('onlin...
Draggable

<div draggable=”true”></div>

addEvent(div, “dragstart”, function(e){
  e.dataTransfer.setData(‘foo’, ‘bar’);
}...
Cross Domain Messaging


postMessage(string);

onMessage(event) {
  event.data;
}
Editable Content

Turn an element into an editable area.
<script>
 document.getElementsByTagName('p')[0].contentEditable =...
Web Sockets
var ws = new WebSocket("ws://hostname:80/");
ws.onmessage = function (event) {
  event.data
};
ws.onclose = fu...
Web Worker


new Worker("worker.js");


- Don’t have access to DOM or page.
- Have to communicate through postMessage API
http://html5demos.com/
Web GL

                   3D O3D
http://www.youtube.com/watch?v=uofWfXOzX-g
Questions?

Marc Grabanski:
http://marcgrabanski.com

User interface and web application
development.
Examples: http://mjg...
